Page 601 of 3342

SUBARU LEGACY 1997 Service Repair Manual B2M0020AB2M0019A B2M0021CB2M1291A 13 2-11SERVICE PROCEDURE 2. Engine

Page 602 of 3342

SUBARU LEGACY 1997 Service Repair Manual (2) Disconnect the following cables.  1Clutch release spring (MT model except 2500 cc)  2Clutch cable (MT model except 2500 cc)  3Accelerator cable  4Cruise control cable (With cruise control) B2M

Page 603 of 3342

SUBARU LEGACY 1997 Service Repair Manual (3) Disconnect the following hoses.  1Brake booster vacuum hose  2Heater inlet and outlet hoses B2M1169C B2M0026AB2M0027 15 2-11SERVICE PROCEDURE 2. Engine

Page 604 of 3342

SUBARU LEGACY 1997 Service Repair Manual G2M0286 11) Remove power steering pump from bracket. (1) Loosen lock bolt and slider bolt, and remove front side V-belt. B2M0340 (2) Remove pipe with bracket from intake manifold. B2M0334 (3) Remove b

Page 605 of 3342

SUBARU LEGACY 1997 Service Repair Manual B2M0335 (3) Disconnect connector from rear oxygen sensor. G2M0291 (4) Separate center exhaust pipe from rear exhaust pipe. B2M0313 (5) Remove bolt which installs center exhaust pipe on hunger bracket.

Page 606 of 3342

SUBARU LEGACY 1997 Service Repair Manual G2M0294 15) Separate torque converter from drive plate. (AT model) (1) Lower the vehicle. (2) Remove service hole plug. (3) Remove bolts which hold torque converter to drive plate. (4) Remove other bo

Page 607 of 3342

SUBARU LEGACY 1997 Service Repair Manual G2M0299 20) Remove bolts which hold upper side of transmission to engine. G2M0300 21) Remove engine from vehicle. (1) Slightly raise engine. (2) Raise transmission with garage jack. (3) Move engine ho

Page 608 of 3342

SUBARU LEGACY 1997 Service Repair Manual B: INSTALLATION 1. Install engine to transmission. 2. Tighten bolts which hold upper side of transmission to engine. 3. Remove lifting device and wire rope. 4. Remove garage jack. 5. Install pitching
