AUTOMATIC DRIVE POSITIONER
Revision: October 20052005 QX56
LIWA0440E
Page 2994 of 3419
AUTOMATIC DRIVE POSITIONER
SE-29
C
D
E
F
G
H
J
K
L
MA
B
SE
Revision: October 20052005 QX56
WIWA0584E
Page 2995 of 3419

SE-30
AUTOMATIC DRIVE POSITIONER
Revision: October 20052005 QX56
Terminals and Reference Values for BCMEIS004XJ
Terminals and Reference Values for Driver Seat Control UnitEIS004XK
TERMINAL WIRE
COLORITEM CONDITIONVOLTAGE (V)
(Approx.)
11 O Ignition switch (ACC or ON) Ignition switch (ACC or ON position) Battery voltage
38 W/L Ignition switch (ON or START)Ignition switch (ON or START posi-
tion)Battery voltage
39 L CAN-H — —
40 P CAN-L — —
47 SB Front door switch LH ON (Open) → OFF (Closed) 0 → Battery voltage
67 B Ground — 0
70 W/B Battery power supply — Battery voltage
TERMINALWIRE
COLORITEM CONDITIONVOLTAGE (V)
(Approx.)
1LUART LINE (RX)Pedal adjusting switch ON (FOR-
WARD or BACKWARD operation)
3 L CAN-H — —
6 O Ignition switch (START) Ignition switch (START position) Battery voltage
9 L/R Reclining motor sensor signalON (seat reclining motor opera-
tion)
Other than above 0 or 5
10 W Rear lifting motor sensor signalON (rear lifting motor operation)
Other than above 0 or 5
11 R / BSliding switch BACKWARD sig-
nalON (seat sliding switch BACK-
WARD operation)0
Other than above Battery voltage
12 O/BReclining switch BACKWARD
signalON (seat reclining switch BACK-
WARD operation)0
Other than above Battery voltage
13 L/B Front lifting switch DOWN signalON (front lifting switch DOWN
operation)0
Other than above Battery voltage
PIIA4813E
SIIA0692J
SIIA0693J
Page 2996 of 3419

AUTOMATIC DRIVE POSITIONER
SE-31
C
D
E
F
G
H
J
K
L
MA
B
SE
Revision: October 20052005 QX56
14 G/W Rear lifting switch DOWN signalON (rear lifting switch DOWN
operation)0
Other than above Battery voltage
15 L/YPedal adjusting switch BACK-
WARD signalON (pedal adjusting switch BACK-
WARD operation) 0
Other than above Battery voltage
16 W Seat sensor power Ignition switch ON 5
17 W UART LINE (TX)Pedal adjusting switch ON (FOR-
WARD or BACKWARD operation)
19 P CAN-L — —
21 L/R A/T device (detent switch) signalSelector lever in P position 0
Selector lever other than P posi-
tion with ignition key in ignition cyl-
inderBattery voltage
24 Y/G Seat sliding motor sensor signalON (seat sliding motor operation)
Other than above 0 or 5
25 LG Front lifting motor sensor signalON (front lifting motor operation)
Other than above. 0 or 5
26 P/BSeat sliding switch FORWARD
signalON (seat sliding switch FOR-
WARD operation)0
Other than above Battery voltage
27 G/BSeat reclining switch FOR-
WARD signalON (seat reclining switch FOR-
WARD operation)0
Other than above Battery voltage
28 Y/B Front lifting switch UP signalON (front lifting switch UP opera-
tion)0
Other than above Battery voltage
29 R/W Rear lifting switch UP signalON (rear lifting switch UP opera-
tion)0
Other than above Battery voltage
30 RPedal adjusting switch FOR-
WARD signalON (pedal adjusting switch FOR-
WARD operation)0
Other than above Battery voltage TERMINALWIRE
COLORITEM CONDITIONVOLTAGE (V)
(Approx.)
PIIA4814E
PIIA3277E
SIIA0691J
Page 2997 of 3419

