FSU-10
COIL SPRING AND SHOCK ABSORBER
Revision: October 20052005 QX56
COIL SPRING AND SHOCK ABSORBERPFP:56210
Removal and InstallationEES001GK
REMOVAL
1. Remove the wheel and tire using power tool.
2. Remove the shock absorber lower bolt using power tool.
3. Remove the three shock absorber upper mounting nuts using
power tool.
4. Remove the coil spring and shock absorber assembly.
Turn steering knuckle out to gain enough clearance for
removal.
INSTALLATION
Installation is in the reverse order of removal.
The step in the shock absorber assembly lower seat faces outside of vehicle.
Tighten all nuts and bolts to specification. Refer to FSU-5, "Components" .
When installing wheel and tire, refer to WT-7, "Rotation" .
Disassembly and AssemblyEES001GL
DISASSEMBLY
1. Set the shock absorber in a vise, then loosen (without removing)
the piston rod lock nut as shown.
CAUTION:
Do not remove piston rod lock nut at this time.
2. Compress the spring using commercial service tool until the
shock absorber mounting insulator can be turned by hand.
WAR NIN G:
Make sure that the pawls of the two spring compressors are
firmly hooked on the spring. The spring compressors must
be tightened alternately and evenly so as not to tilt the
spring.
3. Remove the piston rod lock nut.
Discard the piston rod lock nut, use a new nut for assembly.
INSPECTION AFTER DISASSEMBLY
Shock Absorber Assembly
Check for smooth operation through a full stroke, both compression and extension.
Check for oil leakage on welded or gland packing portions.
Check piston rod for cracks, deformation or other damage and replace if necessary.
Mounting Insulator and Rubber Parts
Check cemented rubber-to-metal portion for separation or cracks. Check rubber parts for deterioration and
replace if necessary.
LEIA0093E
SSU0 02
SSU0 03
Page 2090 of 3419
COIL SPRING AND SHOCK ABSORBER
FSU-11
C
D
F
G
H
I
J
K
L
MA
B
FSU
Revision: October 20052005 QX56
Coil Spring
Check for cracks, deformation or other damage and replace if necessary.
Check the free spring height.
ASSEMBLY
1. When installing coil spring on shock absorber, it must be posi-
tioned as shown.
2. Install upper mounting insulator as shown in line with lower
shock absorber mount and step in shock absorber lower seat.
The step in the shock absorber lower seat faces outside of
vehicle.
3. Tighten the piston rod lock nut to specification. Refer to FSU-5,
"Components" .
Use a new piston rod lock nut for assembly.Front spring free height
4x2 : 325.5 ± 3 mm (12.8 ± 0.1 in)
4x4 : 335.0 ± 3 mm (13.2 ± 0.1 in)
SFA508A
WEIA0093E
Page 2091 of 3419
FSU-12
STABILIZER BAR
Revision: October 20052005 QX56
STABILIZER BARPFP:54611
Removal and InstallationEES001GM
REMOVAL
1. Remove engine under cover using power tool.
2. Remove stabilizer bar mounting bracket bolts and connecting
rod nuts as shown, using power tool.
3. Remove bushings from stabilizer bar.
INSPECTION AFTER REMOVAL
Check stabilizer bar for twist and deformation. Replace if necessary.
Check rubber bushing for cracks, wear and deterioration. Replace if necessary.
INSTALLATION
Installation is in the reverse order of removal.
Tighten all nuts and bolts to specification. Refer to FSU-5, "Components" .
LEIA0094E
Page 2092 of 3419
UPPER LINK
FSU-13
C
D
F
G
H
I
J
K
L
MA
B
FSU
Revision: October 20052005 QX56
UPPER LINKPFP:54524
Removal and InstallationEES001GN
REMOVAL
1. Remove the wheel and tire using power tool.
2. Remove wheel opening shield.
3. Remove cotter pin and nut from upper link ball joint.
4. Separate upper link ball joint stud from steering knuckle using
Tool.
Support lower link with jack.
5. Remove upper link mounting bolts and nuts.
INSPECTION AFTER REMOVAL
Upper Link
Check for deformation and cracks. Replace if necessary.
Upper Link Ball Joint
Check for distortion and damage. Replace if necessary.
INSTALLATION
Installation is in the reverse order of removal.
Tighten all nuts and bolts to specification. Refer to FSU-5, "Components" .
When installing wheel and tire, refer to WT-7, "Rotation" .
After installation, check that the front wheel alignment is within specification. Refer to FSU-6, "Front
Wheel Alignment" . Tool number : ST29020001 (J24319-01)
LEIA0095E
LEIA0096E
Page 2093 of 3419

