Page 1953 of 3419
EM-50Revision: October 2005
CAMSHAFT
2005 QX56
–Position No. 1 camshaft bracket close to the mounting posi-
tion, and then install it to prevent from touching liquid gasket
applied to each surface.
–Temporarily tighten the front cover bolts (4 for each bank) as
shown.
4. Tighten the camshaft bracket bolts as follows:
CAUTION:
After tightening the camshaft bracket bolts, be sure to wipe
off excessive liquid gasket from the parts listed below.
Mating surface of rocker cover
Mating surface of front cover
a. Tighten the front cover bolts (4 for each bank) as shown to the
specified torque.
SBIA0259E
KBIA2486E
Camshaft bracket bolts
Step 1 (bolts 9 - 12) : 1.96 N·m (0.2 kg-m, 17 in-lb)
Step 2 (bolts 1 - 8) : 1.96 N·m (0.2 kg-m, 17 in-lb)
Step 3 (all bolts) : 5.88 N·m (0.6 kg-m, 52 in-lb)
Step 4 (all bolts) : 10.4 N·m (1.1 kg-m, 92 in-lb)
KBIA2522E
Front cover bolts : 11.0 N·m (1.1 kg-m, 8ft - lb)
KBIA2486E
Page 1954 of 3419

CAMSHAFT
EM-51
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: October 20052005 QX56
5. Install the camshaft sprockets using the following procedure:
a. Install the camshaft sprockets aligning them with the matching
marks painted on the timing chain when removed. Align the
camshaft sprocket key groove with the dowel pin on the cam-
shaft front edge at the same time. Then temporarily tighten
bolts.
Install the intake and exhaust side camshaft sprockets by
selectively using the groove of the dowel pin according to the
bank. (Common part used for both banks.)
b. Lock the hexagonal part of the camshaft in the same way as for
removal, and tighten the bolts.
c. Check again that the timing mating mark on the timing chain and
on each sprocket are aligned.
6. Install the chain tensioner using the following procedure:
NOTE:
Left bank is shown.
a. Install the chain tensioner.
Compress the plunger and hold it using a stopper pin when
installing.
Loosen the slack guide side timing chain by rotating the cam-
shaft hexagonal part if mounting space is small.
b. Remove the stopper pin and release the plunger, and then apply
tension to the timing chain.
c. Install the chain tensioner cover onto the front cover (RH bank).
Apply liquid gasket as shown.
Use Genuine RTV Silicone Sealant or equivalent. Refer to
GI-45, "
Recommended Chemical Products and Sealants"
.
7. Check and adjust valve clearances. Refer to EM-51, "
Va l v e
Clearance" .
8. Installation of the remaining components is in the reverse order
of removal.
Valv e C le aranceEBS00LMA
INSPECTION
NOTE:
Perform the following inspection after removal, installation or replacement of camshaft or valve-related parts,
or if there are unusual engine conditions due to changes in valve clearance over time (starting, idling, and/or
noise).
1. Warm up the engine. Then stop the engine.
2. Remove the engine cover, battery cover and air duct assembly. Refer to EM-11, "
Removal and Installa-
tion" , SC-9, "REMOVAL" and EM-14, "Removal and Installation" .
KBIA2482E
KBIA2480E
Chain tensioner bolts : 6.9 N·m (0.70 kg-m, 61 in-lb)
Tensioner cover bolts : 9.0 N·m (0.92 kg-m, 80 in-lb)KBIA2479E
KBIA2547E
Page 1955 of 3419
EM-52Revision: October 2005
CAMSHAFT
2005 QX56
3. Remove the right bank and left bank rocker covers using power tool. Refer to EM-33, "Removal and
Installation" .
4. Turn the crankshaft pulley in the normal direction (clockwise
when viewed from engine front) to align TDC identification notch
(without paint mark) with timing indicator.
5. At this time, make sure both the intake and exhaust cam noses
of No. 1 cylinder (top front on left bank) face outside.
If they do not face outside, turn crankshaft pulley once more.
6. Measure valve clearances at the locations marked “×” as shown
in the table below (locations indicated with black arrow).
NOTE:
Firing order 1-8-7-3-6-5-4-2
No. 1 cylinder compression TDC
KBIA2476E
KBIA0400J
Measuring position (RH bank) No. 2 CYL No. 4 CYL No. 6 CYL No. 8 CYL
No. 1 cylinder at TDC EXH ×
INT××
Measuring position (LH bank) No. 1 CYL No. 3 CYL No. 5 CYL No. 7 CYL
No. 1 cylinder at TDCINT××
EXH××
KBIA2526E
Page 1956 of 3419

