Page 1321 of 3419

EC-130Revision: October 2005
TROUBLE DIAGNOSIS
2005 QX56
*: This function is not necessary in the usual service procedure.
SELF-DIAG RESULTS MODE
Self Diagnostic Item
Regarding items of “DTC and 1st trip DTC”, refer to EC-49, "EMISSION-RELATED DIAGNOSTIC INFORMA-
TION ITEMS" .
Freeze Frame Data and 1st Trip Freeze Frame Data
*: The item is the same as that of 1st trip freeze frame data.TARGET IDLE RPM ADJ*
IDLE CONDITION When setting target idle speed
TARGET IGN TIM ADJ*
IDLE CONDITION When adjusting target ignition tim-
ing WORK ITEM CONDITION USAGE
Freeze frame data
item*Description
DIAG TROUBLE
CODE
[PXXXX]
The engine control component part/control system has a trouble code, it is displayed as “PXXXX”. (Refer
to EC-8, "
INDEX FOR DTC" .)
FUEL SYS-B1
“Fuel injection system status” at the moment a malfunction is detected is displayed.
One mode in the following is displayed.
“Mode2”: Open loop due to detected system malfunction
“Mode3”: Open loop due to driving conditions (power enrichment, deceleration enleanment)
“Mode4”: Closed loop - using oxygen sensor(s) as feedback for fuel control
“Mode5”: Open loop - has not yet satisfied condition to go to closed loop FUEL SYS-B2
CAL/LD VALUE [%]
The calculated load value at the moment a malfunction is detected is displayed.
COOLANT TEMP
[°C] or [°F]
The engine coolant temperature at the moment a malfunction is detected is displayed.
L-FUEL TRM-B1 [%]
“Long-term fuel trim” at the moment a malfunction is detected is displayed.
The long-term fuel trim indicates much more gradual feedback compensation to the base fuel schedule
than short-term fuel trim. L-FUEL TRM-B2 [%]
S-FUEL TRM-B1 [%]
“Short-term fuel trim” at the moment a malfunction is detected is displayed.
The short-term fuel trim indicates dynamic or instantaneous feedback compensation to the base fuel
schedule. S-FUEL TRM-B2 [%]
ENGINE SPEED
[rpm]
The engine speed at the moment a malfunction is detected is displayed.
VEHICL SPEED
[km/h] or [mph]
The vehicle speed at the moment a malfunction is detected is displayed.
ABSOL TH-P/S
[%]
The throttle valve opening at the moment a malfunction is detected is displayed.
B/FUEL SCHDL
[msec]
The base fuel schedule at the moment a malfunction is detected is displayed.
INT/A TEMP SE
[°C] or [°F]
The intake air temperature at the moment a malfunction is detected is displayed.
Page 1322 of 3419
![INFINITI QX4 2005 Factory Service Manual TROUBLE DIAGNOSIS
EC-131
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: October 20052005 QX56
DATA MONITOR MODE
Monitored Item
×: Applicable
Monitored item
[Unit]ECM
INPUT
SIGNALSMAIN
SIGNALSDescription Rem INFINITI QX4 2005 Factory Service Manual TROUBLE DIAGNOSIS
EC-131
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: October 20052005 QX56
DATA MONITOR MODE
Monitored Item
×: Applicable
Monitored item
[Unit]ECM
INPUT
SIGNALSMAIN
SIGNALSDescription Rem](/manual-img/42/57035/w960_57035-1321.png)
TROUBLE DIAGNOSIS
EC-131
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: October 20052005 QX56
DATA MONITOR MODE
Monitored Item
×: Applicable
Monitored item
[Unit]ECM
INPUT
SIGNALSMAIN
SIGNALSDescription Remarks
ENG SPEED [rpm]××
Indicates the engine speed computed
from the signal of the crankshaft position
sensor (POS) and camshaft position
sensor (PHASE).Accuracy becomes poor if engine
speed drops below the idle rpm.
If the signal is interrupted while the
engine is running, an abnormal value
may be indicated.
MAS A/F SE-B1 [V]××
The signal voltage of the mass air flow
sensor is displayed.When the engine is stopped, a certain
value is indicated.
B/FUEL SCHDL
[msec]×
Base fuel schedule indicates the fuel
injection pulse width programmed into
ECM, prior to any learned on board cor-
rection.
A/F ALPHA-B1 [%]×
The mean value of the air-fuel ratio feed-
back correction factor per cycle is indi-
cated.When the engine is stopped, a certain
value is indicated.
