INFINITI QX4 2005 Factory Service Manual ACC-4Revision: October 2005
SERVICE DATA AND SPECIFICATIONS (SDS)
2005 QX56
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
Accelerator ControlEBS00M40
ADJUSTABLE ACCELERATOR PEDAL
Total Pedal Travel a

Page 10 of 3419

INFINITI QX4 2005 Factory Service Manual ACS-1
AUTO CRUISE CONTROL SYSTEM
K ELECTRICAL
CONTENTS
C
D
E
F
G
H
I
J
L
M
SECTION ACS
A
B
ACS
Revision: October 20052005 QX56
ASCD
AUTOMATIC SPEED CONTROL DEVICE (ASCD) ..... 3
Description .........

ACS-1
AUTO CRUISE CONTROL SYSTEM
K ELECTRICAL
CONTENTS
C
D
E
F
G
H
I
J
L
M
SECTION ACS
A
B
ACS
Revision: October 20052005 QX56
ASCD
AUTOMATIC SPEED CONTROL DEVICE (ASCD) ..... 3
Description ............................................................... 3
ICC
PRECAUTIONS .......................................................... 4
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 4
Precautions for ICC System Service ........................ 4
Wiring Diagrams and Trouble Diagnosis .................. 4
PREPARATION ........................................................... 5
Special Service Tool ................................................. 5
DESCRIPTION ............................................................ 6
Outline ...................................................................... 6
VEHICLE-TO-VEHICLE DISTANCE CONTROL
MODE ................................................................... 6
CONVENTIONAL (FIXED SPEED) CRUISE
CONTROL MODE ................................................. 6
BRAKE ASSIST (WITH PREVIEW FUNCTION) ..... 6
System Diagram ....................................................... 6
Components Description .......................................... 7
CAN Communication ................................................ 7
SYSTEM DESCRIPTION ...................................... 7
Switch Operation ...................................................... 7
ICC System Display ................................................. 8
ACTION TEST ............................................................ 9
ICC System Running Test ........................................ 9
VEHICLE-TO-VEHICLE DISTANCE CONTROL
MODE ................................................................... 9
CONVENTIONAL (FIXED SPEED) CRUISE
CONTROL MODE ............................................... 10
LASER BEAM AIMING ADJUSTMENT ................... 12
Outline of Laser Beam Aiming Adjustment Proce-
dure ........................................................................ 12
Preparation ............................................................. 12
Setting up the ICC Target Board ............................ 12
ADJUSTING HEIGHT OF THE TARGET ............ 12
ADJUSTING THE POSITION OF THE TARGET BOARD STRING ................................................. 13
POSITIONING THE TARGET ............................. 13
Sensor Adjustment ................................................. 14
CHECK AFTER THE ADJUSTMENT .................. 17
ELECTRICAL UNITS LOCATION ............................ 18
Component Parts and Harness Connector Location ... 18
WIRING DIAGRAM ................................................... 19
Schematic ............................................................... 19
Wiring Diagram — ICC — ...................................... 20
TERMINALS AND REFERENCE VALUE ................. 24
Terminals and Reference Values for ICC Unit ........ 24
Terminals and Reference Values for ICC Sensor ... 24
TROUBLE DIAGNOSIS — GENERAL DESCRIP-
TION .......................................................................... 25
Work Flow ............................................................... 25
CONSULT-II Function (ICC) ................................... 26
CONSULT-II OPERATION ................................... 26
WORK SUPPORT ............................................... 27
SELF-DIAGNOSTIC RESULTS ........................... 28
DATA MONITOR ................................................. 28
ACTIVE TEST ..................................................... 29
Self-Diagnostic Function ......................................... 31
WITH CONSULT-II .............................................. 31
WITHOUT CONSULT-II ....................................... 32
SELF-DIAGNOSIS BY ICC SYSTEM DISPLAY
WILL NOT RUN ................................................... 33
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC
ITEMS ........................................................................ 36
Diagnostic Trouble Code (DTC) Chart ................... 36
DTC 11 CONTROL UNIT ....................................... 37
DTC 12 VDC CONTROL UNIT ............................... 37
DTC 20 CAN COMM CIRCUIT ............................... 38
DTC 31 POWER SUPPLY CIR1, DTC 34 POWER
SUPPLY CIR2 ........................................................ 38
DTC 41 VHCL SPEED SE CIRC ............................ 39
DTC 43 VDC/TCS/ABS CIRC ................................ 39
DTC 45 BRAKE SW/STOP L SW ........................... 40
DTC 46 OPERATION SW CIRC ............................. 41
DTC 74 LASER BEAM OFF CNTR ........................ 43
DTC 90 STOP LAMP RLY FIX ............................... 43

