INFINITI QX4 2005 Factory Service Manual BRC-30
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: October 20052005 QX56
Display Item List
Self-diagnostic item Malfunction detecting condition Check system
FR LH SENSOR 1
[C1104]Circuit of front LH whe

BRC-30
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: October 20052005 QX56
Display Item List
Self-diagnostic item Malfunction detecting condition Check system
FR LH SENSOR 1
[C1104]Circuit of front LH wheel sensor is open, shorted or sensor power
voltage is unusual.
BRC-38, "
Wheel Sensor
System Inspection"
(Note 1) RR RH SENSOR 1
[C1101]Circuit of rear RH wheel sensor is open, shorted or sensor power
voltage is unusual.
FR RH SENSOR 1
[C1103]Circuit of front RH wheel sensor is open, shorted or sensor power
voltage is unusual.
RR LH SENSOR 1
[C1102]Circuit of rear LH wheel sensor is open, shorted or sensor power
voltage is unusual.
FR LH SENSOR 2
[C1108]ABS actuator and electric unit (control unit) cannot identify sen-
sor pulses, because of large gap between wheel sensor and sen-
sor rotor.
RR RH SENSOR 2
[C1105]ABS actuator and electric unit (control unit) cannot identify sen-
sor pulses, because of large gap between wheel sensor and sen-
sor rotor.
FR RH SENSOR 2
[C1107]ABS actuator and electric unit (control unit) cannot identify sen-
sor pulses, because of large gap between wheel sensor and sen-
sor rotor.
RR LH SENSOR 2
[C1106]ABS actuator and electric unit (control unit) cannot identify sen-
sor pulses, because of large gap between wheel sensor and sen-
sor rotor.
ABS SENSOR
[C1115]Wheel sensor input is abnormal.
STOP LAMP SW
[C1116]Stop lamp switch or circuit malfunction.BRC-45, "
Stop L am p
Switch System Inspec-
tion"
DECEL G SEN SET
[C1160]ABS decel sensor adjustment is incomplete.BRC-55, "Inspection For
Self-diagnosis Result
"DECEL G SEN SET""
ST ANGL SEN SAFE
[C1163]When steering angle sensor is in safe mode.BRC-54, "Steering Angle
Sensor Safe Mode
Inspection"
ST ANGLE SEN CIRCUIT
[C1143]Neutral position of steering angle sensor is dislocated, or steer-
ing angle sensor is malfunctioning.BRC-41, "Steering Angle
Sensor System"
YAW R AT E S E N S O R
[C1145]Yaw rate sensor has generated an error, or yaw rate sensor sig-
nal line is open or shorted.BRC-42, "Ya w R a t e /
Side/Decel G Sensor
System Inspection"

Page 1042 of 3419

INFINITI QX4 2005 Factory Service Manual TROUBLE DIAGNOSIS
BRC-31
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: October 20052005 QX56
FR LH IN ABS SOL
[C1120]Circuit of front LH IN ABS solenoid is open or shorted, or control
line is op

