Page 2889 of 3419

INFINITI QX4 2005 Factory Service Manual RSU-14
TROUBLE DIAGNOSIS
Revision: October 20052005 QX56
6. Select the required operation from the "SELECT DIAG MODE"
screen.
For further information, see the CONSULT-II Operation Manual.
WORK SUPPORT

RSU-14
TROUBLE DIAGNOSIS
Revision: October 20052005 QX56
6. Select the required operation from the "SELECT DIAG MODE"
screen.
For further information, see the CONSULT-II Operation Manual.
WORK SUPPORT
Operation Procedure
1. Touch “AIR LEVELIZER” on “SELECT SYSTEM” screen.
2. Touch “WORK SUPPORT” on “SELECT DIAG MODE” screen.
3. Touch item on “SELECT WORK ITEM” screen.
4. Touch “START”.
5. The setting will be changed and “ADJUSTMENT COMPLETE” will be displayed.
6. Touch “END”.
Display Item List
SELF-DIAGNOSIS
Description
If an error is detected in the system, perform self-diagnosis as follows:
Operation Procedure
1. Turn ignition switch OFF.
2. Connect CONSULT-II and CONSULT-II CONVERTER to the data link connector.
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carries out CAN communication.
3. Turn ignition switch ON.
4. After stopping the vehicle, with the engine running, touch "START (NISSAN BASED VHCL)", "AIR LEV-
ELIZER", "SELF-DIAG RESULTS" in order on the CONSULT-II screen.
CAUTION:
If "START (NISSAN BASED VHCL)" is touched immediately after starting the engine or turning on
the ignition switch, "AIR LEVELIZER" might not be displayed in the "SELECT SYSTEM" screen. In
this case, repeat the operation from step 1.
5. The self-diagnostic results are displayed. (If necessary, the self-diagnostic results can be printed out by
touching "COPY".)
When "NO DTC IS DETECTED" is displayed, check the CK SUSP indicator lamp.
6. Conduct the appropriate inspection from the display item list, and repair or replace the malfunctioning
component.
7. Start and run the vehicle for approximately 1 minute.
8. Turn ignition switch OFF to prepare for erasing the memory.
9. Start the engine and touch "START (NISSAN BASED VHCL)", "AIR LEVELIZER", "SELF-DIAG
RESULTS", "ERASE" in order on the CONSULT-II screen to erase the error memory.
If "AIR LEVELIZER" is not indicated, go to GI-39, "
CONSULT-II Data Link Connector (DLC) Circuit" .
BCIA0031E
Item Description
STANDARD HEIGHT LEVEL This mode allows the vehicle height to be set to vehicle height specification within tolerance.
ADJUST HEIGHT INI The initialization value and flag can be set in the suspension control unit in this mode.
CLEAR HEIGHT INI This mode clears the initialization flag and value in the suspension control unit.

Page 2890 of 3419

INFINITI QX4 2005 Factory Service Manual TROUBLE DIAGNOSIS
RSU-15
C
D
F
G
H
I
J
K
L
MA
B
RSU
Revision: October 20052005 QX56
CAUTION:
If the error memory is not erased, re-conduct the operation from step 7.
10. For the final inspection, star