This data also includes the data for the
air-fuel ratio learning control. A/F ALPHA-B2 [%]×
COOLAN TEMP/S
[°C] or [°F]××
The engine coolant temperature (deter-
mined by the signal voltage of the
engine coolant temperature sensor) is
displayed.When the engine coolant temperature
sensor is open or short-circuited, ECM
enters fail-safe mode. The engine
coolant temperature determined by the
ECM is displayed.
A/F SEN1 (B1) [V]××
The A/F signal computed from the input
signal of the A/F sensor 1 is displayed.
A/F SEN1 (B2) [V]×
HO2S2 (B1) [V]×
The signal voltage of the heated oxygen
sensor 2 is displayed.
HO2S2 (B2) [V]×
HO2S2 MNTR (B1)
[RICH/LEAN]×
Display of heated oxygen sensor 2 sig-
nal:
RICH: means the amount of oxygen
after three way catalyst is relatively
small.
LEAN: means the amount of oxygen
after three way catalyst is relatively
large.
When the engine is stopped, a certain
value is indicated.
HO2S2 MNTR (B2)
[RICH/LEAN]×
VHCL SPEED SE
[km/h] or [mph]××
The vehicle speed computed from the
vehicle speed signal sent from combina-
tion meter is displayed.
BATTERY VOLT [V]××
The power supply voltage of ECM is dis-
played.
ACCEL SEN 1 [V]××
The accelerator pedal position sensor
signal voltage is displayed.ACCEL SEN 2 signal is converted by
ECM internally. Thus, it differs from
ECM terminal voltage signal. ACCEL SEN 2 [V]×
THRTL SEN 1 [V]××
The throttle position sensor signal volt-
age is displayed.THRTL SEN 2 signal is converted by
ECM internally. Thus, it differs from
ECM terminal voltage signal. THRTL SEN 2 [V]×
FUEL T/TMP SE
[°C] or [°F]×
The fuel temperature (determined by the
signal voltage of the fuel tank tempera-
ture sensor) is displayed.
INT/A TEMP SE
[°C] or [°F]××
The intake air temperature (determined
by the signal voltage of the intake air
temperature sensor) is indicated.
EVAP SYS PRES
[V]×
The signal voltage of EVAP control sys-
tem pressure sensor is displayed.
Page 1323 of 3419
![INFINITI QX4 2005 Factory Service Manual EC-132Revision: October 2005
TROUBLE DIAGNOSIS
2005 QX56
FUEL LEVEL SE
[V]×The signal voltage of the fuel level sen-
sor is displayed.
START SIGNAL
[ON/OFF]××
Indicates start signal status [ON/ INFINITI QX4 2005 Factory Service Manual EC-132Revision: October 2005
TROUBLE DIAGNOSIS
2005 QX56
FUEL LEVEL SE
[V]×The signal voltage of the fuel level sen-
sor is displayed.
START SIGNAL
[ON/OFF]××
Indicates start signal status [ON/](/manual-img/42/57035/w960_57035-1322.png)
EC-132Revision: October 2005
TROUBLE DIAGNOSIS
2005 QX56
FUEL LEVEL SE
[V]×The signal voltage of the fuel level sen-
sor is displayed.
START SIGNAL
[ON/OFF]××
Indicates start signal status [ON/OFF]
computed by the ECM according to the
signals of engine speed and battery volt-
age.
After starting the engine, [OFF] is dis-
played regardless of the starter signal.
CLSD THL POS
[ON/OFF]××
Indicates idle position [ON/OFF] com-
puted by ECM according to the acceler-
ator pedal position sensor signal.
AIR COND SIG
[ON/OFF]××
Indicates [ON/OFF] condition of the air
conditioner switch as determined by the
air conditioner signal.
P/N POSI SW
[ON/OFF]××
Indicates [ON/OFF] condition from the
park/neutral position (PNP) switch sig-
nal.
PW/ST SIGNAL
[ON/OFF]××
[ON/OFF] condition of the power steer-
ing system (determined by the signal
voltage of the power steering pressure
sensor signal) is indicated.
LOAD SIGNAL
[ON/OFF]××
Indicates [ON/OFF] condition from the
electrical load signal.
ON: Rear window defogger switch is ON
and/or lighting switch is in 2nd position.
OFF: Both rear window defogger switch
and lighting switch are OFF.
IGNITION SW
[ON/OFF]×
Indicates [ON/OFF] condition from igni-
tion switch signal.
