INFINITI QX4 2005 Factory Service Manual EC-26Revision: October 2005
ENGINE CONTROL SYSTEM
2005 QX56
FUEL INJECTION TIMING
Two types of systems are used.
Sequential Multiport Fuel Injection System
Fuel is injected into each cylinder during e

EC-26Revision: October 2005
ENGINE CONTROL SYSTEM
2005 QX56
FUEL INJECTION TIMING
Two types of systems are used.
Sequential Multiport Fuel Injection System
Fuel is injected into each cylinder during each engine cycle according to the firing order. This system is used
when the engine is running.
Simultaneous Multiport Fuel Injection System
Fuel is injected simultaneously into all eight cylinders twice each engine cycle. In other words, pulse signals of
the same width are simultaneously transmitted from the ECM.
The eight injectors will then receive the signals two times for each engine cycle.
This system is used when the engine is being started and/or if the fail-safe system (CPU) is operating.
FUEL SHUT-OFF
Fuel to each cylinder is cut off during deceleration, operation of the engine at excessively high speeds or oper-
ation of the vehicle at excessively high speed.
Electronic Ignition (EI) SystemUBS00KZ8
INPUT/OUTPUT SIGNAL CHART
*1: This signal is sent to the ECM through CAN communication line.
*2: ECM determines the start signal status by the signals of engine speed and battery voltage.
SYSTEM DESCRIPTION
Firing order: 1 - 8 - 7 - 3 - 6 - 5 - 4 -2
The ignition timing is controlled by the ECM to maintain the best air-fuel ratio for every running condition of the
engine. The ignition timing data is stored in the ECM.
The ECM receives information such as the injection pulse width and camshaft position sensor signal. Comput-
ing this information, ignition signals are transmitted to the power transistor.
During the following conditions, the ignition timing is revised by the ECM according to the other data stored in
the ECM.
At starting
During warm-up
At idle
At low battery voltage
PBIB0122E
Sensor Input signal to ECM ECM function Actuator
Crankshaft position sensor (POS)
Engine speed*
2
Piston position
Ignition timing
controlPower transistor Camshaft position sensor (PHASE)
Mass air flow sensor Amount of intake air
Engine coolant temperature sensor Engine coolant temperature
Throttle position sensor Throttle position
Accelerator pedal position sensor Accelerator pedal position
Knock sensor Engine knocking
Park/neutral position (PNP) switch Gear position
Battery
Battery voltage*
2
Wheel sensor*1Vehicle speed

Page 1218 of 3419

INFINITI QX4 2005 Factory Service Manual ENGINE CONTROL SYSTEM
EC-27
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: October 20052005 QX56
During acceleration
The knock sensor retard system is designed only for emergencies. The basic ignition timing is

Page 1219 of 3419

INFINITI QX4 2005 Factory Service Manual EC-28Revision: October 2005
AIR CONDITIONING CUT CONTROL
2005 QX56
AIR CONDITIONING CUT CONTROLPFP:23710
Input/Output Signal ChartUBS00KZA
*1: This signal is sent to the ECM through CAN communication

Page 1220 of 3419

INFINITI QX4 2005 Factory Service Manual AUTOMATIC SPEED CONTROL DEVICE (ASCD)
EC-29
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: October 20052005 QX56
AUTOMATIC SPEED CONTROL DEVICE (ASCD)PFP:18930
System DescriptionUBS00KZC
INPUT/OUTPUT SIGNAL CHAR

AUTOMATIC SPEED CONTROL DEVICE (ASCD)
EC-29
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: October 20052005 QX56
AUTOMATIC SPEED CONTROL DEVICE (ASCD)PFP:18930
System DescriptionUBS00KZC
INPUT/OUTPUT SIGNAL CHART
*: This signal is sent to the ECM through CAN communication line
BASIC ASCD SYSTEM
Refer to Owner's Manual for ASCD operating instructions.
Automatic Speed Control Device (ASCD) allows a driver to keep vehicle at predetermined constant speed
without depressing accelerator pedal. Driver can set vehicle speed in advance between approximately 40 km/
h (25 MPH) and 144 km/h (89 MPH).
ECM controls throttle angle of electric throttle control actuator to regulate engine speed.
Operation status of ASCD is indicated by CRUISE indicator and SET indicator in combination meter. If any
malfunction occurs in ASCD system, it automatically deactivates control.
NOTE:
Always drive vehicle in safe manner according to traffic conditions and obey all traffic laws.
SET OPERATION
Press MAIN switch. (The CRUISE indicator in combination meter illuminates.)
When vehicle speed reaches a desired speed between approximately 40 km/h (25 MPH) and 144 km/h (89
MPH), press SET/COAST switch. (Then SET indicator in combination meter illuminates.)
ACCEL OPERATION
If the RESUME/ACCELERATE switch is pressed during cruise control driving, increase the vehicle speed until
the switch is released or vehicle speed reaches maximum speed controlled by the system.
And then ASCD will keep the new set speed.
CANCEL OPERATION
When any of following conditions exist, cruise operation will be canceled.
CANCEL switch is pressed
More than 2 switches at ASCD steering switch are pressed at the same time (Set speed will be cleared)
Brake pedal is depressed
Selector lever is changed to N, P, R position
Vehicle speed decreased to 13 km/h (8 MPH) lower than the set speed
VDC system is operated
When the ECM detects any of the following conditions, the ECM will cancel the cruise operation and inform
the driver by blinking indicator lamp.
Engine coolant temperature is slightly higher than the normal operating temperature, CRUISE lamp may
blink slowly.
When the engine coolant temperature decreases to the normal operating temperature, CRUISE lamp will
stop blinking and the cruise operation will be able to work by pressing SET/COAST switch or RESUME/
ACCELERATE switch.
Malfunction for some self-diagnoses regarding ASCD control: SET lamp will blink quickly.
If MAIN switch is turned to OFF during ASCD is activated, all of ASCD operations will be canceled and vehicle
speed memory will be erased.
Sensor Input signal to ECM ECM function Actuator
ASCD brake switch Brake pedal operation
ASCD vehicle speed controlElectric throttle control
actuator Stop lamp switch Brake pedal operation
ASCD steering switch ASCD steering switch operation
Park/Neutral position (PNP)
switchGear position
Wheel sensor* Vehicle speed
TCM* Powertrain revolution

Page 1221 of 3419

INFINITI QX4 2005 Factory Service Manual EC-30Revision: October 2005
AUTOMATIC SPEED CONTROL DEVICE (ASCD)
2005 QX56
COAST OPERATION
When the SET/COAST switch is pressed during cruise control driving, decrease vehicle set speed until the
swi

Page 1222 of 3419

INFINITI QX4 2005 Factory Service Manual CAN COMMUNICATION
EC-31
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: October 20052005 QX56
CAN COMMUNICATIONPFP:23710
System DescriptionUBS00KZE
CAN (Controller Area Network) is a serial communication line for

Page 1223 of 3419

INFINITI QX4 2005 Factory Service Manual EC-32Revision: October 2005
EVAPORATIVE EMISSION SYSTEM
2005 QX56
EVAPORATIVE EMISSION SYSTEMPFP:14950
DescriptionUBS00KZF
SYSTEM DESCRIPTION
The evaporative emission system is used to reduce hydrocar

Page 1224 of 3419

INFINITI QX4 2005 Factory Service Manual EVAPORATIVE EMISSION SYSTEM
EC-33
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: October 20052005 QX56
EVAPORATIVE EMISSION LINE DRAWING
PBIB2053E
