33 R/Y Combination switch output 4 ONLight switch and wiper switch OFF
Wiper dial position 4
34 L Combination switch output 3 ON
Light switch and wiper switch OFF
Wiper dial position 4
35 O/B Combination switch output 2 ON
Light switch and wiper switch OFF
Wiper dial position 4
36 R/W Combination switch output 1 ON
38 W/L Ignition switch (ON) ON — Battery voltage
42 GRGlass hatch ajar switch
signalONHatch glass closed Battery voltage
Hatch glass open 0V
44 ORear wiper auto stop
switch 1ONRise up position (rear wiper arm on
stopper)0V
A Position (full clockwise stop
position)Battery voltage
Forward sweep (counterclockwise
direction)Fluctuating
B Position (full counterclockwise stop
position)0V
Reverse sweep (clockwise direction) Fluctuating
54 Y Rear wiper output circuit 2 ONRise up position (rear wiper arm on
stopper)0V
A Position (full clockwise stop
position)0V
Forward sweep (counterclockwise
direction)0V
B Position (full counterclockwise stop
position)Battery voltage
Reverse sweep (clockwise direction) Battery voltage Te r m i -
nal No.Wire
colorSignal nameMeasuring condition
Reference Value (V)
(Approx.) Ignition
switchOperation or condition
SKIA5292E
SKIA5291E
SKIA5292E
Page 3402 of 3419

REAR WIPER AND WASHER SYSTEM
WW-43
C
D
E
F
G
H
I
J
L
MA
B
WW
Revision: October 20052005 QX56
How to Proceed With Trouble DiagnosisEKS00BEF
1. Confirm the symptoms and customer complaint.
2. Understand operation description and function description. Refer to WW-35, "
System Description" .
3. Perform the Preliminary Check. Refer to WW-43, "
Preliminary Inspection" .
4. Check symptom and repair or replace the cause of malfunction.
5. Does the rear wiper operate normally? If YES: GO TO 6. If NO: GO TO 4.
6. Inspection End.
Preliminary InspectionEKS00BEG
INSPECTION FOR POWER SUPPLY AND GROUND CIRCUIT
Inspection procedure
1. CHECK FUSE
Check if wiper or washer fuse is blown.
OK or NG
OK >> GO TO 2.
NG >> If fuse is blown, be sure to eliminate cause of problem before installing new fuse. Refer to PG-4,
"POWER SUPPLY ROUTING CIRCUIT" .
55 SB Rear wiper output circuit 1 ONRise up position (rear wiper arm on
stopper)0V (except battery voltage at ini-
tial rear wiper ON to lift arm off
stop)
A Position (full clockwise stop
position)Battery voltage
Forward sweep (counterclockwise
direction)Battery voltage
B Position (full counterclockwise stop
position)0V
Reverse sweep (clockwise direction) 0V
67 B Ground ON — 0V
70 W/B Battery power OFF — Battery voltage Te r m i -
nal No.Wire
colorSignal nameMeasuring condition
Reference Value (V)
(Approx.) Ignition
switchOperation or condition
Unit Power source Fuse No.
Front and rear washer motor Ignition ON or START 9
BCMIgnition ON or START 59
Battery f
Page 3403 of 3419
WW-44
REAR WIPER AND WASHER SYSTEM
Revision: October 20052005 QX56
2. CHECK POWER SUPPLY CIRCUIT
1. Disconnect BCM connectors.
2. Check voltage between BCM harness connector terminals and
ground.
OK or NG
OK >> GO TO 3.
NG >> Check harness for open or short between BCM and fuse.
3. GROUND CIRCUIT INSPECTION (BCM)
Check for continuity between the BCM terminal and ground.
OK or NG
OK >> Inspection End.
NG >> Repair/replace BCM ground circuit.
Terminals Ignition switch position
(+)
(–) OFF ON
ConnectorTe r m i n a l
(Wire color)
M18 38 (W/L)
Ground0V Battery voltage
M20 70 (W/B) Battery voltage Battery voltage
WKIA2089E
Terminals
Ignition switch
conditionContinuity
ConnectorTe r m i n a l
(wire color)
M20 67 (B) Ground OFF Yes
WKIA2090E
Page 3404 of 3419

REAR WIPER AND WASHER SYSTEM
WW-45
C
D
E
F
G
H
I
J
L
MA
B
WW
Revision: October 20052005 QX56
CONSULT-II Function (BCM)EKS00BEH
CONSULT-II can display each diagnostic item using the diagnostic test modes shown following.
CONSULT-II OPERATION
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carries out CAN communication.
1. With the ignition switch OFF, connect CONSULT-II and CON-
SULT-II CONVERTER to the data link connector, then turn the
ignition switch ON.
2. Touch "START (NISSAN BASED VHCL)".
3. Touch "BCM" on the "SELECT SYSTEM" screen.
If "BCM" is not indicated, go to GI-39, "
CONSULT-II Data Link
Connector (DLC) Circuit" .
BCM diagnostic
test itemDiagnostic mode Description
Inspection by partWORK SUPPORTSupports inspections and adjustments. Commands are transmitted to the BCM
for setting the status suitable for required operation, input/output signals are
received from the BCM and received data is displayed.
DATA MONITOR Displays BCM input/output data in real time.
ACTIVE TEST Operation of electrical loads can be checked by sending drive signal to them.
SELF-DIAG RESULTS Displays BCM self-diagnosis results.
CAN DIAG SUPPORT MNTR The result of transmit/receive diagnosis of CAN communication can be read.
ECU PART NUMBER BCM part number can be read.
CONFIGURATION Performs BCM configuration read/write functions.
BBIA0369E
BCIA0029E
BCIA0030E
Page 3405 of 3419

