Page 649 of 3419
AV-60
DVD ENTERTAINMENT SYSTEM
Revision: October 20052005 QX56
Removal and Installation of DVD PlayerEKS00BJB
1. Remove center console compartment. Refer to IP-15, "Center Console" .
2. Remove the screws and DVD player.
3. Installation is in reverse order of removal.
Removal and Installation of Video MonitorEKS00BJC
1. Remove rear roof console assembly. Refer to EI-38, "HEADLINING" .
2. Disconnect the video monitor connector.
3. Remove the video housing screws.
4. Remove the video monitor and housing.
5. Remove the video monitor hinge screws and remove the video
monitor.
6. Installation is in reverse order of removal.
WKIA1503E
WKIA1502E
WKIA1219E
Page 650 of 3419

NAVIGATION SYSTEM
AV-61
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: October 20052005 QX56
NAVIGATION SYSTEMPFP:25915
System DescriptionEKS00BJD
The navigation system periodically calculates the vehicle's current
position according to the following three signals: Travel distance of
the vehicle as determined by the vehicle speed sensor, turning angle
of the vehicle as determined by the gyroscope (angular velocity sen-
sor), and the direction of vehicle travel as determined by the GPS
antenna (GPS information).
The current position of the vehicle is then identified by comparing the
calculated vehicle position with map data read from the map DVD-
ROM, which is stored in the DVD-ROM drive (map-matching), and
indicated on the screen with a current-location mark.
By comparing the vehicle position detection results found by the
GPS and by map-matching, more accurate vehicle position data can
be used.
The current vehicle position will be calculated by detecting the dis-
tance the vehicle moved from the previous calculation point and its
direction.
TRAVEL DISTANCE
Travel distance calculations are based on the vehicle speed sensor input signal. Therefore, the calculation
may become incorrect as the tires wear down. To prevent this, an automatic distance fine adjustment function
has been adopted. Adjustments can be made in extreme cases (such as driving with tire chain fitted on tires).
Refer to AV-107, "
Confirmation/Adjustment Mode" .
TRAVEL DIRECTION
Change in the travel direction of the vehicle is calculated by a gyroscope (angular velocity sensor) and a GPS
antenna (GPS information). As the gyroscope and GPS antenna have both merit and demerit, input signals
from them are prioritized in each situation. However, this order of priority may change in accordance with more
detailed travel conditions so that the travel direction is detected more accurately.
MAP-MATCHING
Map-matching is a function that repositions the vehicle on the road
map when a new location is judged to be the most accurate. This is
done by comparing the current vehicle position, calculated by the
method described in the position detection principle, with the road
map data around the vehicle, read from the map DVD-ROM stored in
the DVD-ROM drive.
Therefore, the vehicle position may not be corrected after the vehicle
is driven over a certain distance or time in which GPS information is
hard to receive. In this case, the current-location mark on the display
must be corrected manually.
CAUTION:
The road map data is based on data stored in the map DVD-
ROM.
WKIA1371E
SEL684V
Type Advantage Disadvantage
Gyroscope (angular velocity sensor)
Can detect the vehicle's turning angle
quite accurately.Direction errors may accumulate when the
vehicle is driven for long distances without
stopping.
GPS antenna (GPS information)
Can detect the vehicle's travel direction
(North/South/East/West).Correct direction cannot be detected when
the vehicle speed is low.
SEL685V
Page 651 of 3419

