2005 INFINITI QX4 Factory Service Manual

check engine light pairing phone ad blue oil filter air suspension radio antenna

Page 1145 of 3419

INFINITI QX4 2005 Factory Service Manual DI-42
WARNING CHIME
Revision: October 20052005 QX56
WARNING CHIMEPFP:24814
Component Parts and Harness Connector LocationEKS00BCO
System DescriptionEKS00BCP
FUNCTION
Power is supplied at all times
th

Page 1146 of 3419

INFINITI QX4 2005 Factory Service Manual WARNING CHIME
DI-43
C
D
E
F
G
H
I
J
L
MA
B
DI
Revision: October 20052005 QX56
3. Seat belt warning chime
IGNITION KEY WARNING CHIME
With the key inserted in the ignition switch, the ignition switch in

WARNING CHIME
DI-43
C
D
E
F
G
H
I
J
L
MA
B
DI
Revision: October 20052005 QX56
3. Seat belt warning chime
IGNITION KEY WARNING CHIME
With the key inserted in the ignition switch, the ignition switch in OFF position, and the driver's door open, the
warning chime will sound.
Power is supplied
through key switch and key lock solenoid terminal 4
to BCM terminal 37.
Ground is supplied
to BCM terminal 47
through front door switch LH terminal 2.
Front door switch LH is case grounded.
BCM detects key inserted into the ignition switch, and sends key warning signal to combination meter via CAN
communication lines. When the combination meter receives key warning signal, it sounds warning chime.
LIGHT WARNING CHIME
With the key removed from the ignition switch, the driver's door open, and the lighting switch (part of the com-
bination switch) in 1st or 2nd position, the warning chime will sound. [Except when headlamp battery saver
control operates (5 minutes after ignition switch is turned to OFF or ACC position) and headlamps do not illu-
minate.]
Signal is supplied
from combination switch (lighting switch) terminals 1, 2, 3, 4, 5, 6, 7, 8, 9 and 10
to BCM terminals 2, 3, 4, 5, 6, 32, 33, 34, 35 and 36.
NOTE:
BCM detected lighting switch in 1st or 2nd position. Refer to BCS-3, "
COMBINATION SWITCH READING
FUNCTION" .
Ground is supplied
to BCM terminal 47
through front door switch LH terminal 2.
Front door switch LH is case grounded.
BCM detects headlamps are illuminated, and sends light warning signal to combination meter CAN communi-
cation lines. When the combination meter receives light warning signal, it sounds warning chime.
SEAT BELT WARNING CHIME
When the ignition switch is turned ON with the seat belt unfastened [seat belt buckle pre-tensioner assembly
(seat belt buckle switch) LH unfastened], warning chime will sound for approximately 6 seconds.
Ground is supplied
to combination meter terminal 27
through seat belt buckle pre-tensioner assembly (seat belt buckle switch) LH terminal 1.
Seat belt buckle pre-tensioner assembly (seat belt buckle switch) LH terminal 2 is grounded through body
grounds B7 and B19.
The combination meter sends seat belt buckle switch LH unfastened signal to BCM via CAN communication
line.
BCM receives seat belt buckle pre-tensioner assembly (seat belt buckle switch) LH unfastened signal from
combination meter via CAN communication line, and sends seat belt warning signal to the combination meter
via CAN communication line. When the combination meter receives the seat belt warning signal, it sounds the
warning chime. The BCM controls the (6 second) duration of the seat belt warning chime.
CAN Communication System DescriptionEKS00BCQ
Refer to LAN-5, "CAN COMMUNICATION" .

Page 1147 of 3419

INFINITI QX4 2005 Factory Service Manual DI-44
WARNING CHIME
Revision: October 20052005 QX56
Wiring Diagram — CHIME —EKS00BCR
WKWA2372E

Page 1148 of 3419

INFINITI QX4 2005 Factory Service Manual WARNING CHIME
DI-45
C
D
E
F
G
H
I
J
L
MA
B
DI
Revision: October 20052005 QX56
WKWA1175E

Page 1149 of 3419

INFINITI QX4 2005 Factory Service Manual DI-46
WARNING CHIME
Revision: October 20052005 QX56
Terminals and Reference Value for BCMEKS00BCS
Terminal
No.Wire
colorItem Condition
Reference value (V)
(Approx.) Ignition
switchMeasurement metho

Page 1150 of 3419

INFINITI QX4 2005 Factory Service Manual WARNING CHIME
DI-47
C
D
E
F
G
H
I
J
L
MA
B
DI
Revision: October 20052005 QX56
Terminals and Reference Value for Combination MeterEKS00BCT
How to Proceed With Trouble DiagnosisEKS00BCU
1. Confirm the s

Page 1151 of 3419

INFINITI QX4 2005 Factory Service Manual DI-48
WARNING CHIME
Revision: October 20052005 QX56
2. CHECK POWER SUPPLY CIRCUIT
1. Disconnect BCM connectors M18 and M20.
2. Check voltage between BCM harness connector terminals and
ground.
OK or N

Page 1152 of 3419

INFINITI QX4 2005 Factory Service Manual WARNING CHIME
DI-49
C
D
E
F
G
H
I
J
L
MA
B
DI
Revision: October 20052005 QX56
CONSULT-II Function (BCM)EKS00BCW
CONSULT-II can display each diagnostic item using the diagnostic test modes shown follow
