Page 1049 of 3342

SUBARU LEGACY 1997 Service Repair Manual G3M0026 11) Install the extension cap to transmission. G3M0027 C: DISASSEMBLY Before removing center bearing, check its condition. If it does not operate smoothly or if there is any free play or leaka

Page 1050 of 3342

SUBARU LEGACY 1997 Service Repair Manual G3M0031 5) Lightly tap the head of front propeller shaft with a cop- per hammer until center bearing is removed. CAUTION: Be careful not to damage the thread portion. D: INSPECTION NOTE: Do not disass

Page 1051 of 3342

SUBARU LEGACY 1997 Service Repair Manual G3M0027 4) Align matching marks and connect front and rear pro- peller shafts. Tightening torque: 27.9±4.4 N⋅m (2.85±0.45 kg-m, 20.6±3.3 ft-lb) G3M0024 F: INSTALLATION 1) Insert sleeve yoke into

Page 1052 of 3342

SUBARU LEGACY 1997 Service Repair Manual 2. Rear Differential A: ON-CAR SERVICE 1. FRONT OIL SEAL 1) Disconnect ground cable from battery. 2) Move selector lever or gear shift lever to“N”. 3) Release the parking brake. B3M0316A 4) Remove

Page 1053 of 3342

SUBARU LEGACY 1997 Service Repair Manual G3M0036 9) Remove oil seal using ST. ST 499705401 PULLER ASSY G3M0037 10) Fit a new oil seal using ST. ST 498447120 OIL SEAL INSTALLER G3M0034 11) Install companion flange. 12) Tighten self-locking nu

Page 1054 of 3342

SUBARU LEGACY 1997 Service Repair Manual 2. SIDE OIL SEAL 1) Disconnect ground cable from battery. 2) Move selector lever or gear shift lever to“N”. 3) Release the parking brake. 4) Loosen both wheel nuts. 5) Jack-up the vehicle and supp

Page 1055 of 3342

SUBARU LEGACY 1997 Service Repair Manual G3M0042 (5) Remove the bolts which secure the trailing link to the rear housing. G3M0043 (6) Remove the bolts which secure the front and rear lateral link to the rear housing. G3M1020 (7) Remove cross

Page 1056 of 3342

SUBARU LEGACY 1997 Service Repair Manual G3M1023 10) Remove side oil seal with ST. ST 398527700 PULLER ASSY G3M1024 11) Drive in a new side oil seal with ST. CAUTION: Apply chassis grease between the oil seal lips. ST 398437700 DRIFT G3M1025