AV-62
NAVIGATION SYSTEM
Revision: October 20052005 QX56
In map-matching, alternative routes to reach the destination will
be shown and prioritized, after the road on which the vehicle is
currently driven has been judged and the current-location mark
has been repositioned.
If there is an error in distance and/or direction, the alternative
routes will be shown in different order of priority, and the wrong
road can be avoided.
If two roads are running in parallel, they are of the same priority.
Therefore, the current-location mark may appear on either of
them alternately, depending on maneuvering of the steering
wheel and configuration of the road.
Map-matching does not function correctly when the road on
which the vehicle is driving is new and not recorded in the map
DVD-ROM, or when the road pattern stored in the map data and
the actual road pattern are different due to repair.
When driving on a road not present in the map, the map-match-
ing function may find another road and position the current-loca-
tion mark on it. Then, when the correct road is detected, the
current-location mark may leap to it.
Effective range for comparing the vehicle position and travel
direction calculated by the distance and direction with the road
data read from the map DVD-ROM is limited. Therefore, when
there is an excessive gap between the current vehicle position
and the position on the map, correction by map-matching is not possible.
GPS (GLOBAL POSITIONING SYSTEM)
GPS (Global Positioning System) has been developed and con-
trolled by the US Department of Defense. The system utilizes GPS
satellite (NAVSTAR), sending out radio waves while flying on an orbit
around the earth at the height of approx. 21,000 km (13,000 miles).
The GPS receiver calculates the vehicle's position in three dimen-
sions (latitude/longitude/altitude) according to the time lag of the
radio waves received from four or more GPS satellites (three-dimen-
sional positioning). If radio waves were received only from three
GPS satellites, the GPS receiver calculates the vehicle's position in
two dimensions (latitude/longitude), utilizing the altitude data calcu-
lated previously by using radio waves from four or more GPS satel-
lites (two-dimensional positioning).
Accuracy of the GPS will deteriorate under the following conditions.
In two-dimensional positioning, the GPS accuracy will deteriorate when the altitude of the vehicle position
changes.
There may be an error of approximately 10 m (30 ft) in position detected by three-dimensional positioning,
which is more accurate than two-dimensional positioning. The accuracy can be even lower depending on
the arrangement of the GPS satellites utilized for the positioning.
Position detection is not possible when the vehicle is in an area where radio waves from the GPS satellite
do not reach, such as in a tunnel, parking lot in a building, and under an elevated highway. Radio waves
from the GPS satellites may not be received when some object is located over the GPS antenna.
Position correction by GPS is not available while the vehicle is stopped.
SEL686V
SKIA0613E
SEL526V
Page 652 of 3419

NAVIGATION SYSTEM
AV-63
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: October 20052005 QX56
COMPONENT DESCRIPTION
NAVI Control Unit
The gyro (angular speed sensor) and the DVD-ROM drive are
built-in units that control the navigation functions.
Signals are received from the gyro, the vehicle speed sensor,
and the GPS antenna. Vehicle location is determined by com-
bining this data with the data contained in the DVD-ROM map.
Location information is shown on liquid crystal display (display
unit).
DVD-ROM Drive
Maps, traffic control regulations, and other pertinent information can
be easily read from the DVD-ROM disc.
Map DVD-ROM
The map DVD-ROM has maps, traffic control regulations, and other pertinent information.
To improve DVD-ROM map matching and route determination functions, the DVD-ROM uses an exclusive
Nissan format. Therefore, the use of a DVD-ROM provided by other manufacturers cannot be used.
Gyro (Angular Speed Sensor)
The oscillator gyro sensor is used to detect changes in vehicle steering angle.
The gyro is built into the navigation (NAVI) control unit.
BIRDVIEW™
The BIRDVIEW™ provides a detailed and easily seen display of road conditions covering the vehicle's imme-
diate to distant area.
PLAN VIEW
PKIA0248E
PKIA0249E
WKIA1948E
Page 653 of 3419
AV-64
NAVIGATION SYSTEM
Revision: October 20052005 QX56
BIRDVIEW™
Description
Display area: Trapezoidal representation showing approximate
distances (Wn, D, and Wd).
Ten horizontal grid lines indicate display width while six vertical
grid lines indicate display depth and direction.
Pushing the “ZOOM IN” button during operation displays the
scale change and the view point height on the left side of the
screen.
The height of the view point increases or decreases when
“ZOOM” or “WIDE” is selected with the joystick.
MAP DISPLAY
Function of each icon is as follows:
1. Azimuth indication.
2. Position marker.
–The tip of the arrow shows the current location. The shaft of the
arrow indicates the direction in which the vehicle is traveling.
3. GPS reception signal (indicates current reception conditions).
4. Distance display (shows the distance in a reduced scale).
WKIA1949E
SKIA5613E
WKIA1950E
Page 654 of 3419
NAVIGATION SYSTEM
AV-65
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: October 20052005 QX56
FUNCTION OF CENTER SWITCH
Display with Pushed “DEST” button
Easy Mode ("Short Menus" ON)
Expert Mode ("Short Menus" OFF)
The function of each icon is as follows:
WKIA3137E
WKIA3138E
IconMode
Description
Easy Expert
Address Book×Favorite place can be saved to memory.
Street Address××The destination can be searched from the address.
Point of Interest (POI)××The destination of favorite facility can be searched.
Previous Dest.×The previous ten destinations stored in memory are displayed.
Intersection×The destination can be searched from the intersection.
City×The destination can be searched from city name.
Map×The destination can be searched from the map.
Phone Number×The destination can be set by entering the phone number.
Home×Sets the home as a destination.
Help×Explanation of navigational functions appear on the display.
Country××Select country (USA, CANADA)
Page 655 of 3419