TROUBLE DIAGNOSIS
BRC-31
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: October 20052005 QX56
FR LH IN ABS SOL
[C1120]Circuit of front LH IN ABS solenoid is open or shorted, or control
line is open or shorted to power supply or ground.
BRC-43, "
Solenoid and
VDC Change-Over Valve
System Inspection"
FR LH OUT ABS SOL
[C1121]Circuit of front LH OUT ABS solenoid is open or shorted, or con-
trol line is open or shorted to power supply or ground.
RR RH IN ABS SOL
[C1126]Circuit of rear RH IN ABS solenoid is open or shorted, or control
line is open or shorted to power supply or ground.
RR RH OUT ABS SOL
[C1127]Circuit of rear RH OUT ABS solenoid is open or shorted, or con-
trol line is open or shorted to power supply or ground.
FR RH IN ABS SOL
[C1122]Circuit of front RH IN ABS solenoid is open or shorted, or control
line is open or shorted to power supply or ground.
FR RH OUT ABS SOL
[C1123]Circuit of front RH OUT ABS solenoid is open or shorted, or con-
trol line is open or shorted to power supply or ground.
RR LH IN ABS SOL
[C1124]Circuit of rear LH IN ABS solenoid is open or shorted, or control
line is open or shorted to power supply or ground.
RR LH OUT ABS SOL
[C1125] Circuit of rear LH OUT ABS solenoid is open or shorted, or con-
trol line is open or shorted to power supply or ground.
CV1
[C1164]Front side VDC switch-over solenoid valve (cut valve) is open or
shorted, or control line is open or shorted to power supply or
ground.
CV2
[C1165]Rear side VDC switch-over solenoid valve (cut valve) is open or
shorted, or control line is open or shorted to power supply or
ground.
SV1
[C1166]Front side VDC switch-over solenoid valve (suction valve) is
open or shorted, or control line is open or shorted to power sup-
ply or ground.
SV2
[C1167]Rear side VDC switch-over solenoid valve (suction valve) is open
or shorted, or control line is open or shorted to power supply or
ground.
PUMP MOTOR (Note 3)
[ C 1111 ]During actuator motor operation with ON, when actuator motor
turns OFF or when control line for actuator motor relay is open.BRC-44, "
Actuator
Motor, Motor Relay, and
Circuit Inspection"During actuator motor operation with OFF, when actuator motor
turns ON or when control line for relay is shorted to ground.
BATTERY VOLTAGE
[ABNORMAL]
[C1109]ABS actuator and electric unit (control unit) power voltage is too
low.BRC-46, "
ABS/TCS/
VDC Control Unit Power
and Ground Systems
Inspection"
ST ANGLE SEN SIGNAL
[C1144]Neutral position correction of steering angle sensor is not fin-
ished.BRC-55, "
Inspection For
Self-diagnosis Result
"ST ANGLE SEN SIG-
NAL""
ST ANG SEN COM CIR
[C1156]CAN communication line or steering angle sensor has generated
an error.BRC-41, "Steering Angle
Sensor System"
LONGITUDINAL G-SENSOR
[ C 111 3 ]Longitudinal G-sensor is malfunctioning, or signal line of longitu-
dinal G-sensor is open or shorted.BRC-42, "Yaw Rate/
Side/Decel G Sensor
System Inspection"
CONTROLLER FAILURE
[ C 111 0 ]Internal malfunction of ABS actuator and electric unit (control
unit)BRC-40, "ABS/TCS/
VDC Control Unit
Inspection"
CAN COMM CIRCUIT
[U1000]
CAN communication line is open or shorted.
ABS actuator and electric unit (control unit) internal malfunc-
tion
Battery voltage for ECM is suddenly interrupted for approxi-
mately 0.5 second or more.BRC-55, "
CAN Commu-
nication System Inspec-
tion" (Note 2) Self-diagnostic item Malfunction detecting condition Check system

Page 1043 of 3419

INFINITI QX4 2005 Factory Service Manual BRC-32
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: October 20052005 QX56
Note 1. If wheel sensor 2 for each wheel is indicated, check ABS actuator and electric unit (control unit) power
supply voltage i

BRC-32
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: October 20052005 QX56
Note 1. If wheel sensor 2 for each wheel is indicated, check ABS actuator and electric unit (control unit) power
supply voltage in addition to wheel sensor circuit check.
Note 2. If multiple malfunctions are detected including CAN communication line [U1000], perform diagnosis for
CAN communication line first.
Note 3: "ACTUATOR RLY" on the CONSULT-II self-diagnosis results indicates the malfunction of the actuator
motor relay or circuit.
DATA MONITOR
Operation Procedure
1. After turning OFF the ignition switch, connect CONSULT-II and the CONSULT-II CONVERTER to the data
link connector.
LATERAL G-SENSOR
[C1146]Lateral G-sensor is malfunctioning, or signal line of lateral G-sen-
sor is open or shorted.BRC-42, "Ya w R a t e /
Side/Decel G Sensor
System Inspection"
BR FLUID LEVEL LOW
[C1155]Brake fluid level drops or circuit between ABS actuator and elec-
tric unit (control unit) and brake fluid level switch is open or
shorted.BRC-47, "Brake Fluid
Level Sensor System
Inspection"
ENGIN SIGNAL 1
[C1130]Based on the signal from ECM, ABS actuator and electric unit
(control unit) judges that engine fuel cut system is malfunction-
ing.
BRC-39, "
Engine Sys-
tem Inspection"
ENGIN SIGNAL 2
[C1131]Based on the signal from ECM, ABS actuator and electric unit
(control unit) judges that engine fuel cut system is malfunction-
ing.
ENGIN SIGNAL 3
[C1132]Based on the signal from ECM, ABS actuator and electric unit
(control unit) judges that engine fuel cut system is malfunction-
ing.
ENGIN SIGNAL 4
[C1133]Based on the signal from ECM, ABS actuator and electric unit
(control unit) judges that engine fuel cut system is malfunction-
ing.
ENGIN SIGNAL 6
[C1136]Based on the signal from ECM, ABS actuator and electric unit
(control unit) judges that engine fuel cut system is malfunction-
ing.
ACTR RELAY CIRCUIT
[C1140]ABS actuator relay or circuit malfunction.BRC-44, "
Actuator
Motor, Motor Relay, and
Circuit Inspection"
PRESS SENSE CIRCUIT
[C1142]ABS pressure sensor circuit malfunction.BRC-51, "Pressure Sen-
sor System Inspection"
ABS VARIANT CODING
[C1170]V coding is not malfunctioning.BRC-40, "ABS/TCS/
VDC Control Unit
Inspection"
ACTIVE BOOSTER SOLENOID
NG
[C1178]Active booster solenoid is malfunctioning, or signal line of active
booster servo is open or shorted.BRC-49, "Active Booster
System Inspection"
DELTA S SEN NG
[C1179]Delta stroke sensor malfunctioning, or signal line of delta stroke
sensor is open or shorted.BRC-50, "Delta Stroke
Sensor System Inspec-
tion"
ACTIVE BOOSTER RESPONSE
NG
[C1181]Active booster response is malfunctioning, or signal line of active
booster response is open or shorted.BRC-49, "Active Booster
System Inspection"
BRAKE RELEASE SW NG
[C1184]Brake release switch is malfunctioning, or signal line of brake
release switch is open or shorted.
BRC-44, "
Actuator
Motor, Motor Relay, and
Circuit Inspection"
ACC CU INTERNAL NG
[C1185]ICC control unit internal malfunction.
BRAKE BOOSTER DEFECT
[C1189]Brake booster is defective or malfunctioning. Self-diagnostic item Malfunction detecting condition Check system

