Page 929 of 3419

INFINITI QX4 2005 Factory Service Manual BL-162 BODY REPAIR Revision: October 20052005 QX56 1. Hoodledge assembly (RH, LH) 2. Hoodledge reinforcement (RH, LH) 3. Body mounting bracket (RH, LH) 4. Hoodledge front brace (RH), Battery mounting

Page 930 of 3419

INFINITI QX4 2005 Factory Service Manual BODY REPAIR BL-163 C D E F G H J K L MA B BL Revision: October 20052005 QX56 BODY COMPONENT PARTS LIIA1438E

Page 931 of 3419

INFINITI QX4 2005 Factory Service Manual BL-164 BODY REPAIR Revision: October 20052005 QX56 1. Front fender (RH, LH) 2. Hood assembly 3. Rear hoodledge reinforcement (RH, LH) 4. Outer sill reinforcement (RH, LH) 5. Front pillar hinge brace (

Page 932 of 3419

INFINITI QX4 2005 Factory Service Manual BODY REPAIR BL-165 C D E F G H J K L MA B BL Revision: October 20052005 QX56 Corrosion ProtectionEIS008SH DESCRIPTION To provide improved corrosion prevention, the following anti-corrosive measures ha

Page 933 of 3419

INFINITI QX4 2005 Factory Service Manual BL-166 BODY REPAIR Revision: October 20052005 QX56 ANTI-CORROSIVE WAX To improve corrosion resistance, anti-corrosive wax is applied inside the body sill and inside other closed sec- tions. Accordingl

Page 934 of 3419

INFINITI QX4 2005 Factory Service Manual BODY REPAIR BL-167 C D E F G H J K L MA B BL Revision: October 20052005 QX56 UNDERCOATING The underside of the floor and wheelhouse are undercoated to prevent rust, vibration, noise and stone chip- pi

Page 935 of 3419

INFINITI QX4 2005 Factory Service Manual BL-168 BODY REPAIR Revision: October 20052005 QX56 Body SealingEIS008SI DESCRIPTION The following figure shows the areas which are sealed at the factory. Sealant which has been applied to these areas

Page 936 of 3419

INFINITI QX4 2005 Factory Service Manual BODY REPAIR BL-169 C D E F G H J K L MA B BL Revision: October 20052005 QX56 WIIA0278E