Page 11 of 3419

INFINITI QX4 2005 Factory Service Manual ACS-2Revision: October 20052005 QX56 DTC 92 ECM CIRCUIT ........................................... 48
DTC 96 NP RANGE ............................................... 48
DTC 97 AT CIRCUIT ..........

ACS-2Revision: October 20052005 QX56 DTC 92 ECM CIRCUIT ........................................... 48
DTC 96 NP RANGE ............................................... 48
DTC 97 AT CIRCUIT .............................................. 49
DTC 98 GEAR POSITION ...................................... 49
DTC 102 LASER STAIN ......................................... 50
DTC 103 LASER SENSOR FAIL ............................ 51
DTC 104 LASER AIMING INCMP .......................... 51
DTC 107 LASER COMM FAIL ................................ 51
DTC 109 LASER HIGH TEMP ............................... 52
TROUBLE DIAGNOSIS FOR SYMPTOMS .............. 53
Symptom Chart ....................................................... 53
Symptom 1: ON/OFF Switch Does Not Switch ON*
1
, ON/OFF Switch Does Not Switch OFF*
2 .............. 54
Symptom 2: The ICC System Cannot Be Set (ON/
OFF Switch Turns On/Off) ...................................... 54
Symptom 3: The ICC System Cannot Be Operated
by the CANCEL Switch, ACCEL/RES Switch, or
DISTANCE Switch .................................................. 55Symptom 4: The ICC System Is Not Cancelled
When the Gear Is in ‘N’ ...........................................56
Symptom 5: Chime Does Not Sound ......................56
Symptom 6: Driving Force Is Hunting .....................57
Symptom 7: The ICC System Frequently Cannot
Detect the Vehicle Ahead/The Detection Zone is
Short .......................................................................57
Symptom 8: The System Does Not Detect the Vehi-
cle Ahead at All .......................................................57
ELECTRICAL COMPONENT INSPECTION .............59
ICC Steering Switch ................................................59
ICC Brake Switch and Stop Lamp Switch ...............59
Parking Brake Switch ..............................................59
REMOVAL AND INSTALLATION ..............................60
ICC Unit ..................................................................60
ICC Sensor .............................................................60
ICC Steering Switch ................................................60

Page 12 of 3419

INFINITI QX4 2005 Factory Service Manual AUTOMATIC SPEED CONTROL DEVICE (ASCD)
ACS-3
[ASCD]
C
D
E
F
G
H
I
J
L
MA
B
ACS
Revision: October 20052005 QX56
AUTOMATIC SPEED CONTROL DEVICE (ASCD)PFP:18930
DescriptionEKS00BLB
Regarding the informati

Page 13 of 3419

INFINITI QX4 2005 Factory Service Manual ACS-4
[ICC]
PRECAUTIONS
Revision: October 20052005 QX56
PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
EKS00BLC
The Supplemen