HEATER FAN SW
[ON/OFF]×
Indicates [ON/OFF] condition from
heater fan switch signal.
BRAKE SW
[ON/OFF]×
Indicates [ON/OFF] condition from the
stop lamp switch signal.
INJ PULSE-B1
[msec]×
Indicates the actual fuel injection pulse
width compensated by ECM according
to the input signals.When the engine is stopped, a certain
computed value is indicated.
INJ PULSE-B2
[msec]
IGN TIMING
[BTDC]×
Indicates the ignition timing computed
by ECM according to the input signals.When the engine is stopped, a certain
value is indicated.
CAL/LD VALUE [%]
“Calculated load value” indicates the
value of the current air flow divided by
peak air flow.
MASS AIRFLOW
[g·m/s]
Indicates the mass air flow computed by
ECM according to the signal voltage of
the mass air flow sensor.
PURG VOL C/V [%]
Indicates the EVAP canister purge vol-
ume control solenoid valve control value
computed by the ECM according to the
input signals.
The opening becomes larger as the
value increases.
AIR COND RLY
[ON/OFF]×
The air conditioner relay control condi-
tion (determined by ECM according to
the input signals) is indicated.
FUEL PUMP RLY
[ON/OFF]×
Indicates the fuel pump relay control
condition determined by ECM according
to the input signals. Monitored item
[Unit]ECM
INPUT
SIGNALSMAIN
SIGNALSDescription Remarks
Page 1324 of 3419
![INFINITI QX4 2005 Factory Service Manual TROUBLE DIAGNOSIS
EC-133
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: October 20052005 QX56VENT CONT/V
[ON/OFF]
The control condition of the EVAP canis-
ter vent control valve (determined by
ECM according t INFINITI QX4 2005 Factory Service Manual TROUBLE DIAGNOSIS
EC-133
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: October 20052005 QX56VENT CONT/V
[ON/OFF]
The control condition of the EVAP canis-
ter vent control valve (determined by
ECM according t](/manual-img/42/57035/w960_57035-1323.png)
TROUBLE DIAGNOSIS
EC-133
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: October 20052005 QX56VENT CONT/V
[ON/OFF]
The control condition of the EVAP canis-
ter vent control valve (determined by
ECM according to the input signals) is
indicated.
ON: Closed
OFF: Open
THRTL RELAY
[ON/OFF]×
Indicates the throttle control motor relay
control condition determined by the
ECM according to the input signals.
COOLING FAN
[HI/OFF]×
The control condition of the cooling fan
(determined by ECM according to the
input signals) is indicated.
HI: High speed operation
OFF: Stop
HO2S2 HTR (B1)
[ON/OFF]
Indicates [ON/OFF] condition of heated
oxygen sensor 2 heater determined by
ECM according to the input signals. HO2S2 HTR (B2)
[ON/OFF]
I/P PULLY SPD
[rpm]
Indicates the engine speed computed
from the turbine revolution sensor sig-
nal.
VEHICLE SPEED
[km/h] or [MPH]
Indicates the vehicle speed computed
from the revolution sensor signal.
IDL A/V LEARN
[YET/CMPLT]
Display the condition of idle air volume
learning
YET: Idle Air Volume Learning has not
been performed yet.
CMPLT: Idle Air Volume Learning has
already been performed successfully.
TRVL AFTER MIL
[km] or [mile]
Distance traveled while MIL is activated.
A/F S1 HTR (B1)
[%]
A/F sensor 1 heater control value com-
puted by ECM according to the input sig-
nals.
The current flow to the heater becomes
larger as the value increases. A/F S1 HTR (B2)
[%]
AC PRESS SEN [V]
The signal voltage from the refrigerant
pressure sensor is displayed.
VHCL SPEED SE
[km/h] or [mph]
The vehicle speed computed from the
vehicle speed signal sent from combina-
tion meter is displayed.
SET VHCL SPD*
1
[km/h] or [mph]The preset vehicle speed is displayed.
MAIN SW
[ON/OFF]
Indicates [ON/OFF] condition from MAIN
switch signal.
CANCEL SW
[ON/OFF]
Indicates [ON/OFF] condition from CAN-
CEL switch signal.
RESUME/ACC SW
[ON/OFF]
Indicates [ON/OFF] condition from
RESUME/ACCELERATE switch signal.
SET SW
[ON/OFF]
Indicates [ON/OFF] condition from SET/
COAST switch signal.
