REAR FINAL DRIVE ASSEMBLYPFP:38300
Removal and InstallationEDS003QB
NOTE:
Insert the plastic end of the breather hose into the hole in the suspension member.
Insert the metallic end of the breather hose into the rear final drive cover with the blue paint mark facing
forward.
REMOVAL
1. Remove the rear propeller shaft from the rear final drive. Refer to PR-9, "REMOVAL" .
CAUTION:
Do not impact or damage the rear propeller shaft.
2. Remove the rear stabilizer bar using power tool. Refer to RSU-41, "
REMOVAL" .
3. Remove the spare tire.
4. Disconnect the rear drive shaft from the rear final drive and position it out of the way using a suitable wire.
Refer to RAX-7, "
REMOVAL" .
5. Disconnect the breather hose from the rear final drive cover.
6. Position a suitable jack under the rear final drive case.
CAUTION:
Do not position the jack under the rear final drive cover (aluminum cover).
7. Remove the rear final drive bolts and nuts, and remove the rear final drive using the suitable jack.
1. Breather hose 2. Rear final drive assembly 3. Rear propeller shaft
4. Washer 5. Lower stopper 6. Rear drive shaft
7. Rear final drive assembly 8. Upper stopper
WDIA0190E
Page 2858 of 3419
REAR FINAL DRIVE ASSEMBLY
RFD-11
C
E
F
G
H
I
J
K
L
MA
B
RFD
Revision: October 20052005 QX56
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
After installation, check the final drive oil level. Refer to MA-25, "
Checking Final Drive Oil" .
Page 2859 of 3419
RFD-12
REAR FINAL DRIVE ASSEMBLY
Revision: October 20052005 QX56
ComponentsEDS003QC
R230 2–PINION
WDIA0191E
Page 2860 of 3419

REAR FINAL DRIVE ASSEMBLY
RFD-13
C
E
F
G
H
I
J
K
L
MA
B
RFD
Revision: October 20052005 QX56CAUTION:
Final drive pinion nut torque will be determined when adjusting the total preload. Refer to RFD-13,
"TOTAL PRELOAD" .
Pre-InspectionEDS003QD
Before disassembling the rear final drive, perform the following inspections.
TOTAL PRELOAD
1. Turn the drive pinion in both directions several times to set the
bearing rollers.
2. Check the total preload using Tool.
DRIVE GEAR TO DRIVE PINION BACKLASH
Check the drive gear to drive pinion backlash using a dial gauge at
several points as shown.
DRIVE GEAR RUNOUT
Check the runout of the drive gear using a dial gauge as shown.
1. Drive pinion nut 2. Companion flange 3. Front oil seal
4. Pinion front bearing 5. Pinion bearing adjusting spacer (col-
lapsible spacer)6. Pinion rear bearing
7. Pinion height adjusting washer 8. Drive pinion 9. Gear carrier
10. Drive gear 11. Pinion mate shaft 12. Lock pin
13. Pinion mate gear 14. Pinion mate thrust washer 15. Side gear
16. Side gear thrust washer 17. Differential case 18. Side bearing
19. Side bearing adjusting washer 20. Bearing cap 21. Rear cover
22. Filler plug 23. Drain plug 24. Side oil seal
Tool number : ST3127S000
Total preload : 2.05 - 4.11 N·m (0.21 - 0.42 kg-m,
19 - 36 in-lb)
SPD8 84
Drive gear to drive pinion backlash : 0.13 - 0.18 mm
(0.0051 - 0.0070 in)
SPD5 13
Runout limit : 0.05 mm (0.0020 in) or less
SPD8 86
Page 2861 of 3419

RFD-14
REAR FINAL DRIVE ASSEMBLY
Revision: October 20052005 QX56
COMPANION FLANGE RUNOUT
Mount the dial gauge indicator so the dial gauge needle is positioned
on the propeller shaft mounting surface. Rotate the companion
flange and measure the runout as shown.
