NISSAN ALMERA N16 2003 Electronic Repair Manual REAR WINDOW DEFOGGER INDICATOR LAMP DOES
NOT ILLUMINATE
=NJEL0553S06
1 CHECK POSITION OF IGNITION SWITCH
Is ignition switch ON?
OK or NG
OK GO TO 2.
NG Rear window defogger does not operate if ignitio

Page 2522 of 3189

NISSAN ALMERA N16 2003 Electronic Repair Manual Trouble Diagnoses/YD Engine Models without
Common Rail and K9K Engine Models
=NJEL0465DIAGNOSTIC PROCEDURENJEL0465S01SYMPTOM: Rear window defogger does not activate, or does
not go off after activatin

Page 2523 of 3189

NISSAN ALMERA N16 2003 Electronic Repair Manual 3 CHECK REAR WINDOW DEFOGGER SWITCH INPUT SIGNAL
Check continuity between time control unit terminal 3 and ground.
SEL457X
OK or NG
OK GO TO 4.
NGCheck the following.
Rear window defogger switch
(Refe

Page 2524 of 3189

NISSAN ALMERA N16 2003 Electronic Repair Manual 5 CHECK CONTROL UNIT GROUND CIRCUIT
Check continuity between time control unit terminal 16 and ground.
SEL448X
Yes Replace time control unit.
No Repair harness or connectors.
REAR WINDOW DEFOGGER
Trou

Page 2525 of 3189

NISSAN ALMERA N16 2003 Electronic Repair Manual SEL970W
Electrical Components Inspection=NJEL0076REAR WINDOW DEFOGGER RELAYNJEL0076S01Check continuity between terminals 3 and 5, 6 and 7.
Condition Continuity
12V direct current supply between ter-
m

Page 2526 of 3189

NISSAN ALMERA N16 2003 Electronic Repair Manual SEL263
Filament Check=NJEL00771. Attach probe circuit tester (in volt range) to middle portion of
each filament.
SEL122R
When measuring voltage, wrap tin foil around the top of
the negative probe. The

Page 2527 of 3189

NISSAN ALMERA N16 2003 Electronic Repair Manual Filament RepairNJEL0078REPAIR EQUIPMENTNJEL0078S011) Conductive silver composition (Dupont No. 4817 or equivalent)
2) Ruler 30 cm (11.8 in) long
3) Drawing pen
4) Heat gun
5) Alcohol
6) Cloth
BE540
RE

Page 2528 of 3189

NISSAN ALMERA N16 2003 Electronic Repair Manual System Description=NJEL0497AUDIO SYSTEM WITHOUT DISPLAYNJEL0497S08Refer to Owner’s Manual for audio system operating instructions.
Power is supplied at all times
through 15A fuse (No. 40, located in

System Description=NJEL0497AUDIO SYSTEM WITHOUT DISPLAYNJEL0497S08Refer to Owner’s Manual for audio system operating instructions.
Power is supplied at all times
through 15A fuse (No. 40, located in the fusible link and fuse block)
to audio unit terminal 9.
With the ignition switch in the ACC or ON position, power is supplied
through 10A fuse [No. 1, located in the fuse block (J/B)]
to audio unit terminal 3.
Ground is supplied through the case of the audio unit.
Audio signals are supplied
through audio unit terminals 7, 10, 11, 12, 13, 14, 15, 16
to terminals 1 and 2 of front door speaker LH and RH,
to terminals 1 and 2 of rear door speaker LH and RH and
to terminals 1 and 2 of pillar tweeter LH and RH (with 6 speakers)
AUDIO SYSTEM WITH DISPLAYNJEL0497S09Refer to Owner’s Manual for audio system operating instructions.
Power is supplied at all times
through 15A fuse (No. 40, located in the fuse and fusible link box)
to audio unit terminals 3 and 4, and
to display terminals 21 and 23.
With the ignition switch in the ACC or ON position, power is supplied
through 10A fuse [No. 1, located in the fuse block (J/B)]
to audio unit terminal 2,
to multifunction switch terminal 6 and
to display terminal 19.
Ground is supplied through the case of the audio unit.
Ground is also supplied
through body grounds M28, M67 and F118 (QG engine models)
to multifunction switch terminal 1 and
to display terminals 22 and 24.
Audio signals are supplied
through audio unit terminals 5, 6, 7, 8, 9, 10, 11, 12
to terminals 1 and 2 of front door speaker LH and RH
to terminals 1 and 2 of rear door speaker LH and RH
to terminals 1 and 2 of tweeter LH and RH
AV COMMUNICATION LINENJEL0497S10Audio system is contained and the AV communication line is connected as followings.
Display unit terminals 12 and 13, and
Multifunction switch terminals 12 and 14.
Multifunction switch terminals 11 and 13, and
Audio unit terminals 31 and 32.
Audio unit terminals 35 and 36, and
AV and NAVI control unit terminals 47 and 48 (with navigation system).
The operation is controlled by operation signals from multifunction switch, then audio screen is displayed.
NAVIGATION SYSTEM OF GUIDANCE VOICE OPERATIONNJEL0497S11When navigation system is used, guidance voice signal is supplied
from AV and NAVI control unit terminals 7 and 8
to audio unit terminals 35 and 36.
Navigation system of guidance voice will be sounded.
AUDIO
System Description
EL-192