SE-32
AUTOMATIC DRIVE POSITIONER
Revision: October 20052005 QX56
Terminals and Reference Values for Automatic Drive Positioner Control UnitEIS004XL
31 L/Y Sensor ground — 0
32 B Ground — 0
33 L/B Battery power supply — Battery voltage
35 V/WSliding motor FORWARD out-
put signalSliding switch FORWARD opera-
tion (Motor operated)Battery voltage
Other than above 0
36 Y/GReclining motor FORWARD out-
put signalReclining switch FORWARD oper-
ation (Motor operated)Battery voltage
Other than above 0
37 BRFront lifting motor DOWN output
signalFront lifting switch DOWN opera-
tion (Motor operated)Battery voltage
Other than above 0
38 B/WRear lifting motor UP output sig-
nalRear end lifting switch UP opera-
tion (Motor operated)Battery voltage
Other than above 0
39 YRear lifting motor DOWN output
signalRear end lifting switch DOWN
operation (Motor operated)Battery voltage
Other than above 0
40 Y/R Battery power supply — Battery voltage
42 O/BSliding motor BACKWARD out-
put signalSliding switch BACKWARD oper-
ation (Motor operated)Battery voltage
Other than above 0
44 Y/RReclining motor BACKWARD
output signalReclining switch BACKWARD
operation (Motor operated)Battery voltage
Other than above 0
45 GRFront lifting motor UP output sig-
nalFront lifting switch UP operation
(Motor operated)Battery voltage
Other than above 0
48 B/W Ground — 0 TERMINALWIRE
COLORITEM CONDITIONVOLTAGE (V)
(Approx.)
TERMINAL WIRE
COLORITEM CONDITIONVOLTAGE (V)
(Approx.)
1 W/G ADP steering switch TILT UPADP steering switch in UP position 0
Other than above 5
2 LG Changeover switch RH signalChangeover switch in RH position 0
Other than above 5
3 Y/B Mirror switch UP signalMirror switch in UP position 0
Other than above 5
4 V/W Mirror switch LEFT signalMirror switch in LEFT position 0
Other than above 5
5R/BMirror sensor (RH vertical) sig-
nalMirror motor RH is operated UP or
DOWNChanges between 3.4 (close to
peak) 0.6 (close to valley)
6L/YMirror sensor (LH vertical) sig-
nalMirror motor LH is operated UP or
DOWNChanges between 3.4 (close to
peak) 0.6 (close to valley)
7 Y/R Tilt sensor inputTilt position TOP 2
Tilt position BOTTOM 4
Page 2998 of 3419

AUTOMATIC DRIVE POSITIONER
SE-33
C
D
E
F
G
H
J
K
L
MA
B
SE
Revision: October 20052005 QX56
8 BR/Y Pedal sensor input signalPedal position front end 0.5
Pedal position rear end 4.5
9 LG/B Seat memory switch 1 signalMemory switch 1 ON 0
Memory switch 1 OFF 5
10 L UART LINE (TX)Pedal adjusting switch ON (FOR-
WARD or BACKWARD operation)
12 PSeat memory switch indictor 1
signalMemory switch 1 ON 0
Memory switch 1 OFF Battery voltage
13 Y/GSeat memory switch indictor 2
signalMemory switch 2 ON 0
Memory switch 2 OFF Battery voltage
14 GR/R Mirror motor RH UP signalMirror motor RH is operated UP 1.5 - Battery voltage
Other than above 0
15 V/R Mirror motor RH LEFT signalMirror motor RH is operated LEFT 1.5 - Battery voltage
Other than above 0
16 OMirror motor LH DOWN signalMirror motor LH is operated DOWN 1.5 - Battery voltage
Other than above 0
Mirror motor LH RIGHT signalMirror motor LH is operated RIGHT 1.5 - Battery voltage
Other than above 0
17 G/BADP steering switch TILT
DOWNADP steering switch in DOWN posi-
tion0
Other than above 5
18 BR/W Changeover switch LH signalChangeover switch in LH position 0
Other than above 5
19 SB Mirror switch DOWN signalMirror switch in DOWN position 0
Other than above 5
20 GR Mirror switch RIGHT signalMirror switch in RIGHT position 0
Other than above 5
21 L/WMirror sensor (RH horizontal)
signalMirror motor RH is operated LEFT
or RIGHTChanges between 3.4 (close to left
edge) 0.6 (close to right edge)
22 GMirror sensor (LH horizontal)
signalMirror motor LH is operated LEFT
or RIGHTChanges between 3.4 (close to left
edge) 0.6 (close to right edge)
24 G/O Seat memory set switch signalSet switch 1 ON 0
Set switch 1 OFF 5
25 P/L Seat memory switch 2 signalMemory switch 2 ON 0
Memory switch 2 OFF 5
26 W UART LINE (RX)Pedal adjusting switch ON (FOR-
WARD or BACKWARD operation) TERMINAL WIRE
COLORITEM CONDITIONVOLTAGE (V)
(Approx.)
PIIA4813E
PIIA4814E
Page 2999 of 3419

SE-34
AUTOMATIC DRIVE POSITIONER
Revision: October 20052005 QX56
Work Flow EIS004XM
