Page 2001 of 3419

INFINITI QX4 2005 Factory Service Manual EM-98Revision: October 2005 CYLINDER BLOCK 2005 QX56 M9 bolt M12 bolt Replace applicable bolts if outside the limit. CONNECTING ROD BOLT DIAMETER Measure diameter "d" at position shown. When “d

Page 2002 of 3419

INFINITI QX4 2005 Factory Service Manual SERVICE DATA AND SPECIFICATIONS (SDS) EM-99 C D E F G H I J K L MA EM Revision: October 20052005 QX56 SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030 Standard and LimitEBS00LMM GENERAL SPECIFICATIONS D

Page 2003 of 3419

INFINITI QX4 2005 Factory Service Manual EM-100Revision: October 2005 SERVICE DATA AND SPECIFICATIONS (SDS) 2005 QX56 CAMSHAFT AND CAMSHAFT BEARING Unit: mm (in) *: Total indicator reading Valve Lifter Unit: mm (in) Valve Clearance Unit: mm

Page 2004 of 3419

INFINITI QX4 2005 Factory Service Manual SERVICE DATA AND SPECIFICATIONS (SDS) EM-101 C D E F G H I J K L MA EM Revision: October 20052005 QX56 Available Valve Lifter Unit: mm (in) Identification (stamped) Mark Thickness N788 7.88 (0.3102) N

Page 2005 of 3419

INFINITI QX4 2005 Factory Service Manual EM-102Revision: October 2005 SERVICE DATA AND SPECIFICATIONS (SDS) 2005 QX56 CYLINDER HEAD Unit: mm (in) Valve Dimensions Unit: mm (in) Items Standard Limit Head surface distortion 0.03 (0.0012) 0.1 (

Page 2006 of 3419

INFINITI QX4 2005 Factory Service Manual SERVICE DATA AND SPECIFICATIONS (SDS) EM-103 C D E F G H I J K L MA EM Revision: October 20052005 QX56 Valve Guide Unit: mm (in) Valve Seat Unit: mm (in) Valve Spring Items Standard Oversize [0.2 (0.0

Page 2007 of 3419

INFINITI QX4 2005 Factory Service Manual EM-104Revision: October 2005 SERVICE DATA AND SPECIFICATIONS (SDS) 2005 QX56 CYLINDER BLOCK Unit: mm (in) Surface flatnessStandard 0.03 (0.0012) LImit 0.1 (0.004) Main bearing housing inside diameter

Page 2008 of 3419

INFINITI QX4 2005 Factory Service Manual SERVICE DATA AND SPECIFICATIONS (SDS) EM-105 C D E F G H I J K L MA EM Revision: October 20052005 QX56 PISTON, PISTON RING AND PISTON PIN Available Piston Unit: mm (in) Piston Ring Unit: mm (in) Pisto
