NISSAN ALMERA N16 2003  Electronic Repair Manual TROUBLE DIAGNOSIS
EC-463
[QG (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
62 Y/RIntake valve timing control
solenoid valve[Engine is running]
●Warm-up condition
●Idle speedBATTERY VOLTAGE
(11 -

Page 794 of 3189

NISSAN ALMERA N16 2003  Electronic Repair Manual EC-464
[QG (WITHOUT EURO-OBD)]
TROUBLE DIAGNOSIS
82 BSensor ground
(Accelerator pedal position
sensor 1)[Engine is running]●Warm-up condition
●Idle speedApproximately 0V
83 BSensor ground
(Accele

Page 795 of 3189

NISSAN ALMERA N16 2003  Electronic Repair Manual TROUBLE DIAGNOSIS
EC-465
[QG (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
: Average voltage for pulse signal (Actual pulse signal can be confirmed by oscilloscope.)
CONSULT-II FunctionEBS00KF0
FUNCTI

Page 796 of 3189

NISSAN ALMERA N16 2003  Electronic Repair Manual EC-466
[QG (WITHOUT EURO-OBD)]
TROUBLE DIAGNOSIS
ENGINE CONTROL COMPONENT PARTS/CONTROL SYSTEMS APPLICATION
X: Applicable
*1: This item includes 1st trip DTCs.
*2: This mode includes 1st trip freeze f

Page 797 of 3189

NISSAN ALMERA N16 2003  Electronic Repair Manual TROUBLE DIAGNOSIS
EC-467
[QG (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
2. Connect  “CONSULT-II”  and ″CONSULT-II  CONVERTER″ to
data link connector, which is located under the driver’s s

Page 798 of 3189

NISSAN ALMERA N16 2003  Electronic Repair Manual EC-468
[QG (WITHOUT EURO-OBD)]
TROUBLE DIAGNOSIS
*: This function is not necessary in the usual service procedure.
SELF-DIAG RESULTS MODE
Self Diagnostic Item
Regarding items of “DTC and 1st trip DT

Page 799 of 3189

NISSAN ALMERA N16 2003  Electronic Repair Manual TROUBLE DIAGNOSIS
EC-469
[QG (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
DATA MONITOR MODE
Monitored Item
×: Applicable
Monitored item
[Unit]ECM
INPUT
SIG-
NALSMAIN
SIG-
NALSCAN
DIAG
SUP-
PORT

Page 800 of 3189

NISSAN ALMERA N16 2003  Electronic Repair Manual EC-470
[QG (WITHOUT EURO-OBD)]
TROUBLE DIAGNOSIS
THRTL SEN 1 [V]××●The throttle position sensor signal volt-
age is displayed.
THRTL SEN 2 [V]×
INT/A TEMP SE
[°C] or [°F]××
●The intake air
