Page 1153 of 3419

INFINITI QX4 2005 Factory Service Manual DI-50 WARNING CHIME Revision: October 20052005 QX56 4. Touch “BUZZER” or “BCM”. 5. Select “DATA MONITOR” or “SELF-DIAG RESULTS”. DATA MONITOR Operation Procedure 1. Touch “BUZZER”

Page 1154 of 3419

INFINITI QX4 2005 Factory Service Manual WARNING CHIME DI-51 C D E F G H I J L MA B DI Revision: October 20052005 QX56 Display Item List SELF-DIAGNOSTIC RESULTS Operation Procedure 1. Touch “BCM” on "SELECT TEST ITEM” screen. 2. Touch

Page 1155 of 3419

INFINITI QX4 2005 Factory Service Manual DI-52 WARNING CHIME Revision: October 20052005 QX56 Key Warning Chime and Light Warning Chime Do Not Operate (Seat Belt Warn- ing Chime Does Operate) EKS00BCY 1. CHECK BCM INPUT SIGNAL With CONSULT-II

Page 1156 of 3419

INFINITI QX4 2005 Factory Service Manual WARNING CHIME DI-53 C D E F G H I J L MA B DI Revision: October 20052005 QX56 3. CHECK FRONT DOOR SWITCH LH Check continuity between front door switch LH terminal 2 and exposed metal of switch while p

Page 1157 of 3419

INFINITI QX4 2005 Factory Service Manual DI-54 WARNING CHIME Revision: October 20052005 QX56 3. CHECK BCM INPUT SIGNAL With CONSULT-II With "DATA MONITOR" of "BUZZER", confirm "KEY ON SW" changes when the key is inserted/removed from the ign

Page 1158 of 3419

INFINITI QX4 2005 Factory Service Manual WARNING CHIME DI-55 C D E F G H I J L MA B DI Revision: October 20052005 QX56 5. CHECK KEY SWITCH CIRCUIT 1. Disconnect BCM. 2. Check continuity between BCM harness connector M18 terminal 37 (B/R) an

Page 1159 of 3419

INFINITI QX4 2005 Factory Service Manual DI-56 WARNING CHIME Revision: October 20052005 QX56 Seat Belt Warning Chime Does Not OperateEKS00BD1 1. CHECK WARNING CHIME OPERATION 1. With key removed from the ignition and the front door LH open,

Page 1160 of 3419

INFINITI QX4 2005 Factory Service Manual WARNING CHIME DI-57 C D E F G H I J L MA B DI Revision: October 20052005 QX56 5. CHECK SEAT BELT BUCKLE SWITCH CIRCUIT 1. Disconnect combination meter connector. 2. Check continuity between combinatio