WW-46
REAR WIPER AND WASHER SYSTEM
Revision: October 20052005 QX56
4. Select the desired part to be diagnosed on the "SELECT TEST
ITEM" screen.
DATA MONITOR
Operation Procedure
1. Touch "WIPER" on "SELECT TEST ITEM" screen.
2. Touch "DATA MONITOR" on "SELECT DIAG MODE" screen.
3. Touch either "ALL SIGNALS" or "SELECTION FROM MENU" on "SELECT MONITOR ITEM" screen.
4. Touch "START".
5. When "SELECTION FROM MENU" is selected, touch items to be monitored. When "ALL SIGNALS" is
selected, all the items will be monitored.
6. Touch "RECORD" while monitoring, then the status of the monitored item can be recorded. To stop
recording, touch "STOP".
Display Item List
ACTIVE TEST
Operation Procedure
1. Touch "WIPERS" on the "SELECT TEST ITEM" screen.
2. Touch "ACTIVE TEST" on the "SELECT DIAG MODE" screen.
3. Touch item to be tested and check operation of the selected item.
4. During the operation check, touching "BACK" deactivates the operation.
LKIA0183E
All signals Monitors all the items.
Selection from menu Selects and monitors the individual item selected.
Monitor item name
"OPERATION OR UNIT"Contents
IGN ON SW "ON/OFF" Displays "IGN Position (ON)/OFF, ACC Position (OFF)" status as judged from ignition switch signal.
IGN SW CAN "ON/OFF"Displays "IGN Position (ON)/OFF, ACC Position (OFF)" status as judged from CAN communica-
tions.
FR WIPER INT "ON/OFF" Displays "Front Wiper INT (ON)/Other (OFF)" status as judged from wiper switch signal.
FR WIPER LOW "ON/OFF" Displays "Front Wiper LOW (ON)/Other (OFF)" status as judged from wiper switch signal.
FR WIPER HI "ON/OFF" Displays "Front Wiper HI (ON)/Other (OFF)" status as judged from wiper switch signal.
FR WASHER SW "ON/OFF" Displays "Front Washer Switch (ON)/Other (OFF)" status as judged from wiper switch signal.
INT VOLUME (1 - 7) Displays intermittent operation dial position setting (1 - 7) as judged from wiper switch signal.
VEHICLE SPEED "0.0 km/h" Displays vehicle speed as received over CAN communication.
FR WIPER STOP "ON/OFF" Displays "Stopped (ON)/Operating (OFF)" status as judged from the auto stop signal.
RR WIPER INT "ON/OFF" Displays "Rear Wiper INT (ON)/Other (OFF)" status as judged from wiper switch signal.
RR WIPER ON "ON/OFF" Displays "Rear Wiper (ON)/Other (OFF)" status as judged from wiper switch signal.
RR WASHER SW "ON/OFF" Displays "Rear Washer Switch (ON)/Other (OFF)" status as judged from wiper switch signal.
RR WIPER STOP "ON/OFF" Displays "Stopped (OFF)/Operating (ON)" status as judged from the auto stop switch 1.
RR AUTO STP 2 "ON/OFF" Displays "Stopped (OFF)/Operating (ON)" status as judged from the auto stop switch 2.
Page 3406 of 3419

REAR WIPER AND WASHER SYSTEM
WW-47
C
D
E
F
G
H
I
J
L
MA
B
WW
Revision: October 20052005 QX56
Display Item List
Rear Wiper Does Not OperateEKS00BEI
1. REAR WIPER ACTIVE TEST
1. Turn on rear wiper using "ACTIVE TEST". Refer to WW-46, "
ACTIVE TEST" .
2. Make sure rear wiper operates.
OK or NG
OK >> GO TO 7.
NG >> GO TO 2.
2. CHECK REAR WIPER MOTOR CIRCUITS
1. Turn ignition switch OFF.
2. Disconnect BCM connector and rear wiper motor connector.
3. Check continuity between BCM harness connector terminals
and rear wiper motor harness connector terminals.
OK or NO
OK >> GO TO 3.
NO >> Repair harness or connector.
3. CHECK GLASS HATCH AJAR SWITCH
1. Make sure hatch glass is closed.
2. Check continuity between BCM connector M19 terminal 42 (GR)
and ground.
OK or NG
OK >> GO TO 4.
NG >> Repair harness if shorted. If not, refer to BL-117,
"GLASS HATCH AJAR SWITCH CHECK" for further
glass hatch ajar switch diagnosis.
Test item Display on CONSULT-II screen Description
Front wiper HI output FR WIPER (HI) Front wiper HI can be operated by any ON-OFF operation.
Front wiper LO output FR WIPER (LO) Front wiper LO can be operated by any ON-OFF operation.
Front wiper INT output FR WIPER (INT) Front wiper INT can be operated by any ON-OFF operation.
Rear wiper output RR WIPER Rear wiper can be operated by any ON-OFF operation.
Wiper should operate.
Te r m i n a l s
Continuity
ConnectorTerminal
(wire color)ConnectorTe r m i n a l
(wire color)
M1955 (SB)
D7044 (SB)
Ye s
54 (Y) 6 (Y)
WKIA2091E
42 (GR) - Ground : Continuity should not exist.
WKIA2092E
Page 3407 of 3419

