HORN
WW-59
C
D
E
F
G
H
I
J
L
MA
B
WW
Revision: October 20052005 QX56
Removal and InstallationEKS00BEZ
REMOVAL
1. Remove the front grille. Refer to EI-17, "FRONT GRILLE" .
2. Disconnect horn connector.
3. Remove horn bolt and remove horn from vehicle.
INSTALLATION
1. Tighten horn bolt to specified torque.
2. Reconnect horn connector.
3. Install front grille. Refer to EI-17, "
FRONT GRILLE" .
LKIA0419E
Horn bolt : 17 N·m (1.7 kg-m, 13 ft-lb)