Page 1044 of 3419

INFINITI QX4 2005 Factory Service Manual TROUBLE DIAGNOSIS
BRC-33
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: October 20052005 QX56
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detec

TROUBLE DIAGNOSIS
BRC-33
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: October 20052005 QX56
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carries out CAN communication.
2. Touch “START (NISSAN BASED VHCL)”, “ABS”, “DATA MONITOR” in order on the CONSULT-II screen.
If “ABS” is not indicated, go to GI-39, "
CONSULT-II Data Link Connector (DLC) Circuit" .
CAUTION:
When “START (NISSAN BASED VHCL)” is touched immediately after starting the engine or turning
on the ignition switch, “ABS” might not be displayed in the system selection screen. In this case,
repeat the operation from step 2.
3. Return to the Monitor Item Selection screen, and touch “ECU INPUT SIGNALS”, “MAIN SIGNALS”, or
“SELECTION FROM MENU”. Refer to the following information.
4. When “START” is touched, the data monitor screen is displayed.
Display Item List
Item
(Unit)Data monitor item selection
Remarks
ECU INPUT
SIGNALSMAIN
SIGNALSSELECTION
FROM MENU
GEAR×××Gear position judged by PNP
switch signal is displayed.
FR RH SENSOR
(km/h, MPH)×××Wheel speed calculated by front
RH wheel sensor signal is dis-
played.
FR LH SENSOR
(km/h, MPH)×××Wheel speed calculated by front LH
wheel sensor signal is displayed.
RR RH SENSOR
(km/h, MPH)×××Wheel speed calculated by rear RH
wheel sensor signal is displayed.
RR LH SENSOR
(km/h, MPH)×××Wheel speed calculated by rear LH
wheel sensor signal is displayed.
BATTERY VOLT
(V)×××Voltage supplied to ABS actuator
and electric unit (control unit) is dis-
played.
N POSI SIG – –×Shift position judged by PNP switch
signal.
P POSI SIG – –×Shift position judged by PNP switch
signal.
ACCEL POS SIG
(%)×–×Throttle valve open/close status
judged by CAN communication sig-
nal is displayed.
ENGINE SPEED
(rpm)×××Engine speed judged by CAN com-
munication signal is displayed.
STR ANGLE SIG
(deg)×–×Steering angle detected by steering
angle sensor is displayed.
YA W R AT E S E N
(d/s)×××Yaw rate detected by yaw rate sen-
sor is displayed.
DECEL G SEN
(d/s)×××Longitudinal acceleration detected
by decel G-sensor is displayed.
SIDE G-SENSOR
(m/s
2 )×– ×Transverse acceleration detected
by side G-sensor is displayed.
STOP LAMP SW
(ON/OFF)×××Stop lamp switch (ON/OFF) status
is displayed.
OFF SW
(ON/OFF) ×× ×VDC OFF switch (ON/OFF) status
is displayed.
ABS WARN LAMP
(ON/OFF)–××ABS warning lamp (ON/OFF) status
is displayed.