WW-48
REAR WIPER AND WASHER SYSTEM
Revision: October 20052005 QX56
4. CHECK REAR WIPER MOTOR AUTO STOP CIRCUITS
1. Disconnect BCM connector M18.
2. Check continuity between BCM harness connector terminals
and rear wiper motor harness connector terminals.
OK or NO
OK >> GO TO 5.
NO >> Repair harness or connector.
5. CHECK REAR WIPER MOTOR AUTO STOP SWITCH GROUNDS
Check continuity between rear wiper motor harness connector D704
terminals and ground.
OK or NG
OK >> GO TO 6.
NG >> Repair harness or connector.
6. CHECK REAR WIPER OPERATING
1. Connect BCM connectors and rear wiper motor connector.
2. Select "RR WIPER" during "ACTIVE TEST". Refer to WW-46,
"ACTIVE TEST" . When rear wiper is operating, check voltage
between BCM connector terminals.
OK or NG
OK >> Replace rear wiper motor. Refer to WW-53, "Removal and Installation of Rear Wiper Motor" .
NG >> Replace BCM. Refer to BCS-20, "
Removal and Installation of BCM" .
Te r m i n a l s
Continuity
ConnectorTe r m i n a l
(wire color)ConnectorTe r m i n a l
(wire color)
M18 26 (Y/L)
D7041 (Y/L)
Ye s
M19 44 (O) 2 (O)
WKIA2093E
Terminals
Continuity
ConnectorTe r m i n a l
(wire color)
D7043 (B)
Ground Yes
5 (B)
WKIA2094E
ConnectorTe r m i n a l s
Voltage
(Approx.) (+)
(–) Condition
Terminal
(wire color)
M1954 (Y)
GroundOperating Fluctuating
55 (SB)End of travel
(stopped)0
WKIA2095E
Page 3408 of 3419

REAR WIPER AND WASHER SYSTEM
WW-49
C
D
E
F
G
H
I
J
L
MA
B
WW
Revision: October 20052005 QX56
7. CHECK COMBINATION SWITCH INPUT SIGNAL
Select "BCM" on CONSULT-II. With "WIPER" data monitor, make
sure "RR WIPER INT", "RR WIPER ON" turn ON-OFF according to
operation of wiper switch.
OK or NG
OK >> Replace BCM. Refer to BCS-20, "Removal and Installa-
tion of BCM" .
NG >> Check the wiper switch. Refer to WW-7, "
COMBINA-
TION SWITCH READING FUNCTION" .
Rear Wiper Stop Position Is IncorrectEKS00BEJ
1. CHECK AUTO STOP SWITCH INPUT SIGNALS
Select "BCM" on CONSULT-II. With "WIPER" data monitor, make
sure "RR WIPER STOP" and "RR AUTO STOP 2" turn ON-OFF
according to wiper operation.
OK or NG
OK >> Replace BCM. Refer to BCS-20, "Removal and Installation of BCM" .
NG >> GO TO 2.
2. CHECK AUTO STOP CIRCUITS FOR SHORT TO GROUND
1. Turn ignition switch to OFF.
2. Disconnect BCM and rear wiper motor connectors.
3. Check continuity between BCM harness connector terminals
and ground.
OK or NO
OK >> GO TO 3.
NO >> Repair harness or connector.When wiper switch is in
INT position: RR WIPER INT ON
When wiper switch is in
ON position: RR WIPER ON ON
SKIA4243E
When wiper switch is OFF
and arm on stop: RR WIPER STOP ON
: RR AUTO STOP 2 ON
When wiper switch is ON
and arm in position A: RR WIPER STOP OFF
: RR AUTO STOP 2 ON
When wiper switch is ON
counterclockwise sweep: RR WIPER STOP OFF
: RR AUTO STOP 2 OFF
When wiper switch is ON
and arm in position B: RR WIPER STOP ON
: RR AUTO STOP 2 OFF
When wiper switch is ON
clockwise sweep: RR WIPER STOP OFF
: RR AUTO STOP 2 OFF
When wiper switch is ON
and arm in position A: RR WIPER STOP ON
: RR AUTO STOP 2 OFF
WKIA1418E
Te r m i n a l s
Continuity
ConnectorTe r m i n a l
(wire color)
M18 26 (Y/L)
Ground No
M19 44 (O)
WKIA2096E
