Page 3289 of 3419

INFINITI QX4 2005 Factory Service Manual TF-146 TRANSFER ASSEMBLY Revision: October 20052005 QX56 DISASSEMBLY Rear Case 1. Remove the rear case bolts. 2. Remove the rear case from the center case. 3. Remove the dust cover, using suitable too

Page 3290 of 3419

INFINITI QX4 2005 Factory Service Manual TRANSFER ASSEMBLY TF-147 C E F G H I J K L MA B TF Revision: October 20052005 QX56 Front Case 1. Remove the rear case assembly. Refer to TF-146, "Rear Case" . 2. Remove the transfer control device. Re

Page 3291 of 3419

INFINITI QX4 2005 Factory Service Manual TF-148 TRANSFER ASSEMBLY Revision: October 20052005 QX56 10. Put a matching mark on top of the front drive shaft thread in line with the mark on the companion flange. CAUTION: Use paint to make the ma

Page 3292 of 3419

INFINITI QX4 2005 Factory Service Manual TRANSFER ASSEMBLY TF-149 C E F G H I J K L MA B TF Revision: October 20052005 QX56 17. Remove the 2-4 sleeve and L-H sleeve from the 2-4 fork and L- H fork respectively. 18. Drive out the retaining pi

Page 3293 of 3419

INFINITI QX4 2005 Factory Service Manual TF-150 TRANSFER ASSEMBLY Revision: October 20052005 QX56 22. Remove the sun gear assembly and planetary carrier assembly from the front case, using Tool. 23. Remove the snap ring and internal gear, us

Page 3294 of 3419

INFINITI QX4 2005 Factory Service Manual TRANSFER ASSEMBLY TF-151 C E F G H I J K L MA B TF Revision: October 20052005 QX56 27. Remove the snap ring from the planetary carrier assembly, using suitable tool. 28. Remove the sun gear assembly f

Page 3295 of 3419

INFINITI QX4 2005 Factory Service Manual TF-152 TRANSFER ASSEMBLY Revision: October 20052005 QX56 32. Remove the metal bushing from the sun gear, using Tools. Center Case 1. Remove the rear case assembly. Refer to TF-146, "Rear Case" . 2. Re

Page 3296 of 3419

INFINITI QX4 2005 Factory Service Manual TRANSFER ASSEMBLY TF-153 C E F G H I J K L MA B TF Revision: October 20052005 QX56 6. Remove the neutral-4LO and ATP switches. 7. Remove the bolts and main oil pump. 8. Remove the outer gear and inner
