Page 1289 of 3342

SUBARU LEGACY 1997 Service Repair Manual B: SERVICE DATA ITEM STANDARD SERVICE LIMIT Front brakePad thickness (including back metal)17 mm (0.67 in) 7.5 mm (0.295 in) Disc thickness 24 mm (0.94 in) 22 mm (0.87 in) Disc runout—0.075 mm (0.00

Page 1290 of 3342

SUBARU LEGACY 1997 Service Repair Manual 1. Front Disc Brake 1. EXCEPT 2500 cc MODEL B4M1152A 1Caliper body  2Air bleeder screw  3Guide pin (Green)  4Pin boot  5Piston seal  6Piston  7Piston boot  8Lock pin (Yellow) 9Support  10Pad

Page 1291 of 3342

SUBARU LEGACY 1997 Service Repair Manual 2. 2500 cc MODEL B4M1151A 1Caliper body  2Air bleeder screw  3Guide pin (Green)  4Pin boot  5Piston seal  6Piston  7Piston boot  8Boot ring  9Lock pin (Yellow) 10Support  11Pad clip  12Out

Page 1292 of 3342

SUBARU LEGACY 1997 Service Repair Manual 2. Rear Disc Brake B4M0066A 1Lock pin  2Lock pin sleeve  3Lock pin boot  4Air bleeder screw  5Caliper body  6Guide pin  7Guide pin boot  8Piston seal  9Piston  10Piston boot  11Boot ring

Page 1293 of 3342

SUBARU LEGACY 1997 Service Repair Manual 3. Rear Drum Brake G4M0910 1Air bleeder cap  2Air bleeder screw  3Boot  4Piston  5Cup  6Spring  7Wheel cylinder body  8Pin  9Plug  10Back plate 11Upper shoe return spring  12Retainer  13W

Page 1294 of 3342

SUBARU LEGACY 1997 Service Repair Manual 4. Master Cylinder 1. WITHOUT TCS B4M0067A 1Cap  2Reserve tank  3Seal  4Cylinder body  5Secondary piston  6Primary piston 7C-ring  8Level indicator ASSY  9Supply valve stopper (With ABS)  10

Page 1295 of 3342

SUBARU LEGACY 1997 Service Repair Manual 3. RHD MODEL B4M1199A 1Cap  2Filter  3Reservoir tank  4Bracket  5Piston retainer  6Primary piston 7Secondary piston  8Cylinder body  9Seal  10Pin Tightening torque: N⋅m (kg-m, ft-lb) T1: 1

Page 1296 of 3342

SUBARU LEGACY 1997 Service Repair Manual 5. Brake Booster 1. MODELS WITH ABS AND TCS G4M0355 1Push rod  2Return spring  3Reaction disc  4Key 5Filter  6Silencer  7Operating rod  8Poppet valve 9Valve body  10Plunger valve  11Diaphra
