Page 1 of 3419

INFINITI QX4 2005 Factory Service Manual -1QUICK REFERENCE INDEX AGENERAL INFORMATIONGIGeneral InformationBENGINEEMEngine MechanicalLUEngine Lubrication SystemCOEngine Cooling SystemECEngine Control SystemFLFuel SystemEXExhaust SystemACCAcce

Page 2 of 3419

INFINITI QX4 2005 Factory Service Manual QUICK REFERENCE CHART: QX562005

QUICK REFERENCE CHART: QX56PFP:00000
Engine Tune-Up DataELS001U4
Cylinder arrangementV- 8
Displacement
5,552 cm
3 (338.80 in3 )
Bore and stroke98 x 92 mm (3.86 x 3.

Page 3 of 3419

INFINITI QX4 2005 Factory Service Manual 2005
QUICK REFERENCE CHART: QX56

Drive Belt Deflection and Tension
Spark Plugs (Double Platinum Tipped)
Front Wheel Alignment (Unladen*1 )*6ELS001U5
*1: Fuel, radiator coolant and engine oil full. S

2005
QUICK REFERENCE CHART: QX56

Drive Belt Deflection and Tension
Spark Plugs (Double Platinum Tipped)
Front Wheel Alignment (Unladen*1 )*6ELS001U5
*1: Fuel, radiator coolant and engine oil full. Spare tire, jack, hand tools and mats in designated positions.
*2: Target value 37° 31′ (37.52°)
*3: Target value 33° 59′ (33.98°)
*4: Target value 37° 44′ (37.73°)
*5: Target value 33° 29′ (33.48°)
*6: Some vehicles may be equipped with straight (non-adjustable) lower link bolts and washers. In order to adjust camber and caster on
these vehicles, first replace the lower link bolts and washers with adjustable (cam) bolts and washers.Tension of drive belts Auto adjustment by auto tensioner
MakeNGK
Standard typePLFR5A-11
Hot typePLFR4A-11
Cold typePLFR6A-11
Gap (nominal)1.1 mm (0.043 in)
Drive type4x2 4x4
Camber
Degree minute (decimal degree)Minimum -0° 51′ (-0.85°)-0° 33′ (-0.55°)
Nominal -0° 6′ (-0.10°)0° 12′ (0.20°)
Maximum 0° 39′ (0.65°)0° 57′ (0.95°)
Cross camber 0° 45′ (0.75°) or less 0° 45′ (0.75°) or less
Caster
Degree minute (decimal degree)Minimum 3° 15′ (3.25°)2° 45′ (2.75°)
Nominal 4° 0′ (4.00°)3° 30′ (3.50°)
Maximum 4° 45′ (4.75°)4° 15′ (4.25°)
Cross caster 0° 45′ (0.75°) or less 0° 45′ (0.75°) or less
Kingpin inclination
Degree minute (decimal degree)13° 32′ (13.53°)13° 13′ (13.22°)
Total toe-inDistance (A − B)Minimum 1.8 mm (0.07 in) 1.8 mm (0.07 in)
Nominal 2.8 mm (0.11 in) 2.8 mm (0.11 in)
Maximum 3.8 mm (0.15 in) 3.8 mm (0.15 in)
Angle (left side and right side)
Degree minute (decimal degree)Minimum 0° 3′ (0.05°)0° 3′ (0.05°)
Nominal 0° 5′ (0.08°)0° 5′ (0.08°)
Maximum 0° 7′ (0.12°)0° 7′ (0.12°)
Wheel turning angle
(full turn)Inside
Degree minute (decimal degree)34° 31′ – 38° 31′ *2
(34.52° – 38.52°)34° 44′ – 38° 44′ *4
(34.73° – 38.73°)
Outside
Degree minute (decimal degree)30° 59′ – 34° 59′ *3
(30.98° – 34.98°)30° 29′ – 34° 29′ *5
(30.48° – 34.48°)
SFA234AC

Page 4 of 3419

INFINITI QX4 2005 Factory Service Manual QUICK REFERENCE CHART: QX56
2005

Rear Wheel AlignmentELS001U6
BrakeELS001U7
Unit: mm (in) Camber
Degree minute (decimal degree)Minimum 0° 0′ (0°)
Nominal - 0° 30′ (-0.5°)
Maximum - 1° 0′

Page 5 of 3419

INFINITI QX4 2005 Factory Service Manual 2005
QUICK REFERENCE CHART: QX56

Disc Brake - Repair LimitsELS001U8
Unit: mm (in)
Brake PedalELS001U9
Unit: mm (in)
Refill CapacitiesELS001UA
Brake model CLZ31VC (Front) AD14VE (Rear)
Brake PadStand

Page 6 of 3419

INFINITI QX4 2005 Factory Service Manual ACC-1
ACCELERATOR CONTROL SYSTEM
B ENGINE
CONTENTS
C
D
E
F
G
H
I
J
K
L
M
SECTION ACC
A
ACC
Revision: October 20052005 QX56 ACCELERATOR CONTROL SYSTEM ...................... 2
Removal and Installatio

Page 7 of 3419

INFINITI QX4 2005 Factory Service Manual ACC-2Revision: October 2005
ACCELERATOR CONTROL SYSTEM
2005 QX56
ACCELERATOR CONTROL SYSTEMPFP:18005
Removal and InstallationEBS00M3Z
Adjustable Accelerator Pedal
CAUTION:
Do not disassemble the acce

Page 8 of 3419

INFINITI QX4 2005 Factory Service Manual ACCELERATOR CONTROL SYSTEM
ACC-3
C
D
E
F
G
H
I
J
K
L
MA
ACC
Revision: October 20052005 QX56
4. Disconnect the adjustable pedal electric motor electrical connec-
tor.
5. Disconnect the adjustable pedal
