3. CHECK ENCODER GROUND
1. Turn ignition switch OFF.
2. Check continuity between front power window motor LH connector D9 terminal 6 and ground.
OK or NG
OK >> GO TO 5.
NG >> GO TO 4.
4. CHECK ENCODER GROUND CIRCUIT
1. Disconnect main power window and door lock/unlock switch.
2. Check continuity between front power window motor LH connector D9 terminal 6 and main power window
and door lock/unlock switch connector D7 terminal 2.
OK or NG
OK >> Replace main power window and door lock/unlock
switch.
NG >> Repair or replace harness.
5. CHECK ENCODER SIGNAL
1. Connect front power window motor LH.
2. Turn ignition switch ON.
3. Check the signal between main power window and door lock/unlock switch connector and ground with
oscilloscope.
OK or NG
OK >> Replace main power window and door lock/unlock switch.
NG >> GO TO 6.6 (W/B) - Ground : Continuity should exist.
LIIA0923E
6 (W/B) - 2 (W/B) : Continuity should exist.
LIIA0924E
Connec-
torTerminals (Wire color)
Condition Signal
(+) (-)
D7 13 (G/Y) Ground Opening
LIIA0364EOCC3383D
Page 2202 of 3419

POWER WINDOW SYSTEM
GW-47
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: October 20052005 QX56
6. CHECK ENCODER CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect front power window motor LH and main power window and door lock/unlock switch.
3. Check continuity between front power window motor LH connector D9 terminal 3 and main power window
and door lock/unlock switch connector D7 terminal 13.
OK or NG
OK >> Replace front power window motor LH.
NG >> Repair or replace harness.
Encoder Circuit Check Front RHEIS005Y6
1. CHECK POWER WINDOW MOTOR RH POWER SUPPLY
1. Turn ignition switch OFF.
2. Disconnect front power window motor RH.
3. Turn ignition switch ON.
4. Check voltage between front power window motor RH connector D104 terminal 4 and ground.
OK or NG
OK >> GO TO 3.
NG >> GO TO 2.
2. CHECK HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect power window and door lock/unlock switch RH.
3. Check continuity between front power window motor RH connector D104 terminal 4 and power window
and door lock/unlock switch RH connector D105 terminal 4.
OK or NG
OK >> Replace power window and door lock/unlock switch RH.
NG >> Repair or replace harness.3 (G/Y) - 13 (G/Y) : Continuity should exist.
LIIA0937E
4 (G/R) - Ground : Approx. 10V
WIIA0513E
4 (G/R) - 4 (G/R) : Continuity should exist.
LIIA1266E
Page 2203 of 3419

GW-48
POWER WINDOW SYSTEM
Revision: October 20052005 QX56
3. CHECK ENCODER GROUND
1. Turn ignition switch OFF.
2. Check continuity between front power window motor RH connector D104 terminal 6 and ground.
OK or NG
OK >> GO TO 5.
NG >> GO TO 4.
4. CHECK ENCODER GROUND CIRCUIT
1. Disconnect power window and door lock/unlock switch RH.
2. Check continuity between front power window motor RH connector D104 terminal 6 and power window
and door lock/unlock switch RH connector D105 terminal 3.
OK or NG
OK >> Replace power window and door lock/unlock switch RH.
NG >> Repair or replace harness.
5. CHECK ENCODER SIGNAL
1. Connect front power window motor RH.
2. Turn ignition switch ON.
3. Check the signal between power window and door lock/unlock switch RH connector and ground with
oscilloscope.
OK or NG
OK >> Replace power window and door lock/unlock switch RH.
NG >> GO TO 6.6 (W/B) - Ground : Continuity should exist.
LIIA0923E
6 (W/B) - 3 (W/B) : Continuity should exist.
LIIA1264E
Connec-
torTerminals (Wire color)
Condition Signal
(+) (-)
D105 12 (G/Y) Ground Opening
LIIA1267EOCC3383D
Page 2204 of 3419

POWER WINDOW SYSTEM
GW-49
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: October 20052005 QX56
6. CHECK ENCODER CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect front power window motor RH and power window and door lock/unlock switch RH.
3. Check continuity between front power window motor RH connector D104 terminal 3 and power window
and door lock/unlock switch RH connector D105 terminal 12.
OK or NG
OK >> Replace front power window motor RH.
NG >> Repair or replace harness.
Door Switch CheckEIS005Y7
1. CHECK FRONT DOOR SWITCH INPUT SIGNAL
With CONSULT-II
Check front door switches (“DOOR SW-DR” and “DOOR SW-AS” ) in “DATA MONITOR” mode with CON-
SULT-II.
Without CONSULT-II
Check voltage between BCM connector and ground.
OK or NG
OK >> Front door switch is OK.
NG >> GO TO 2.3 (G/Y) - 12 (G/Y) : Continuity should exist.
LIIA1268E
Monitor item Condition
DOOR SW-DROPEN : ON
CLOSE : OFF
DOOR SW-ASOPEN : ON
CLOSE : OFF
PIIA2464E
Item ConnectorTerminals (Wire color)
ConditionVoltage (V)
(Approx.)
(+) (-)
Front RH M18 12 (R/L)
GroundOPEN 0
CLOSE Battery voltage
Front LH M19 47 (SB)OPEN 0
CLOSE Battery voltage
LIIA0946E
Page 2205 of 3419

