Page 849 of 3419

INFINITI QX4 2005 Factory Service Manual BL-82
VEHICLE SECURITY (THEFT WARNING) SYSTEM
Revision: October 20052005 QX56
WIWA1229E

Page 850 of 3419

INFINITI QX4 2005 Factory Service Manual VEHICLE SECURITY (THEFT WARNING) SYSTEM
BL-83
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: October 20052005 QX56
WIWA0752E

Page 851 of 3419

INFINITI QX4 2005 Factory Service Manual BL-84
VEHICLE SECURITY (THEFT WARNING) SYSTEM
Revision: October 20052005 QX56
WIWA1312E

Page 852 of 3419

INFINITI QX4 2005 Factory Service Manual VEHICLE SECURITY (THEFT WARNING) SYSTEM
BL-85
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: October 20052005 QX56
Terminals and Reference Value for BCMEIS008QQ
Te r m i n a l Wire
ColorItem ConditionVoltage (

Page 853 of 3419

INFINITI QX4 2005 Factory Service Manual BL-86
VEHICLE SECURITY (THEFT WARNING) SYSTEM
Revision: October 20052005 QX56
Terminals and Reference Value for IPDM E/REIS008QR
1*: when horn reminder is ON.
2*: L/W is for USA.
3*: Y is for Canada.

Page 854 of 3419

INFINITI QX4 2005 Factory Service Manual VEHICLE SECURITY (THEFT WARNING) SYSTEM
BL-87
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: October 20052005 QX56
1. Turn ignition switch OFF.
2. Connect CONSULT-II and CONSULT-II CONVERTER to the
data link con

Page 855 of 3419

INFINITI QX4 2005 Factory Service Manual BL-88
VEHICLE SECURITY (THEFT WARNING) SYSTEM
Revision: October 20052005 QX56
CONSULT-II APPLICATION ITEM
Data Monitor
Active Test
Work Support
Monitored Item Description
DOOR SW-AS Indicates [ON/OFF]

BL-88
VEHICLE SECURITY (THEFT WARNING) SYSTEM
Revision: October 20052005 QX56
CONSULT-II APPLICATION ITEM
Data Monitor
Active Test
Work Support
Monitored Item Description
DOOR SW-AS Indicates [ON/OFF] condition of front door switch RH.
DOOR SW-RR Indicates [ON/OFF] condition of rear door switch RH.
DOOR SW-RL Indicates [ON/OFF] condition of rear door switch LH.
DOOR SW-DR Indicates [ON/OFF] condition of front door switch LH.
BACK DOOR SW Indicates [ON/OFF] condition of back door latch.
TRNK OPN MNTR Indicates [ON/OFF] condition of glass hatch ajar switch.
ACC ON SW Indicates [ON/OFF] condition of ignition switch in ACC position.
IGN ON SW Indicates [ON/OFF] condition of ignition switch in ON position.
KEYLESS UNLOCK Indicates [ON/OFF] condition of unlock signal from keyfob.
KEYLESS LOCK Indicates [ON/OFF] condition of lock signal from keyfob.
KEY CYL LK-SW Indicates [ON/OFF] condition of lock signal from door key cylinder switch.
KEY CYL UN-SW Indicates [ON/OFF] condition of unlock signal from door key cylinder switch.
KEYLESS PBD Indicates [ON/OFF] condition of unlock signal from door key cylinder switch.
CDL UNLOCK SW Indicates [ON/OFF] condition of unlock signal from lock/unlock switch.
CDL LOCK SW Indicates [ON/OFF] condition of lock signal from lock/unlock switch.
HOOD SW Indicates [ON/OFF] condition of hood switch.
Test Item Description
THEFT INDThis test is able to check security indicator lamp operation. The lamp will be turned on when “ON”
on CONSULT-II screen is touched.
HEADLAMP (HI)This test is able to check vehicle security lamp operation. The high beam headlamps will be acti-
vated for 0.5 seconds after “ON” on CONSULT-II screen is touched.
VEHICLE SECURITY HORNThis test is able to check vehicle security horn operation. The horns will be activated for 0.5 sec-
onds after “ON” on CONSULT-II screen is touched.
Test Item Description
SECURITY ALARM SET This mode can confirm and change security alarm ON-OFF setting.
THEFT ALM TRGThe switch which triggered vehicle security alarm is recorded. This mode is able to confirm and
erase the record of vehicle security alarm. The trigger data can be erased by touching “CLEAR”
on CONSULT-II screen.

Page 856 of 3419

INFINITI QX4 2005 Factory Service Manual VEHICLE SECURITY (THEFT WARNING) SYSTEM
BL-89
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: October 20052005 QX56
Trouble DiagnosisEIS008QT
WORK FLOW
“POWER DOOR LOCK SYSTEM” Diagnosis refer to BL-16, "POW