BRAKE SW1
[ON/OFF]
Indicates [ON/OFF] condition from
ASCD brake switch signal. Monitored item
[Unit]ECM
INPUT
SIGNALSMAIN
SIGNALSDescription Remarks
Page 1325 of 3419

EC-134Revision: October 2005
TROUBLE DIAGNOSIS
2005 QX56
*1: Models with ASCD
*2: Models with ICC
NOTE:
Any monitored item that does not match the vehicle being diagnosed is deleted from the display automatically.
DATA MONITOR (SPEC) MODE
Monitored Item
BRAKE SW2
[ON/OFF]Indicates [ON/OFF] condition of stop
lamp switch signal.
DIST SW*
2
[ON/OFF]
Indicates [ON/OFF] condition from DIS-
TANCE switch signal.
VHCL SPD CUT
[NON/CUT]
Indicates the vehicle cruise condition.
NON: Vehicle speed is maintained at the
ASCD set speed.
CUT: Vehicle speed increased to exces-
sively high compared with the ASCD set
speed, and ASCD operation is cut off.
LO SPEED CUT*
1
[NON/CUT]
Indicates the vehicle cruise condition.
NON: Vehicle speed is maintained at the
ASCD set speed.
CUT: Vehicle speed decreased to exces-
sively low compared with the ASCD set
speed, and ASCD operation is cut off.
AT O D M O N I T O R *
1
[ON/OFF]
Indicates [ON/OFF] condition of A/T O/D
according to the input signal from the
TCM.
AT OD CANCEL*
1
[ON/OFF]
Indicates [ON/OFF] condition of A/T O/D
cancel signal sent from the TCM.
CRUISE LAMP
[ON/OFF]
Indicates [ON/OFF] condition of
CRUISE lamp determined by the ECM
according to the input signals.
SET LAMP*
1
[ON/OFF]
Indicates [ON/OFF] condition of SET
lamp determined by the ECM according
to the input signals.
Voltage [V]
Voltage, frequency, duty cycle or pulse
width measured by the probe.
Only # is displayed if item is unable to
be measured.
Figures with #s are temporary ones.
They are the same figures as an actual
piece of data which was just previously
measured. Frequency [msec],
[Hz] or [%]
DUTY-HI
DUTY-LOW
PLS WIDTH-HI
PLS WIDTH-LOWMonitored item
[Unit]ECM
INPUT
SIGNALSMAIN
SIGNALSDescription Remarks
Monitored item
[Unit]ECM
INPUT
SIGNALSMAIN
SIGNALSDescription Remarks
ENG SPEED [rpm]××
Indicates the engine speed computed
from the signal of the crankshaft position
sensor (POS) and camshaft position
sensor (PHASE).
MAS A/F SE-B1 [V]××
The signal voltage of the mass air flow
sensor specification is displayed.When engine is running specification
range is indicated.
Page 1326 of 3419

TROUBLE DIAGNOSIS
EC-135
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: October 20052005 QX56
NOTE:
Any monitored item that does not match the vehicle being diagnosed is deleted from the display automatically.
ACTIVE TEST MODE
Test Item
B/FUEL SCHDL
[msec]×
Base fuel schedule indicates the fuel
injection pulse width programmed into
ECM, prior to any learned on board cor-
rection.
When engine is running specification
range is indicated.
A/F ALPHA-B1 [%]
A/F ALPHA-B2 [%]×
The mean value of the air-fuel ratio feed-
back correction factor per cycle is indi-
cated.When engine is running specification
range is indicated.
This data also includes the data for
the air-fuel ratio learning control. Monitored item
[Unit]ECM
INPUT
SIGNALSMAIN
SIGNALSDescription Remarks
TEST ITEM CONDITION JUDGEMENT CHECK ITEM (REMEDY)
FUEL INJEC-
TION
Engine: Return to the original
trouble condition
Change the amount of fuel injec-
tion using CONSULT-II.If trouble symptom disappears, see
CHECK ITEM.
Harness and connectors
Fuel injector
Air fuel ratio (A/F) sensor 1
IGNITION TIM-
ING
Engine: Return to the original
trouble condition
Timing light: Set
Retard the ignition timing using
CONSULT-II.If trouble symptom disappears, see
CHECK ITEM.
Perform Idle Air Volume Learning.
POWER BAL-
ANCE
Engine: After warming up, idle
the engine.
A/C switch: OFF
Selector lever: P or N
Cut off each injector signal one at
a time using CONSULT-II.Engine runs rough or dies.