AV-66
NAVIGATION SYSTEM
Revision: October 20052005 QX56
Display with Pushed “ROUTE” button
Easy Mode ("Short Menus" ON)
Expert Mode ("Short Menus" OFF)
The function of each icon is as follows:
*: When in Easy Mode, “Route Info.” and “Edit Route” are not displayed.
SKIA4494E
SKIA4495E
IconMode
Description
Easy Expert
Quick Stop××The selected facility is set as the destination or way point.
(Route guidance has been turned OFF or the destination has been reached.)
Where am I?××Next, current and previous street names can be displayed.
Cancel Guidance××The following items can be selected.
All Destinations
Way point
Not Cancel
(Displayed only when the destination area has been set.)
Route Info.*×The following items can be selected.
Complete Route
Tu rn L ist
Route Simulation
(Displayed only when the destination area has been set.)
Edit Route*×Change the destination or add the transit points of the route set in the route guide. (Dis-
played only when the automatic reroute function has been turned OFF and the recom-
mended route is not followed.)
Help×Explanation of navigational functions appear on the display.
Page 656 of 3419

NAVIGATION SYSTEM
AV-67
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: October 20052005 QX56
Display with Pushed “SETTING” button
The function of each icon is as follows:
Display Settings
How To Perform Display Setting
1. Start the engine.
2. Push “SETTING” button.
3. Select “Display” with "ENTER" button.
Application Items
Brightness/Contrast/Map Back ground
How To Perform Navigation Setting
1. Select “Brightness/Contrast/Map Background”.
Brightness, Contrast and Background are shown at the lower part of the screen, and it can be set with the
joystick.
Display Off
How To Perform Navigation Setting
1. Select “Display Off”.
When setting is turned on (Indicator light ON), the display will be under sleep mode.
SKIA4496E
Icon Description
Display Settings of display can be performed.
Vehicle Electronic Systems Settings of vehicle electrical equipment can be performed.
System Settings Settings of linguistic select, time adjusting and beep sound can be performed.
Navigation Settings and adjusting of navigation can be performed.
Short Menus Easy Mode and Expert Mode can be switched.
Guidance Volume The volume and/or on/off of voice prompt can be controlled by the joystick.
Help (only easy mode) Explanation of navigational functions appear on the display.
SKIA5791E
Icon DescriptionReference
page
Brightness/Contrast/Map Background Brightness, Contrast and Map Background can be set.AV- 6 7
Display Off Display sleep mode ON/OFF can be switched.AV- 6 7
Setting of the under section display The setting status of A/C or AV can be shown. AV- 6 8
