INFINITI QX4 2005 Factory Service Manual AT-282 REPAIR FOR COMPONENT PARTS Revision: October 20052005 QX56 3. Install oil pump housing oil seal to the oil pump housing until it is flush with the face of oil pump housing, using Tool. CAUTION:

Page 354 of 3419

INFINITI QX4 2005 Factory Service Manual REPAIR FOR COMPONENT PARTS AT-283 D E F G H I J K L MA B AT Revision: October 20052005 QX56 2. Remove 3rd one-way clutch from front sun gear. INSPECTION 3rd One-way Clutch Check frictional surface fo

Page 355 of 3419

INFINITI QX4 2005 Factory Service Manual AT-284 REPAIR FOR COMPONENT PARTS Revision: October 20052005 QX56 b. Check 3rd one-way clutch for correct locking and unlocking directions. CAUTION: If not as shown in illustration, check installation

Page 356 of 3419

INFINITI QX4 2005 Factory Service Manual REPAIR FOR COMPONENT PARTS AT-285 D E F G H I J K L MA B AT Revision: October 20052005 QX56 DISASSEMBLY 1. Compress snap ring using 2 flat-bladed screwdrivers. 2. Remove front carrier assembly and inp

Page 357 of 3419

INFINITI QX4 2005 Factory Service Manual AT-286 REPAIR FOR COMPONENT PARTS Revision: October 20052005 QX56 4. Disassemble input clutch assembly. a. Remove O-ring and seal rings from input clutch assembly. b. Remove needle bearing from input

Page 358 of 3419

INFINITI QX4 2005 Factory Service Manual REPAIR FOR COMPONENT PARTS AT-287 D E F G H I J K L MA B AT Revision: October 20052005 QX56 CAUTION: If necessary, replace the input clutch assembly. Front Carrier Assembly Check for deformation, fat

Page 359 of 3419

INFINITI QX4 2005 Factory Service Manual AT-288 REPAIR FOR COMPONENT PARTS Revision: October 20052005 QX56 c. Install needle bearing in input clutch assembly. CAUTION: Apply petroleum jelly to needle bearing. d. Install new O-ring and seal r

Page 360 of 3419

INFINITI QX4 2005 Factory Service Manual REPAIR FOR COMPONENT PARTS AT-289 D E F G H I J K L MA B AT Revision: October 20052005 QX56 3. Compress snap ring using 2 flat-bladed screwdrivers. 4. Install front carrier assembly and input clutch a