Harness and connectors
Compression
Fuel injector
Power transistor
Spark plug
Ignition coil
COOLING FAN*
Ignition switch: ON
Turn the cooling fan HI and OFF
using CONSULT-II.Cooling fan moves and stops.
Harness and connectors
Cooling fan motor
IPDM E/R
ENG COOLANT
TEMP
Engine: Return to the original
trouble condition
Change the engine coolant tem-
perature using CONSULT-II.If trouble symptom disappears, see
CHECK ITEM.
Harness and connectors
Engine coolant temperature sen-
sor
Fuel injector
FUEL PUMP
RELAY
Ignition switch: ON
(Engine stopped)
Turn the fuel pump relay ON and
OFF using CONSULT-II and lis-
ten to operating sound.Fuel pump relay makes the operat-
ing sound.Harness and connectors
Fuel pump relay
PURG VOL
CONT/V
Engine: After warming up, run
engine at 1,500 rpm.
Change the EVAP canister purge
volume control solenoid valve
opening percent using CON-
SULT-II.Engine speed changes according to
the opening percent.Harness and connectors
Solenoid valve
Page 1327 of 3419

EC-136Revision: October 2005
TROUBLE DIAGNOSIS
2005 QX56
*: Leaving cooling fan OFF with CONSULT-II while engine is running may cause the engine to overheat.
DTC & SRT CONFIRMATION MODE
SRT STATUS Mode
For details, refer to EC-54, "SYSTEM READINESS TEST (SRT) CODE" .
SRT WORK SUPPORT Mode
This mode enables a technician to drive a vehicle to set the SRT while monitoring the SRT status.
DTC WORK SUPPORT Mode
*: DTC P1442 and P1456 does not apply to JA60 models but appears in DTC Work Support Mode screens.FUEL/T TEMP
SEN
Change the fuel tank temperature using CONSULT-II.
VENT CON-
TROL/V
Ignition switch: ON
(Engine stopped)
Turn solenoid valve ON and OFF
with the CONSULT-II and listen
to operating sound.Solenoid valve makes an operating
sound.Harness and connectors
Solenoid valve TEST ITEM CONDITION JUDGEMENT CHECK ITEM (REMEDY)
Test mode Test item Condition Reference page
EVAPORATIVE
SYSTEMPURG FLOW P0441
Refer to corresponding
trouble diagnosis for
DTC.EC-304
EVP SML LEAK P0442/P1442*EC-309
EVP V/S LEAK P0456/P1456*EC-357
PURG VOL CN/V P1444EC-531
A/F SEN1A/F SEN1 (B1) P1276EC-497A/F SEN1 (B2) P1286EC-497
A/F SEN1 (B1) P1278/P1279EC-507, EC-519
A/F SEN1 (B2) P1288/P1289EC-507, EC-519
HO2S2HO2S2 (B1) P0139EC-225
HO2S2 (B1) P1146EC-415
HO2S2 (B1) P1147EC-426
HO2S2 (B2) P0159EC-225
HO2S2 (B2) P1166EC-415
HO2S2 (B2) P1167EC-426
Page 1328 of 3419

TROUBLE DIAGNOSIS
EC-137
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: October 20052005 QX56
REAL TIME DIAGNOSIS IN DATA MONITOR MODE (RECORDING VEHICLE DATA)
Description
CONSULT-II has two kinds of triggers and they can be selected by touching “SETTING” in “DATA MONITOR”
mode.
1. “AUTO TRIG” (Automatic trigger):
The malfunction will be identified on the CONSULT-II screen
in real time.
In other words, DTC/1st trip DTC and malfunction item will be
displayed if the malfunction is detected by ECM.
At the moment a malfunction is detected by ECM, “MONI-
TOR” in “DATA MONITOR” screen is changed to “Recording
Data ... xx%” as shown in the figure, and the data after the
malfunction detection is recorded. Then when the percentage
reached 100%, “REAL-TIME DIAG” screen is displayed. If
“STOP” is touched on the screen during “Recording Data ...
xx%”, “REAL-TIME DIAG” screen is also displayed.
The recording time after the malfunction detection and the
recording speed can be changed by “TRIGGER POINT” and
“Recording Speed”. Refer to CONSULT-II Operation Manual.
2. “MANU TRIG” (Manual trigger):
DTC/1st trip DTC and malfunction item will not be displayed
automatically on CONSULT-II screen even though a malfunc-
tion is detected by ECM.
DATA MONITOR can be performed continuously even though
a malfunction is detected.
SEF 7 05 Y
SEF 7 07 X
