Page 297 of 3419
AT-226
A/T SHIFT LOCK SYSTEM
Revision: October 20052005 QX56
Key unlock
Check operation by applying battery voltage to key switch and
key lock solenoid.
CAUTION:
Be careful not to cause burnout of the harness.
KEY SWITCH
Check continuity between terminals of the key switch and key
lock solenoid.
STOP LAMP SWITCH
Check continuity between terminals of the stop lamp switch har-
ness connector.
Check stop lamp switch after adjusting brake pedal.
Connector No. Terminal No.
M27 2 (Battery voltage) - 1 (Ground)
WCIA0241E
Condition Connector No. Terminal No. Continuity
Key inserted
M27 3 - 4Ye s
Key withdrawn No
SCIA5662E
ConditionConnector
No.Terminal No. Continuity
When brake pedal is depressed
E38 1 -2Ye s
When brake pedal is released No
SCIA2045E
Page 298 of 3419
SHIFT CONTROL SYSTEM
AT-227
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: October 20052005 QX56
SHIFT CONTROL SYSTEMPFP:34901
Control Device Removal and InstallationECS00CKT
1. Select lever knob 2. A/T console finisher 3. Control device assembly
4. Position lamp 5. A/T selector control cable 6. Lock plate
LCIA0348E
Page 299 of 3419

AT-228
SHIFT CONTROL SYSTEM
Revision: October 20052005 QX56
REMOVAL
1. Remove A/T finisher.
Refer to IP-13, "A/T Finisher" .
2. Disconnect selector control cable.
3. Disconnect A/T device harness connector.
4. Remove control device assembly.
INSTALLATION
Installation is in reverse order of removal. Be careful of the following:
After installation is completed, adjust and check A/T position.
Adjustment of A/T PositionECS00CKU
1. Loosen nut of control cable.
2. Place PNP switch and selector lever in “P” position.
3. After pushing the control cable in the direction shown with a
force of 9.8 N·m (1kg-m, 2.2 lb-ft), release it. This is in the natu-
ral state, tighten control cable nut to specifications.
Checking of A/T PositionECS00CKV
1. Place selector lever in “P” position, and turn ignition switch ON
(engine stop).
2. Make sure selector lever can be shifted to other than “P” posi-
tion when brake pedal is depressed. Also make sure selector
lever can be shifted from “P” position only when brake pedal is
depressed.
3. Move the selector lever and check for excessive effort, sticking,
noise or rattle.
4. Confirm the selector lever stops at each position with the feel of
engagement when it is moved through all the positions. Check
whether or not the actual position the selector lever is in
matches the position shown by the shift position indicator and
the transmission body.
5. The method of operating the lever to individual positions correctly should be as shown.
6. Confirm the back-up lamps illuminate only when lever is placed in the “R” position. Confirm the back-up
lamps does not illuminate when selector lever is pushed against “R” position in the “P” or “N” position.
7. Confirm the engine can only be started with the selector lever in the “P” and “N” positions.
8. Make sure transmission is locked completely in “P” position.Control cable nut : 14.5 N·m (1.5 kg-m, 11 ft-lb)
LCIA0345E
LCIA0325E
Page 300 of 3419
ON-VEHICLE SERVICE
AT-229
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: October 20052005 QX56
ON-VEHICLE SERVICEPFP:00000
Oil PanECS00CKW
REMOVAL AND INSTALLATION
Removal
1. Drain A/T fluid, refer to MA-24, "Changing A/T Fluid" .
2. Remove oil pan and gasket.
3. Check foreign materials in oil pan to help determine cause of malfunction. If the A/T fluid is very dark, has
some burned smell, or contains foreign particles, friction material (clutches, band) may need replacement.
A tacky film that will not wipe clean indicates varnish build up. Varnish can cause valves, servo, and
clutches to stick and can inhibit pump pressure.
CAUTION:
If friction material is detected, flush the transmission cooler after repair, refer to AT- 1 3 , "
A/T FLUID
COOLER CLEANING PROCEDURE" .
4. Remove magnets from oil pan.
Installation
1. Install the oil pan magnets as shown.
SCIA2308E
SCIA5200E
SCIA5200E
Page 301 of 3419
AT-230
ON-VEHICLE SERVICE
Revision: October 20052005 QX56
2. Install the oil pan and new oil pan gasket.
CAUTION:
Be sure the oil pan drain plug is located to the rear of the
transmission assembly.
Before installing oil pan bolts, remove any traces of old
sealant from the sealing surfaces and threaded holes.
Do not reuse old gasket, replace with a new one.
Always replace the oil pan bolts as they are self-sealing.
Partially install the oil pan bolts in a criss-cross pattern to
prevent dislocation of the gasket.
3. Tighten oil pan bolts in numerical order as shown.
4. Install drain plug in oil pan.
CAUTION:
Do not reuse old drain plug gasket replace with a new one.
5. Refill the transmission assembly with fluid. Refer to MA-24, "
Changing A/T Fluid" .
SCIA2308E
Oil pan bolts : 7.9 N·m (0.81 kg-m, 70 in-lb)
SCIA4 113 E
Drain plug : 34 N·m (3.5 kg-m, 25 ft-lb)
Page 302 of 3419
ON-VEHICLE SERVICE
AT-231
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: October 20052005 QX56
Control Valve With TCM and A/T Fluid Temperature Sensor 2ECS00CKX
COMPONENTS
1. Transmission 2. Snap ring 3. Sub-harness
4. Control valve with TCM 5. Bracket 6. A/T fluid temperature sensor 2
7. Oil pan gasket 8. Oil pan 9. Magnet
10. Drain plug 11. Drain plug gasket 12. Oil pan bolt
13. Terminal cord assembly 14. O-ring
SCIA5478E
Page 303 of 3419
AT-232
ON-VEHICLE SERVICE
Revision: October 20052005 QX56
CONTROL VALVE WITH TCM REMOVAL AND INSTALLATION
Removal
1. Disconnect negative battery terminal
2. Drain ATF through drain plug.
3. Disconnect A/T assembly harness connector.
4. Remove snap ring from A/T assembly harness connector.
5. Push A/T assembly harness connector.
CAUTION:
Be careful not to damage connector.
6. Remove oil pan and oil pan gasket, refer to AT-229, "
Removal" .
7. Disconnect A/T fluid temperature sensor 2 connector.
CAUTION:
Be careful not to damage connector.
8. Straighten terminal clip to free terminal cord assembly A/T fluid
temperature sensor 2 harness.
SCIA5021E
SCIA5022E
SCIA5023E
SCIA5446E
Page 304 of 3419
ON-VEHICLE SERVICE
AT-233
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: October 20052005 QX56
9. Disconnect revolution sensor connector.
CAUTION:
Be careful not to damage connector.
10. Straighten terminal clips to free revolution sensor harness.
11. Remove bolts A, B and C from control valve with TCM.
12. Remove control valve with TCM from transmission case.
CAUTION:
When removing, be careful with the manual valve notch and
manual plate height. Remove it vertically.
13. Remove A/T fluid temperature sensor 2 with bracket from con-
trol valve with TCM.
SCIA5024E
SCIA3969E
Bolt symbol Length mm (in) Number of bolts
A 42 (1.65) 5
B 55 (2.17) 6
C 40 (1.57) 1
SCIA5139E
SCIA5142E
SCIA5301E