CAMSHAFT
EM-53
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: October 20052005 QX56
Measure valve clearances using suitable tool.
CAUTION:
If the inspection was carried out with a cold engine, make sure the values with a fully warmed
up engine are still within specifications.
7. Turn the crankshaft pulley clockwise by 270° from the position of No. 1 cylinder compression TDC to
obtain No. 3 cylinder compression TDC.
8. Measure valve clearances at the locations marked “×” as shown
in the table below (locations indicated with white arrow).
No. 3 cylinder compression TDC
9. Turn the crankshaft pulley clockwise 90° from the position of No.
3 cylinder compression TDC (clockwise by 360° from the posi-
tion of No. 1 cylinder compression TDC) to measure the intake
and exhaust valve clearances of No. 6 cylinder and exhaust
valve clearance of No. 2 cylinder.
10. If out of specifications, adjust as necessary, Refer to EM-53, "
ADJUSTMENT" :
ADJUSTMENT
NOTE:
Perform adjustment depending on the selected head thickness of the valve lifter.Valve clearance standard:
Hot*
Intake : 0.304 - 0.416 mm (0.012 - 0.016 in)
Exhaust : 0.308 - 0.432 mm (0.012 - 0.017 in)
Cold
Intake : 0.26 - 0.34 mm (0.010 - 0.013 in)
Exhaust : 0.29 - 0.37 mm (0.011 - 0.015 in)
* : Approximately 80°C (176°F)
KBIA0185E
Measuring position (RH bank) No. 2 CYL No. 4 CYL No. 6 CYL No. 8 CYL
No. 3 cylinder at TDC EXH ×
INT ×
Measuring position (LH bank) No. 1 CYL No. 3 CYL No. 5 CYL No. 7 CYL
No. 3 cylinder at TDCINT××
EXH××
KBIA2526E
KBIA2548E
Page 1957 of 3419

EM-54Revision: October 2005
CAMSHAFT
2005 QX56
The specified valve lifter thickness is the dimension at normal temperatures. Ignore dimensional differ-
ences caused by temperature. Use the specifications for hot engine condition to adjust.
1. Remove the camshaft. Refer to EM-43, "
Removal and Installation" .
2. Remove the valve lifters at the locations that are out of specification.
3. Measure the center thickness of the removed valve lifters using
suitable tool.
4. Use the equation below to calculate the valve lifter thickness for replacement.
Valve lifter thickness calculation:
Thickness of replacement valve lifter = t1+ (C1 - C2)
t1 = Thickness of removed valve lifter
C1 = Measured valve clearance
C2= Standard valve clearance:
Thickness of a new valve lifter can be identified by stamp
marks on the reverse side (inside the cylinder).
Stamp mark N788 indicates 7.88 mm (0.3102 in) in thickness.
Available thickness of valve lifter: 25 sizes with range 7.88 to
8.36 mm (0.3102 to 0.3291 in) in steps of 0.02 mm (0.0008 in)
(when manufactured at factory). Refer to EM-101, "
Available
Valve Lifter" .
5. Install the selected valve lifter.
6. Install the camshaft.
7. Manually turn the crankshaft pulley a few turns.
8. Make sure the valve clearances for cold engine are within specifications by referring to the specified val-
ues.
9. After completing the repair, check the valve clearances again with the specifications for a warmed engine.
Make sure the values are within specifications.
KBIA0057E
Intake : 0.36 mm (0.0142 in)*
Exhaust : 0.37 mm (0.0146 in)*
*: Approximately 80°C (176°F)
KBIA0 119 E
Valve clearance standard:
Hot*
Intake : 0.304 - 0.416 mm (0.012 - 0.016 in)
Exhaust : 0.308 - 0.432 mm (0.012 - 0.017 in)
Cold
Intake : 0.26 - 0.34 mm (0.010 - 0.013 in)
Exhaust : 0.29 - 0.37 mm (0.011 - 0.015 in)
* : Approximately 80°C (176°F)
Page 1958 of 3419

