15 CHECK HARNESS CONTINUITY BETWEEN GLOW RELAY AND GLOW PLUG FOR OPEN AND SHORT
1. Disconnect glow plug harness connector.
2. Check harness continuity between glow relay terminal 3 and glow plug harness connector. Refer to Wiring Diagram.
Continuity should exist.
3. Also check harness for short to ground and short to power.
OK or NG
OK GO TO 16.
NG Repair open circuit or short to ground or short to power in harness or connectors.
16 CHECK GLOW RELAY
Check continuity between glow relay terminals 3 and 5 under the following conditions.
SEF433Y
OK or NG
OK GO TO 17.
NG Replace glow relay.
17 CHECK GLOW PLUG
1. Remove glow plug connecting plate.
2. Check glow plug resistance.
SEF434Y
NOTE:
Do not bump glow plug heating element. If it is bumped, replace glow plug withanewone.
If glow plug is dropped from a height of 10 cm (3.94 in) or higher, replace with a new one.
If glow plug installation hole is contaminated with carbon, remove it witha reamer or suitable tool.
Hand-tighten glow plug by turning it two or three times, then tighten usinga tool to specified torque.
: 17.7 - 22.5 N·m (1.8 - 2.3 kg-m, 13 - 16 ft-lb)
OK or NG
OK GO TO 18.
NG Replace glow plug.
GI
MA
EM
LC
FE
CL
MT
AT
AX
SU
BR
ST
RS
BT
HA
SC
EL
IDX
GLOW CONTROL SYSTEMYD
Diagnostic Procedure (Cont’d)