TROUBLE DIAGNOSIS
RSU-15
C
D
F
G
H
I
J
K
L
MA
B
RSU
Revision: October 20052005 QX56
CAUTION:
If the error memory is not erased, re-conduct the operation from step 7.
10. For the final inspection, start and run the vehicle for approximately 1 minute and confirm that the CK
SUSP indicator lamp is off.
Display Item List
DATA MONITOR
Operation Procedure
1. After turning OFF the ignition switch, connect CONSULT-II and the CONSULT-II CONVERTER to the data
link connector.
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carries out CAN communication.
2. Touch "START (NISSAN BASED VHCL)", "AIR LEVELIZER", "DATA MONITOR" in order on the CON-
SULT-II screen.
If "AIR LEVELIZER" is not indicated, go to GI-39, "
CONSULT-II Data Link Connector (DLC) Circuit" .
CAUTION:
When "START (NISSAN BASED VHCL)" is touched immediately after starting the engine or turning
on the ignition switch, "AIR LEVELIZER" might not be displayed in the "SELECT SYSTEM" screen.
In this case, repeat the operation from step 2.
3. Return to the "SELECT MONITOR ITEM" screen, and touch "ALL SIGNALS" or "SELECTION FROM
MENU". Refer to the following information.
4. When "START" is touched, the data monitor screen is displayed.
Self-diagnostic item Malfunction detecting condition Check system
Vehicle height sensor
[C1801]Vehicle height sensor voltage is less than 0.2V or greater than
4.8V for more than 60 seconds.Refer to RSU-17, "
Height
Sensor System Inspection" .
Compressor relay
[C1802]1. Driving transistor for compressor relay is off and monitor volt-
age continues high level for more than 10 seconds.
2. Driving transistor for compressor relay is on and monitor volt-
age continues low level for more than 5 seconds.Refer to RSU-20, "
Compres-
sor Motor, Compressor
Motor Relay and Circuit
Inspection" .
Exhaust solenoid
[C1803]1. Driving transistor for exhaust solenoid is off and monitor volt-
age continues high level for more than 10 seconds.
2. Driving transistor for exhaust solenoid is on and monitor volt-
age continues low level for more than 5 seconds.Refer to RSU-19, "
Exhaust
Valve Solenoid System
Inspection" .
Vehicle height adjusting trouble
(compressor)
[C1804]Continuous compressor relay ON time is more than 120 sec-
onds.Refer to RSU-20, "
Compres-
sor Motor, Compressor
Motor Relay and Circuit
Inspection" .
Vehicle height adjusting trouble
(exhaust solenoid)
[C1805]Continuous exhaust solenoid ON time is more than 120 seconds.Refer to RSU-19, "
Exhaust
Valve Solenoid System
Inspection" .
Vehicle height sensor locking trou-
ble
[C1806]Output sensor voltage variation ±0.02V is more than 100 hour
when vehicle height range is normal.Refer to RSU-17, "
Height
Sensor System Inspection" .
Sensor 5V trouble
[C1807]Sensor reference voltage is less than 0.8V or more than 6V for
20 seconds.Refer to RSU-17, "
Height
Sensor System Inspection" .
Integral time trouble by supplying
air
[C1808]Integral discontinuous time on the compressor is more than 180
seconds.Refer to RSU-20, "
Compres-
sor Motor, Compressor
Motor Relay and Circuit
Inspection" .

Page 2891 of 3419

INFINITI QX4 2005 Factory Service Manual RSU-16
TROUBLE DIAGNOSIS
Revision: October 20052005 QX56
Display Item List
X: Applicable
–: Not applicable
ACTIVE TEST
CAUTION:
Do not perform active test while driving.
Operation Procedure
1. Conn

Page 2892 of 3419

INFINITI QX4 2005 Factory Service Manual TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
RSU-17
C
D
F
G
H
I
J
K
L
MA
B
RSU
Revision: October 20052005 QX56
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMSPFP:00000
Height Sensor System InspectionEES001

Page 2893 of 3419

INFINITI QX4 2005 Factory Service Manual RSU-18
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: October 20052005 QX56
4. CHECK HEIGHT SENSOR POWER AND GROUND
1. Reconnect the suspension control unit connector.
2. Turn the ignition swit

Page 2894 of 3419

INFINITI QX4 2005 Factory Service Manual TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
RSU-19
C
D
F
G
H
I
J
K
L
MA
B
RSU
Revision: October 20052005 QX56
Exhaust Valve Solenoid System InspectionEES001HB
INSPECTION PROCEDURE
1. SELF-DIAGNOSIS RE

Page 2895 of 3419

INFINITI QX4 2005 Factory Service Manual RSU-20
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: October 20052005 QX56
5. EXHAUST VALVE SOLENOID INSPECTION
Apply 12V to suspension air compressor C9 terminal 2 and body
ground to suspensi

Page 2896 of 3419

INFINITI QX4 2005 Factory Service Manual TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
RSU-21
C
D
F
G
H
I
J
K
L
MA
B
RSU
Revision: October 20052005 QX56
2. CHECK SYSTEM OPERATION
1. Load vehicle to standard laden condition (with driver, front