OIL SEAL
EM-55
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: October 20052005 QX56
OIL SEALPFP:00100
Removal and Installation of Valve Oil SealEBS00LMB
REMOVAL
1. Remove the camshaft relating to the valve oil seal to be removed. Refer to EM-43, "REMOVAL" .
2. Remove the valve lifters. Refer to EM-43, "
REMOVAL" .
Correctly identify the location where each part is removed from. Keep parts organized to avoid mixing
them up.
3. Turn the crankshaft until the cylinder requiring new oil seals is at TDC. This will prevent the valve from
dropping into the cylinder.
4. Remove the valve collet using Tool.
CAUTION:
Do not damage the valve lifter holes.
5. Remove the valve spring retainer and valve spring.
CAUTION:
Do not remove the valve spring seat from the valve spring.
6. Remove the valve oil seal using Tool.
INSTALLATION
Installation is in the reverse order of removal.
Install the valve oil seal using Tool.
Apply new engine oil on the new valve oil seal joint and seal lip.
Install the valve oil seal to the specified height "H".Tool number : KV10116200 (J-26336-B)
: KV10115900 (J-26336-20)
: KV10109220 ( — )
WBIA0578E
Tool number : KV10107902 (J-38959)
WBIA0478E
Tool number : KV10115600 (J-38958)
Height "H" (Without valve spring seat installed)
Intake and exhaust : 14.3 - 14.9 mm (0.563 - 0.587 in)
WBIA0490E
Page 1959 of 3419

EM-56Revision: October 2005
OIL SEAL
2005 QX56
Removal and Installation of Front Oil SealEBS00LMC
REMOVAL
1. Remove the radiator. Refer to CO-12, "Removal and Installation" .
2. Remove cooling fan. Refer to CO-15, "
Removal and Installation (Crankshaft Driven Type)" .
3. Remove the crankshaft pulley. Refer to EM-35, "
TIMING CHAIN" .
4. Remove the front oil seal using suitable tool.
CAUTION:
Do not damage front cover and oil pump drive spacer.
INSTALLATION
1. Apply new engine oil to both the oil seal lip and dust seal lip of the new front oil seal.
2. Install the front oil seal.
Install the front oil seal so that each seal lip is oriented as
shown.
Press-fit until the height of the front oil seal is level with the
mounting surface using suitable tool.
CAUTION:
Do not damage front timing chain case and crankshaft.
Press-fit straight and avoid causing burrs or tilting oil
seal.
3. Installation of the remaining components is in the reverse order of removal.
Removal and Installation of Rear Oil SealEBS00LMD
REMOVAL
1. Remove the transmission assembly. Refer to AT-244, "Removal and Installation (4x2)" or AT-247,
"Removal and Installation (4x4)" .
a. Remove the drive plate.
Holding the crankshaft pulley bolt, lock the crankshaft and remove the drive plate bolts.
Remove the bolts diagonally.
CAUTION:
Do not damage the drive plate. Especially, avoid deforming and damaging the signal plate
teeth (circumference position).
Place the drive plate with the signal plate surface facing other than downward.
SBIA0359E
SEM 71 5A
PBIC2931E
Page 1960 of 3419
OIL SEAL
EM-57
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: October 20052005 QX56
Keep magnetic materials away from signal plate.
b. Remove the engine rear plate.
2. Remove the rear oil seal using suitable tool.
CAUTION:
Do not damage crankshaft or oil seal retainer surface.
INSTALLATION
1. Apply new engine oil to both the oil seal lip and dust seal lip of the new rear oil seal.
2. Install the rear oil seal.
Install the rear oil seal so that each seal lip is oriented as
shown.
Press-fit the rear oil seal using suitable tool.
CAUTION:
Do not damage the crankshaft or cylinder block.
Press-fit the oil seal straight to avoid causing burrs or
tilting.
Do not touch grease applied onto the oil seal lip.
Do not damage or scratch the outer circumference of
the rear oil seal.
Tap until flattened with the front edge of the oil seal retainer.
3. Installation of the remaining components is in the reverse order of removal.
WBIA0437E
SEM 71 5A
WBIA0438E