GW-50
POWER WINDOW SYSTEM
Revision: October 20052005 QX56
2. CHECK FRONT DOOR SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect front door switch LH or RH and BCM.
3. Check continuity between front door switch connector B8 (LH) or B108 (RH) terminal 2 and BCM connec-
tor M19 terminal 47 (LH) or connector M18 terminal 12 (LH).
4. Check continuity between front door switch connector B8 (LH)
or B108 (RH) terminal 2 and ground.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace harness.
3. CHECK DOOR SWITCH
1. Disconnect front door switch LH or RH.
2. Check continuity between each front door switch terminal 2 and body ground part of front door switch.
OK or NG
OK >> Replace BCM.
NG >> Replace malfunctioning front door switch.Front LH
2 (SB) - 47 (SB) : Continuity should exist.
Front RH
2 (R/L) - 12 (R/L) : Continuity should exist.
2 (SB or R/L) - Ground : Continuity should not exist.
LIIA0947E
Terminal Door switch Continuity
2Body ground part
of front door
switchPushed No
Released Yes
LIIA0948E
Page 2206 of 3419

POWER WINDOW SYSTEM
GW-51
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: October 20052005 QX56
Front Door Lock Assembly LH (Key Cylinder Switch) CheckEIS005Y8
1. CHECK FRONT DOOR LOCK ASSEMBLY LH (KEY CYLINDER SWITCH) INPUT SIGNAL
With CONSULT-II
Check front door lock assembly LH (key cylinder switch) (“KEY
CYL LK SW”) in “DATA MONITOR” mode for “POWER DOOR
LOCK SYSTEM” with CONSULT-II. Refer to GW-34, "
DATA
MONITOR" .
Check front door lock assembly LH (key cylinder switch) (“KEY
CYL UN-SW”) in “DATA MONITOR” mode for “POWER DOOR
LOCK SYSTEM” with CONSULT-II. Refer to GW-34, "
DATA
MONITOR" .
Without CONSULT-II
Check voltage between main power window and door lock/unlock switch connector and ground.
OK or NG
OK >> Front door lock assembly LH (key cylinder switch) is OK.
NG >> GO TO 2.
2. CHECK FRONT DOOR LOCK ASSEMBLY LH (KEY CYLINDER SWITCH) CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect main power window and door lock/unlock switch and front door lock assembly (key cylinder
switch).
3. Check continuity between main power window and door lock/
unlock switch connector D7 terminals 4, 6 and front door lock
assembly LH (key cylinder switch) connector D14 terminals 1, 6.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace harness.“KEY CYL LK-SW” should be “ON” when key inserted
in door key cylinder is turned to lock.
LIIA0047E
“KEY CYL UN-SW” should be “ON” when key inserted
in door key cylinder was turned to unlock.
LIIA0050E
ConnectorTerminals (Wire color)
Key position Voltage (V)
(Approx.)
(+) (–)
D76 (R)
GroundNeutral / Unlock 5
Lock 0
4 (L)Neutral / Lock 5
Unlock 0
LIIA1448E
6 (R) - 6 (R) : Continuity should exist.
4 (L) - 1 (L) : Continuity should exist.
LIIA1571E
Page 2207 of 3419
GW-52
POWER WINDOW SYSTEM
Revision: October 20052005 QX56
3. CHECK FRONT DOOR LOCK ASSEMBLY LH (KEY CYLINDER SWITCH) GROUND
Check continuity between front door lock assembly LH (key cylinder switch) connector D14 terminal 5 and
ground.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace harness.
4. CHECK FRONT DOOR LOCK ASSEMBLY LH (KEY CYLINDER SWITCH)
Check continuity between front door lock assembly LH (key cylinder switch) connector D14 terminals 1, 6 and
5.
OK or NG
OK >> Replace main power window and door lock/unlock
switch.
NG >> Replace front door lock assembly LH (key cylinder
switch). 5 (B) - Ground : Continuity should exist.
LIIA1572E
Terminals Key position Continuity
6
5Neutral / Unlock No
Lock Yes
1Neutral / Lock No
Unlock Yes
LIIA1573E
Page 2208 of 3419

POWER WINDOW SYSTEM
GW-53
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: October 20052005 QX56
Power Window Serial Link Check Front LH and RHEIS005Y9
1. CHECK SERIAL LINK OUTPUT SIGNAL
With CONSULT-II
Check door lock and unlock switch (“LOCK SW DR/AS”, “UNLK SW DR/AS”) in DATA MONITOR mode for
“REMOTE KEYLESS ENTRY SYSTEM” with CONSULT-II. Refer to GW-34, "
DATA MONITOR" .
When door lock and unlock switch is turned to LOCK
When door lock and unlock switch is turned to UNLOCK
Without CONSULT-II
1. Remove key from ignition switch, and the door of driver side and passenger side is closed.
2. Check the signal between BCM connector and ground with oscilloscope when door lock and unlock
switch (front LH and front RH) is turned “LOCK” or “UNLOCK”.
3. Make sure signals which are shown in the figure below can be
detected during 10 second just after door lock and unlock switch
(front LH and front RH) is turned “LOCK” or “UNLOCK”.
OK or NG
OK >> GO TO 2.
NG >> GO TO 3.
2. CHECK BCM OUTPUT SIGNAL
Check power window serial link (“POWER WINDOW DOWN”) in “ACTIVE TEST” mode with CONSULT-II.
Refer to GW-34, "
ACTIVE TEST" .
When “ACTIVE TEST” is executed, is the window of driver side and
passenger side lowered.
OK or NG
OK >> Further inspection is necessary. Refer to GW-35, "Trou-
ble Diagnoses Symptom Chart" .
NG >> Replace BCM.LOCK SW DR/AS : ON
UNLK SW DR/AS : ON
LIIA0172E
ConnectorTerminals (Wire color)
Signal
(+) ( – )
M18 22 (W/V) Ground
LIIA0391E
PIIA2344E
PIIA3080E