Page 1045 of 3419

INFINITI QX4 2005 Factory Service Manual BRC-34
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: October 20052005 QX56
SLIP LAMP
(ON/OFF)–××SLIP indicator lamp (ON/OFF) sta-
tus is displayed.
FR LH IN SOL
(ON/OFF)–××Front LH IN ABS solenoid

BRC-34
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: October 20052005 QX56
SLIP LAMP
(ON/OFF)–××SLIP indicator lamp (ON/OFF) sta-
tus is displayed.
FR LH IN SOL
(ON/OFF)–××Front LH IN ABS solenoid (ON/
OFF) status is displayed.
FR LH OUT SOL
(ON/OFF)–××Front LH OUT ABS solenoid (ON/
OFF) status is displayed.
RR RH IN SOL
(ON/OFF)–××Rear RH IN ABS solenoid (ON/
OFF) status is displayed.
RR RH OUT SOL
(ON/OFF) –××Rear RH OUT ABS solenoid (ON/
OFF) status is displayed.
FR RH IN SOL
(ON/OFF)–××Front RH IN ABS solenoid (ON/
OFF) status is displayed.
FR RH OUT SOL
(ON/OFF)–××Front RH OUT ABS solenoid (ON/
OFF) status is displayed.
RR LH IN SOL
(ON/OFF)–××Rear LH IN ABS solenoid (ON/
OFF) status is displayed.
RR LH OUT SOL
(ON/OFF)–××Rear LH OUT ABS solenoid (ON/
OFF) status is displayed.
OFF LAMP
(ON/OFF)–××OFF Lamp (ON/OFF) status is dis-
played.
MOTOR RELAY
(ON/OFF)–××ABS motor relay signal (ON/OFF)
status is displayed.
ACTUATOR RLY
(ON/OFF)– ××ABS actuator relay signal (ON/
OFF) status is displayed.
CV1
(ON/OFF)––×Front side switch-over solenoid
valve (cut valve) (ON/OFF) status is
displayed.
CV2
(ON/OFF)––×Rear side switch-over solenoid
valve (cut-valve) (ON/OFF) status
is displayed.
SV1
(ON/OFF)––×Front side switch-over solenoid
valve (suction valve) (ON/OFF) sta-
tus is displayed.
SV2
(ON/OFF)––×Rear side switch-over solenoid
valve (suction valve) (ON/OFF) sta-
tus is displayed.
VDC FAIL SIG
(ON/OFF)––×VDC fail signal (ON/OFF) status is
displayed.
TCS FAIL SIG
(ON/OFF)––×TCS fail signal (ON/OFF) status is
displayed.
ABS FAIL SIG
(ON/OFF)––×ABS fail signal (ON/OFF) status is
displayed.
EBD FAIL SIG
(ON/OFF)––×EBD fail signal (ON/OFF) status is
displayed.
FLUID LEV SW
(ON/OFF)×–×Brake fluid level switch (ON/OFF)
status is displayed.
EBD SIGNAL
(ON/OFF)––×EBD operation (ON/OFF) status is
displayed.
ABS SIGNAL
(ON/OFF)––×ABS operation (ON/OFF) status is
displayed.
TCS SIGNAL
(ON/OFF)––×TCS operation (ON/OFF) status is
displayed. Item
(Unit)Data monitor item selection
Remarks
ECU INPUT
SIGNALSMAIN
SIGNALSSELECTION
FROM MENU

Page 1046 of 3419

INFINITI QX4 2005 Factory Service Manual TROUBLE DIAGNOSIS
BRC-35
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: October 20052005 QX56
×: Applicable
–: Not applicableVDC SIGNAL
(ON/OFF)––×VDC operation (ON/OFF) status is
display