ACS-4
[ICC]
PRECAUTIONS
Revision: October 20052005 QX56
PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
EKS00BLC
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WAR NIN G:
To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.
Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.
Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Precautions for ICC System ServiceEKS00BLD
Do not look straight into the laser beam discharger when adjusting laser beam aiming.
Turn the ON/OFF switch OFF during chassis dynamometer testing.
Do not remove, disassemble, or reposition the ICC sensor unless told to do so.
Erase DTC when replacing parts of ICC system, then check the operation of ICC system after adjusting
laser beam aiming if necessary.
Wiring Diagrams and Trouble Diagnosis EKS00BLE
When you read wiring diagrams, refer to the following:
Refer to GI-15, "How to Read Wiring Diagrams" in GI section.
Refer to PG-4, "POWER SUPPLY ROUTING CIRCUIT" for power distribution circuit in PG section.
When you perform trouble diagnosis, refer to the following:
Refer to GI-11, "HOW TO FOLLOW TEST GROUPS IN TROUBLE DIAGNOSES" in GI section.
Refer to GI-27, "How to Perform Efficient Diagnosis for an Electrical Incident" in GI section.

Page 14 of 3419

INFINITI QX4 2005 Factory Service Manual PREPARATION
ACS-5
[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
Revision: October 20052005 QX56
PREPARATIONPFP:00002
Special Service ToolEKS00BLF
The actual shapes of Kent-Moore tools may differ from those of spec

Page 15 of 3419

INFINITI QX4 2005 Factory Service Manual ACS-6
[ICC]
DESCRIPTION
Revision: October 20052005 QX56
DESCRIPTIONPFP:00000
OutlineEKS00BLG
The Intelligent Cruise Control (ICC) system automatically maintains a selected distance from the vehicle
ah

ACS-6
[ICC]
DESCRIPTION
Revision: October 20052005 QX56
DESCRIPTIONPFP:00000
OutlineEKS00BLG
The Intelligent Cruise Control (ICC) system automatically maintains a selected distance from the vehicle
ahead according to that vehicle's speed, or at the set speed, if the road ahead is clear.
The ICC function has two cruise control modes and brake assist (with preview function). The ICC system may
AUTO-CANCEL for various reasons, for example, when the windshield wipers are operating.
VEHICLE-TO-VEHICLE DISTANCE CONTROL MODE
Vehicle-to-vehicle distance control mode, the same speed as other vehicles, can be maintained without the
constant need to adjust the operating speed as with a conventional cruise control system.
The system is intended to enhance the operation of the vehicle when following another vehicle in the same
lane and direction.
If the distance sensor detects a slower moving vehicle ahead, the system will reduce speed so that the vehicle
ahead can be followed at the selected distance.
The system automatically controls the throttle and applies the brakes (up to 25% of vehicle braking power) if
necessary.
The detection range of the sensor is approximately 120 m (390 ft) ahead.
Refer to Owner's Manual for Intelligent Cruise Control System operating instructions.
CONVENTIONAL (FIXED SPEED) CRUISE CONTROL MODE
Conventional (fixed speed) cruise control mode is cruising at preset speeds.
Refer to Owner's Manual for Intelligent Cruise Control System operation instructions.
BRAKE ASSIST (WITH PREVIEW FUNCTION)
When the force applied to brake pedal exceeds a certain level, the brake assist is activated and generates a
greater braking force than that of a conventional brake booster, even with light pedal force.
When the preview function identifies the need to apply the sudden brake by sensing the vehicle ahead in the
same lane and the distance and relative speed from it, it applies the brake pre-pressure before driver
depresses the brake pedal and improves brake response by reducing its free play.
Refer to Owner's Manual for Intelligent Cruise Control System operating instructions.
System DiagramEKS00BLH
WKIA1976E

Page 16 of 3419

INFINITI QX4 2005 Factory Service Manual DESCRIPTION
ACS-7
[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
Revision: October 20052005 QX56
Components DescriptionEKS00BLI
CAN CommunicationEKS00BLJ
SYSTEM DESCRIPTION
Refer to LAN-5, "CAN COMMUNICATION" .
Swi
