Page 3041 of 3189

NISSAN ALMERA N16 2003 Electronic Repair Manual REMOVAL AND INSTALLATION/3-DOOR HATCHBACK=NJRS00571. Slide the seat all the way forward and tilt the seatback toward the front. 2. Remove adjuster cover. 3. Remove floor anchor bolt. 4. Remove shoulde

Page 3042 of 3189

NISSAN ALMERA N16 2003 Electronic Repair Manual NRS134 SEAT BELTS Front Seat Belt (Cont’d) RS-10

Page 3043 of 3189

NISSAN ALMERA N16 2003 Electronic Repair Manual Rear Seat Belt REMOVAL AND INSTALLATION/4-DOOR SEDAN WITH 2-POINT TYPE REAR CENTER SEAT BELT =NJRS00421. Remove rear seat. Refer to BT-59, “REAR SEAT” for details. 2. Remove outer and floor anchor

Page 3044 of 3189

NISSAN ALMERA N16 2003 Electronic Repair Manual SRS815 SEAT BELTS Rear Seat Belt (Cont’d) RS-12

Page 3045 of 3189

NISSAN ALMERA N16 2003 Electronic Repair Manual REMOVAL AND INSTALLATION/4-DOOR SEDAN WITH 3-POINT TYPE REAR CENTER SEAT BELT =NJRS00631. Remove rear seat. Refer to BT-59, “REAR SEAT” for details. 2. Remove outer and floor anchor bolt. 3. Remov

Page 3046 of 3189

NISSAN ALMERA N16 2003 Electronic Repair Manual SRS890 SEAT BELTS Rear Seat Belt (Cont’d) RS-14

Page 3047 of 3189

NISSAN ALMERA N16 2003 Electronic Repair Manual REMOVAL AND INSTALLATION/HATCHBACK WITH 3–POINT TYPE REAR CENTER SEAT=NJRS00581. Remove rear seat. Refer to BT-59, “REAR SEAT” for details. 2. Remove outer and floor anchor bolt. 3. Remove rear

Page 3048 of 3189

NISSAN ALMERA N16 2003 Electronic Repair Manual SRS877-A SEAT BELTS Rear Seat Belt (Cont’d) RS-16
