2003 NISSAN ALMERA N16 Electronic Repair Manual

garage door opener instrument cluster cabin filter high beam water pump trunk release

Load previous 8 pages

Page 2689 of 3189

NISSAN ALMERA N16 2003 Electronic Repair Manual Wiring Diagram — MULTI —NJEL0481FIG. 1NJEL0481S01
YEL765D
GI
MA
EM
LC
EC
FE
CL
MT
AT
AX
SU
BR
ST
RS
BT
HA
SC
IDX
MULTI-REMOTE CONTROL SYSTEM
Wiring Diagram — MULTI —
EL-353

Page 2690 of 3189

NISSAN ALMERA N16 2003 Electronic Repair Manual FIG. 2NJEL0481S02
YEL766D
MULTI-REMOTE CONTROL SYSTEM
Wiring Diagram — MULTI — (Cont’d)
EL-354

Page 2691 of 3189

NISSAN ALMERA N16 2003 Electronic Repair Manual SIIA1645E
Trouble Diagnoses/QG and YD Engine Models
with Common Rail
NJEL0582CONSULT-II INSPECTION PROCEDURENJEL0582S011. Turn ignition switch “OFF”.
2. Connect CONSULT-II to the data link connect

Page 2692 of 3189

NISSAN ALMERA N16 2003 Electronic Repair Manual CONSULT-II APPLICATION ITEMSNJEL0582S02DATA MONITOR
Monitored Item Description
IGNITION SW Indicates [ON/OFF] condition of ignition switch in ON position.
TRUNK OPEN SW Indicates [ON/OFF] condition of

CONSULT-II APPLICATION ITEMSNJEL0582S02DATA MONITOR
Monitored Item Description
IGNITION SW Indicates [ON/OFF] condition of ignition switch in ON position.
TRUNK OPEN SW Indicates [ON/OFF] condition of trunk room lamp switch (sedan) or back door switch (wagon).
RKE LOCK Indicates [ON/OFF] condition of lock signal from remote controller.
RKE UNLOCK Indicates [ON/OFF] condition of unlock signal from remote controller.
RKE SEL UNLOCK Indicates [ON/OFF] condition of select unlock signal from remote controller.
RKE TRUNK RELIndicates [ON/OFF] condition of trunk (sedan) or back door (wagon) open signal from trunk or
back door release switch.
BATTERY CHECK Indicates [OK/NG] condition of remote controller battery.
WORK SUPPORT
Test Item Description
KEYLESS CHECK It can be checked whether remote controller ID code is registered or not in this mode.
KEYLESS REGISTRATION Remote controller ID code can be registered.
KEYLESS DI FLASH This mode can be setting remote controller function.
SYMPTOM CHARTNJEL0582S03First perform the “SELF-DIAG RESULTS” in “SMART ENTRANCE”
with CONSULT-II, when perform the each trounble diagnosis. Refer
to EL-355, “CONSULT-II INSPECTION PROCEDURE”.
NOTE:
Always check remote controller battery before replacing
remote controller.
Symptom Diagnoses/service procedureReference
page
All function of multi-remote control system do not
operate.Remote controller battery check EL-357
Power supply and ground circuit for smart entrance control
unit checkEL-358
.If above systems are OK, replace smart entrance control unit. —
The new ID of remote controller cannot be
entered.Remote controller battery check EL-357
Key switch check —
Door switch check —
Power supply and ground circuit check EL-358
If above systems are OK, replace smart entrance control unit. —
Door lock or unlock does not function.If the power door lock system does not operate manually,
check power door lock system.EL-356
Remote controller battery check EL-357
If above systems are OK, replace smart entrance control unit. —
Hazard reminder does not activate properly
when pressing lock or unlock button of remote
controller.Remote controller battery check EL-357
Hazard reminder check EL-359
If above systems are OK, replace smart entrance control unit. —
MULTI-REMOTE CONTROL SYSTEM
Trouble Diagnoses/QG and YD Engine Models with Common Rail (Cont’d)
EL-356

Page 2693 of 3189

NISSAN ALMERA N16 2003 Electronic Repair Manual REMOTE CONTROLLER BATTERY CHECKNJEL0582S04
1 CHECK REMOTE CONTROLLER BATTERY
Remove battery and measure voltage across battery positive and negative terminals, (+) and (−).
SEL237W
Voltage: 2.5V - 3

Page 2694 of 3189

NISSAN ALMERA N16 2003 Electronic Repair Manual POWER SUPPLY AND GROUND CIRCUIT CHECKNJEL0582S05
1 CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect smart entrance control unit connector.
3. Check voltage between smart entrance

Page 2695 of 3189

NISSAN ALMERA N16 2003 Electronic Repair Manual HAZARD REMINDER CHECKNJEL0582S06
1 CHECK HAZARD WARNING LAMP
Check if hazard warning lamp flashes with hazard switch.
Does hazard warning lamp operate?
Ye s G O T O 2 .
No Check hazard warning lamp ci

Page 2696 of 3189

NISSAN ALMERA N16 2003 Electronic Repair Manual Trouble Diagnoses/YD Engine Models without
Common Rail and K9K Engine Models
=NJEL0482SYMPTOM CHARTNJEL0482S01NOTE:
Always check remote controller battery before replacing remote
controller.
Symptom D