If runout is not within specification, remove the companion
flange, rotate 90° in relation to the drive pinion, and install the
companion flange using a new drive pinion nut. Tighten the drive
pinion nut to the minimum specified torque. Final drive pinion nut
torque will be determined when adjusting the total preload. Refer
to RFD-13, "
TOTAL PRELOAD" .
CAUTION:
The drive pinion nut is not reusable. Use a new drive pinion nut for installation.
If runout is not within specification after rotating the companion flange 90° on the drive pinion, replace the
companion flange. Recheck the companion flange runout.
If the new companion flange runout is not within specification, inspect the drive pinion bearing and the
drive pinion. Repair as necessary.
CAUTION:
Clean all of the rust and dirt off of the companion flange surface before measuring the companion
flange runout.
TOOTH CONTACT
Check the tooth contact. Refer to RFD-14, "TOOTH CONTACT" .
Disassembly and AssemblyEDS003QE
REMOVAL OF DIFFERENTIAL CASE ASSEMBLY
1. Use two 45 mm (1.77 in) spacers to mount the gear carrier on
Tool.
2. For installation, paint match marks on one side of the bearing
caps as shown.
NOTE:
Bearing caps are line-bored for initial assembly. Replace the
bearing caps in their original positions.Companion flange runout : 0.08 mm (0.003 in) or less
Tool number : KV40104000
Drive pinion nut : 167 - 372 N·m (17 - 38 kg-m,
124 - 274 ft-lb)
WDIA0062E
Tool number : KV38100800
SPD8 88
SPD8 89
Page 2862 of 3419
REAR FINAL DRIVE ASSEMBLY
RFD-15
C
E
F
G
H
I
J
K
L
MA
B
RFD
Revision: October 20052005 QX56
3. Remove the bearing caps.
4. Lift the differential case assembly out of the gear carrier using
Tool.
Keep the side bearing outer races together with the inner
races. Do not mix them up.
Keep the adjusting washers together with the bearings.
REMOVAL OF DRIVE PINION ASSEMBLY
1. Apply match marks on the companion flange and drive pinion
using paint.
2. Loosen the drive pinion nut using Tool as shown.
Discard the drive pinion nut and use a new drive pinion nut for
installation.
S-PD3 43
Tool number : HT72400000
S-PD3 44
SPD9 19
Tool number : KV40104000
SDIA11 44 E
Page 2863 of 3419
RFD-16
REAR FINAL DRIVE ASSEMBLY
Revision: October 20052005 QX56
3. Remove the drive pinion together with the rear bearing inner
race and the bearing adjusting spacer.
4. Remove the front oil seal. Refer to RFD-6, "
Removal and Instal-
lation" .
5. Remove the pinion front bearing inner race.
6. Remove the side oil seal. Refer toRFD-8, "
Removal and Installa-
tion" .
7. Remove the pinion bearing outer races using a suitable brass
drift.
8. Remove the pinion rear bearing inner race and the drive pinion
height adjusting washer using Tool.
SPD8 92
SDIA0817E
Tool number: : ST30021000
S-PD1 79
Page 2864 of 3419
REAR FINAL DRIVE ASSEMBLY
RFD-17
C
E
F
G
H
I
J
K
L
MA
B
RFD
Revision: October 20052005 QX56
DISASSEMBLY OF DIFFERENTIAL CASE ASSEMBLY
1. Remove the side bearing inner races using Tools.
CAUTION:
To prevent damage to the bearing, engage the puller jaws in
the groove.
Do not to mix the left and right side parts, clearly label the
parts during disassembly.
2. Loosen the drive gear bolts in a criss-cross pattern and remove
the bolts.
3. Tap the drive gear off the differential case using a soft hammer.
Tap evenly all around the drive gear to keep the drive gear
from binding.Tool number A: ST3306S001
B: ST33061000
SPD9 20
SPD0 22
SPD0 24
