Page 1873 of 3419

INFINITI QX4 2005 Factory Service Manual EI-12 CLIP AND FASTENER Revision: October 20052005 QX56 CR103 CS101 CF118 C205 Symbol No.Shapes Removal & Installation SBF768BSBF770B SBF078BSBF992G LIIA1341ELIIA1342E LIIA1344ELIIA1345E

Page 1874 of 3419

INFINITI QX4 2005 Factory Service Manual FRONT BUMPER EI-13 C D E F G H J K L MA B EI Revision: October 20052005 QX56 FRONT BUMPERPFP:F2022 Removal and InstallationEIS004WD 1. Remove side screws from fascia assembly. 2. Remove screws from fr

Page 1875 of 3419

INFINITI QX4 2005 Factory Service Manual EI-14 FRONT BUMPER Revision: October 20052005 QX56 4. Remove fog turn/fog lamp finisher and fog turn/fog lamp. Disconnect harnesses. 5. Remove engine underside cover. 6. Remove fasteners, release cli

Page 1876 of 3419

INFINITI QX4 2005 Factory Service Manual REAR BUMPER EI-15 C D E F G H J K L MA B EI Revision: October 20052005 QX56 REAR BUMPERPFP:H5022 Removal and InstallationEIS004WE WIIA0261E

Page 1877 of 3419

INFINITI QX4 2005 Factory Service Manual EI-16 REAR BUMPER Revision: October 20052005 QX56 1. Remove quarter panel trim covers LH and RH. 2. Disconnect sonar sensor harness connector under rear fascia assembly. 3. Release retainer clips on b

Page 1878 of 3419

INFINITI QX4 2005 Factory Service Manual FRONT GRILLE EI-17 C D E F G H J K L MA B EI Revision: October 20052005 QX56 FRONT GRILLEPFP:62310 Removal and InstallationEIS004WF 1. Remove bolts and nuts attaching grille. 2. Remove grille. Install

Page 1879 of 3419

INFINITI QX4 2005 Factory Service Manual EI-18 COWL TOP Revision: October 20052005 QX56 COWL TOPPFP:66100 Removal and InstallationEIS004WG 1. Remove right and left wiper arms. Refer to WW-31, "Removal and Installation of Front Wiper Arms, Ad

Page 1880 of 3419

INFINITI QX4 2005 Factory Service Manual COWL TOP EI-19 C D E F G H J K L MA B EI Revision: October 20052005 QX56 5. Remove wiper motor and connecting rod linkage. Refer to WW-31, "Removal and Installation of Wiper Motor and Linkage" . 6. Di
