Page 2417 of 3419

INFINITI QX4 2005 Factory Service Manual LAN-138 [CAN] CAN SYSTEM (TYPE 4) Revision: October 20052005 QX56 Case 3 Check harness between ICC unit and driver seat control unit. Refer to LAN-158, "Circuit Check Between ICC Unit and Driver Seat

Page 2418 of 3419

INFINITI QX4 2005 Factory Service Manual CAN SYSTEM (TYPE 4) LAN-139 [CAN] C D E F G H I J L MA B LAN Revision: October 20052005 QX56 Case 4 Check harness between driver seat control unit and data link connector. Refer to LAN-158, "Circuit C

Page 2419 of 3419

INFINITI QX4 2005 Factory Service Manual LAN-140 [CAN] CAN SYSTEM (TYPE 4) Revision: October 20052005 QX56 Case 5 Check harness between data link connector and IPDM E/R. Refer to LAN-159, "Circuit Check Between Data Link Connector and IPDM E

Page 2420 of 3419

INFINITI QX4 2005 Factory Service Manual CAN SYSTEM (TYPE 4) LAN-141 [CAN] C D E F G H I J L MA B LAN Revision: October 20052005 QX56 Case 6 Check ECM circuit. Refer to LAN-160, "ECM Circuit Check" . SKIB3388E PKIA8823E

Page 2421 of 3419

INFINITI QX4 2005 Factory Service Manual LAN-142 [CAN] CAN SYSTEM (TYPE 4) Revision: October 20052005 QX56 Case 7 Check TCM circuit. Refer to LAN-160, "TCM Circuit Check" . SKIB3389E PKIA8824E

Page 2422 of 3419

INFINITI QX4 2005 Factory Service Manual CAN SYSTEM (TYPE 4) LAN-143 [CAN] C D E F G H I J L MA B LAN Revision: October 20052005 QX56 Case 8 Check ICC sensor circuit. Refer to LAN-161, "ICC Sensor Circuit Check" . SKIB3390E PKIA8825E

Page 2423 of 3419

INFINITI QX4 2005 Factory Service Manual LAN-144 [CAN] CAN SYSTEM (TYPE 4) Revision: October 20052005 QX56 Case 9 Check ICC unit circuit. Refer to LAN-161, "ICC Unit Circuit Check" . SKIB3391E PKIA8826E

Page 2424 of 3419

INFINITI QX4 2005 Factory Service Manual CAN SYSTEM (TYPE 4) LAN-145 [CAN] C D E F G H I J L MA B LAN Revision: October 20052005 QX56 Case 10 Check driver seat control unit circuit. Refer to LAN-162, "Driver Seat Control Unit Circuit Check"