FSU-14
LOWER LINK
Revision: October 20052005 QX56
LOWER LINKPFP:55020
Removal and InstallationEES001GO
REMOVAL
1. Remove the wheel and tire using power tool.
2. Remove lower shock absorber bolt.
3. Remove stabilizer bar connecting rod lower nut using power tool, then separate connecting rod from lower
link. Refer to FSU-12, "
Removal and Installation" .
4. Remove drive shaft, if equipped. Refer to FAX-7, "
Removal and Installation" .
5. Remove pinch bolt from steering knuckle using power tool, then
separate lower link ball joint from steering knuckle.
6. Remove lower link adjusting bolts and nuts, then the lower link.
NOTE:
Some vehicles may be equipped with straight (non-adjustable)
lower link bolts and washers. In order to adjust camber and
caster on these vehicles, first replace the lower link bolts and
washers with adjustable (cam) bolts and washers.
INSPECTION AFTER REMOVAL
Lower Link
Check for deformation and cracks. Replace if necessary.
Lower Link Bushing
Check for distortion and damage. Replace if necessary.
INSTALLATION
Installation is in the reverse order of removal.
Tighten all nuts and bolts to specification. Refer to FSU-5, "Components" .
When installing wheel and tire, refer to WT-7, "Rotation" .
After installation, check that the front wheel alignment is within specification. Refer to FSU-6, "Front
Wheel Alignment" .
LEIA0097E
WEIA0079E
Page 2094 of 3419

UPPER BALL JOINT AND LOWER BALL JOINT
FSU-15
C
D
F
G
H
I
J
K
L
MA
B
FSU
Revision: October 20052005 QX56
UPPER BALL JOINT AND LOWER BALL JOINTPFP:40110
Removal and InstallationEES001GP
The ball joints are part of the upper and lower links. Refer to FSU-13, "Removal and Installation" (upper link),
FSU-14, "
Removal and Installation" (lower link).
InspectionEES001GQ
Check the ball joint for excessive play. Replace the upper or lower link assembly if any of the following
exists:
Ball joint stud is worn.
Ball joint is hard to swing.
Ball joint play in axial directions or end play is excessive.
SWINGING FORCE
NOTE:
Before checking the axial forces and end play, turn the lower ball joint at least 10 revolutions so that the ball
joint is properly broken in.
1. Measure the ball joint swinging force using a suitable tool.
Measure at the cotter pin hole for upper ball joint as shown.
Measure at the groove for lower ball joint as shown.
2. Verify the ball joint swinging force is within specification.
TURNING FORCE
Check the turning torque using a suitable tool.
NOTE:
Before checking the axial forces and end play, turn the lower ball
joint at least 10 revolutions so that the ball joint is properly broken in.
WEIA0076E
Swinging force “A”
Upper ball joint : 8.1–103.2 N (0.8–10.5 kg-f,
1.8–23.2 lb-f)
Lower ball joint : 11.4–145.5 N (1.1–14.8 kg-f,
2.5–32.7 lb-f)
SFA858A
Turning torque “B” : 0.5 - 6.4 N·m (0.05 - 0.65 kg-m,
4 - 57 in-lb)
SFA858A
Page 2095 of 3419
FSU-16
UPPER BALL JOINT AND LOWER BALL JOINT
Revision: October 20052005 QX56
VERTICAL END PLAY
Measure the vertical end play using a suitable tool.
Check dust cover for damage. Replace it and the cover clamp if
necessary.
NOTE:
Before checking the axial forces and end play, turn the lower ball
joint at least 10 revolutions so that the ball joint is properly broken in.
Vertical end play “C” : 0 mm (0 in)
SFA858A
Page 2096 of 3419

KNUCKLE
FSU-17
C
D
F
G
H
I
J
K
L
MA
B
FSU
Revision: October 20052005 QX56
KNUCKLEPFP:40014
On-Vehicle Inspection and ServiceEES001GR
Make sure the mounting conditions (looseness, backlash) of each component and component status (wear,
damage) are within specifications. Refer to FSU-21, "
Ball Joint" .
Removal and InstallationEES001GS
REMOVAL
1. Remove wheel and tire from vehicle using power tool.
2. Without disconnecting the hydraulic lines, remove brake caliper using power tool. Reposition it aside with
wire. Refer to BR-21, "
Removal and Installation of Brake Caliper Assembly and Disc Rotor" .
CAUTION:
It is not necessary to remove bolts on torque member and brake hose except for disassembly or
replacement of caliper assembly. In this case, hang cylinder body with a wire so that the brake
hose in not under tension.
NOTE:
Avoid depressing brake pedal while brake caliper is removed.
3. Put alignment marks on disc rotor and wheel hub and bearing
assembly, then remove disc rotor.
4. Remove ABS sensor from steering knuckle. Refer to BRC-64, "
Removal and Installation" .
CAUTION:
Do not pull on ABS sensor harness.
5. Remove cotter pin, then remove lock nut from drive shaft using power tool.
6. Remove steering outer socket cotter pin at steering knuckle, then loosen mounting nut using power tool.
1. Disc rotor 2. Wheel hub and bearing assembly 3. Wheel stud
4. Splash guard 5. Steering knuckle
WDIA0043E
WDIA0044E