TROUBLE DIAGNOSIS
BRC-35
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: October 20052005 QX56
×: Applicable
–: Not applicableVDC SIGNAL
(ON/OFF)––×VDC operation (ON/OFF) status is
displayed.
EBD WARN LAMP – –×Brake warning lamp (ON/OFF) sta-
tus is displayed.
SLCT LVR POSI×××Shift position judged by PNP switch
signal.
R POSI SIG – –×Shift position judged by PNP switch
signal.
4WD FAIL REQ – –×The state of 4WD controller is dis-
played by CAN communication sig-
nal.
2WD/4WD – –×It recognizes on software whether it
is 2WD and whether it is in 4WD
state.
BST OPER SIG – –×Active booster operation (ON/OFF)
status is displayed.
PRESS SENSOR×–×Brake pressure detected by pres-
sure sensor is displayed.
CRANKING SIG – –×The input state of the key SW
START position signal is displayed.
PRESS SEN 2 – –×Brake pressure detected by pres-
sure sensor is displayed.
DELTA S SEN – –×The amount of stroke sensor move-
ments in the active booster
detected by DELTA S SEN is dis-
played.
RELEASE SW NO – –×Release switch signal (ON/OFF)
status is displayed. "ON" indicates
that the brake pedal is depressed.
"OFF" is that the brake pedal is
released.
RELEASE SW NC – –×Release switch signal (ON/OFF)
status is displayed. "OFF" indi-
cates that the brake pedal is
depressed on. "ON" is that the
brake pedal is released.
OHB FAIL – –×OHB fail status is displayed.
HBA FAIL – –×HBA fail status is displayed.
OHB SIG – –×OHB operation (ON/OFF) status is
displayed.
HBA SIG – –×HBA operation (ON/OFF) status is
displayed.
PRES CTRL ACC – –×Pressure control state (ON/OFF) is
displayed. It is applied only to an
ICC vehicle.
PRES FAIL ACC – –×Pressure control fail state (ON/
OFF) is displayed. It is applied only
to an ICC vehicle.
STP OFF RLY – –×Stop lamp relay signal (ON/OFF)
status is displayed. Item
(Unit)Data monitor item selection
Remarks
ECU INPUT
SIGNALSMAIN
SIGNALSSELECTION
FROM MENU

Page 1047 of 3419

INFINITI QX4 2005 Factory Service Manual BRC-36
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: October 20052005 QX56
ACTIVE TEST
CAUTION:
Do not perform active test while driving.
Make sure to completely bleed air from the brake system.
The AB

BRC-36
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: October 20052005 QX56
ACTIVE TEST
CAUTION:
Do not perform active test while driving.
Make sure to completely bleed air from the brake system.
The ABS and brake (EBD) warning lamps turn on during the active test.
Operation Procedure
1. Connect the CONSULT-II and CONSULT-II CONVERTER to the data link connector and start the engine.
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carries out CAN communication.
2. Touch “START (NISSAN BASED VHCL)” on the display screen.
3. Touch “ABS”.
If “ABS” is not indicated, go to GI-39, "
CONSULT-II Data Link Connector (DLC) Circuit" .
4. Touch “ACTIVE TEST”.
5. The test item selection screen is displayed.
6. Touch necessary test item.
7. With the “MAIN SIGNALS” display selected, touch “START”.
8. The Active Test screen will be displayed, so conduct the following test.
Solenoid Valve Operation Chart
*: ON for 1 to 2 seconds after the touch, and then OFF
NOTE:
If active test is performed with brake pedal depressed, pedal stroke may change. This is normal.
“TEST IS STOPPED” is displayed approximately 10 seconds after operation starts.
After “TEST IS STOPPED” is displayed, to perform test again, repeat Step 6.
LBR379
OperationABS solenoid valve ABS solenoid valve (ACT)
UP KEEP DOWN UPACTUA-
TO R U PACTUA-
TOR KEEP
FR RH SOL
FR RH ABS SOLE-
NOID (ACT)FR RH IN SOL OFF ON ON OFF OFF OFF
FR RH OUT SOL OFF OFF ON* OFF OFF OFF
FR LH SOL
FR LH ABS SOLE-
NOID (ACT)FR LH IN SOL OFF ON ON OFF OFF OFF
FR LH OUT SOL OFF OFF ON* OFF OFF OFF
RR RH SOL
RR RH ABS SOLE-
NOID (ACT)RR RH IN SOL OFF ON ON OFF OFF OFF
RR RH OUT SOL OFF OFF ON* OFF OFF OFF
RR LH SOL
RR LH ABS SOLE-
NOID (ACT)RR LH IN SOL OFF ON ON OFF OFF OFF
RR LH OUT SOL OFF OFF ON* OFF OFF OFF
REAR SOLRR RH IN SOL OFF ON ON OFF OFF OFF
RR RH OUT SOL OFF OFF ON* OFF OFF OFF
RR LH IN SOL OFF ON ON OFF OFF OFF
RR LH OUT SOL OFF OFF ON* OFF OFF OFF

Page 1048 of 3419

INFINITI QX4 2005 Factory Service Manual TROUBLE DIAGNOSIS
BRC-37
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: October 20052005 QX56
ABS Motor
Touch “ON” and “OFF” on the screen. Check that ABS motor relay
operates as shown in

Load next 8 pages

Page: < prev 1-10 ... 1009-1016 1017-1024 1025-1032 1033-1040 1041-1048 1049-1056 1057-1064 1065-1072 1073-1080 ... 3424 next >

airbag winter tires checking oil phone reset infotainment system trunk
