INFINITI QX4 2005  Factory Service Manual CO-16Revision: October 2005
ENGINE COOLING FAN
2005 QX56
Start and warm up the engine. Visually make sure that there are no leaks of the engine coolant.
Removal and Installation (Motor Driven Type)EB

Page 1098 of 3419

INFINITI QX4 2005  Factory Service Manual WATER PUMP
CO-17
C
D
E
F
G
H
I
J
K
L
MA
CO
Revision: October 20052005 QX56
WATER  P UM PPFP:21020
Removal and InstallationEBS00LNC
CAUTION:
When removing water pump, be careful not to get engine cool

Page 1099 of 3419

INFINITI QX4 2005  Factory Service Manual CO-18Revision: October 2005
WATER PUMP
2005 QX56
After installation bleed the air from the cooling system. Refer to MA-14, "REFILLING ENGINE COOLANT"
.
INSPECTION AFTER INSTALLATION
Check for leaks

Page 1100 of 3419

INFINITI QX4 2005  Factory Service Manual THERMOSTAT AND WATER PIPING
CO-19
C
D
E
F
G
H
I
J
K
L
MA
CO
Revision: October 20052005 QX56
THERMOSTAT AND WATER PIPINGPFP:21200
Removal and InstallationEBS00LND
REMOVAL
Removal of Thermostat
1. Drain

Page 1101 of 3419

INFINITI QX4 2005  Factory Service Manual CO-20Revision: October 2005
THERMOSTAT AND WATER PIPING
2005 QX56
CAUTION:
Perform when the engine is cold.
2. Remove the air duct and resonator assembly. Refer to EM-14, "
REMOVAL" .
3. Remove the en

Page 1102 of 3419

INFINITI QX4 2005  Factory Service Manual SERVICE DATA AND SPECIFICATIONS (SDS)
CO-21
C
D
E
F
G
H
I
J
K
L
MA
CO
Revision: October 20052005 QX56
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
Standard and LimitEBS00LNE
ENGINE COOLANT CAPACITY

Page 1103 of 3419

INFINITI QX4 2005  Factory Service Manual CO-22Revision: October 2005
SERVICE DATA AND SPECIFICATIONS (SDS)
2005 QX56

Page 1104 of 3419
