Page 1225 of 3419

INFINITI QX4 2005 Factory Service Manual EC-34Revision: October 2005 EVAPORATIVE EMISSION SYSTEM 2005 QX56 BBIA0444E

Page 1226 of 3419

INFINITI QX4 2005 Factory Service Manual EVAPORATIVE EMISSION SYSTEM EC-35 C D E F G H I J K L MA EC Revision: October 20052005 QX56 Component InspectionUBS00KZG EVAP CANISTER Check EVAP canister as follows: 1. Block port B . 2. Blow air int

Page 1227 of 3419

INFINITI QX4 2005 Factory Service Manual EC-36Revision: October 2005 EVAPORATIVE EMISSION SYSTEM 2005 QX56 EVAP SERVICE PORT Positive pressure is delivered to the EVAP system through the EVAP service port. If fuel vapor leakage in the EVAP s

Page 1228 of 3419

INFINITI QX4 2005 Factory Service Manual EVAPORATIVE EMISSION SYSTEM EC-37 C D E F G H I J K L MA EC Revision: October 20052005 QX56 How to Detect Fuel Vapor LeakageUBS00KZI CAUTION: Never use compressed air or a high pressure pump. Do not

Page 1229 of 3419

INFINITI QX4 2005 Factory Service Manual EC-38Revision: October 2005 EVAPORATIVE EMISSION SYSTEM 2005 QX56 WITHOUT CONSULT-II 1. Attach the EVAP service port adapter securely to the EVAP ser- vice port. 2. Also attach the pressure pump with

Page 1230 of 3419

INFINITI QX4 2005 Factory Service Manual ON BOARD REFUELING VAPOR RECOVERY (ORVR) EC-39 C D E F G H I J K L MA EC Revision: October 20052005 QX56 ON BOARD REFUELING VAPOR RECOVERY (ORVR)PFP:00032 System DescriptionUBS00KZJ From the beginning

Page 1231 of 3419

INFINITI QX4 2005 Factory Service Manual EC-40Revision: October 2005 ON BOARD REFUELING VAPOR RECOVERY (ORVR) 2005 QX56 Diagnostic ProcedureUBS00KZK SYMPTOM: FUEL ODOR FROM EVAP CANISTER IS STRONG. 1. CHECK EVAP CANISTER 1. Remove EVAP canis

Page 1232 of 3419

INFINITI QX4 2005 Factory Service Manual ON BOARD REFUELING VAPOR RECOVERY (ORVR) EC-41 C D E F G H I J K L MA EC Revision: October 20052005 QX56 SYMPTOM: CANNOT REFUEL/FUEL ODOR FROM THE FUEL FILLER OPENING IS STRONG WHILE REFUELING. 1. CH
