SUBARU LEGACY 1997 Service Repair Manual B2M0755 10CJ2 CHECK PRESSURE SENSOR. 1) Measure actual atmospheric pressure. 2) Read data on Subaru Select Monitor or OBD-II general scan tool. Subaru Select Monitor Designate mode using function key

Page 2218 of 3342

SUBARU LEGACY 1997 Service Repair Manual B2M1270B OBD0005B 10CJ4CHECK PRESSURE SOURCES SWITCH- ING SOLENOID VALVE. 1) Turn ignition switch to OFF. 2) Connect test mode connector. 3) Turn ignition switch to ON. : Does pressure sources switchi

Page 2219 of 3342

SUBARU LEGACY 1997 Service Repair Manual B2M1129 CK: DTC P1144 —PRESSURE SENSOR CIRCUIT RANGE/PERFORMANCE PROBLEM (HIGH INPUT)— DTC DETECTING CONDITION: Two consecutive driving cycles with fault WIRING DIAGRAM: B2M1308 CAUTION: After re

Page 2220 of 3342

SUBARU LEGACY 1997 Service Repair Manual OBD0145A 10CK1 CHECK DATA FOR CONTROL. 1) Turn ignition switch to OFF. 2) Connect Subaru Select Monitor or the OBD-II general scan tool to data link connector. 3) Turn ignition switch ON and Subaru Se

Page 2221 of 3342

SUBARU LEGACY 1997 Service Repair Manual B2M1130 CL: DTC P1400 —FUEL TANK PRESSURE CONTROL SOLENOID VALVE CIRCUIT LOW INPUT— DTC DETECTING CONDITION: Two consecutive driving cycles with fault WIRING DIAGRAM: B2M0928 CAUTION: After repai

Page 2222 of 3342

SUBARU LEGACY 1997 Service Repair Manual H2M1408B 10CL1 CHECK OUTPUT SIGNAL FROM ECM. 1) Turn ignition switch to ON. 2) Measure voltage between ECM and chassis ground. : Connector & terminal (B84) No. 10 (+)—Chassis ground (�): Is the volt

Page 2223 of 3342

SUBARU LEGACY 1997 Service Repair Manual B2M0931A 4) Measure resistance of harness between ECM and fuel tank pressure control solenoid valve connector. : Connector & terminal (B84) No. 10—(R68) No. 2: Is the voltage less than 1Ω? : Go to

Page 2224 of 3342

SUBARU LEGACY 1997 Service Repair Manual B2M0932A 10CL4CHECK POWER SUPPLY TO FUEL TANK PRESSURE CONTROL SOLENOID VA LV E . 1) Turn ignition switch to ON. 2) Measure voltage between fuel tank pressure control solenoid valve and chassis ground
