Page 1505 of 3342

SUBARU LEGACY 1997 Service Repair Manual EPA0111
48
4-7DIAGNOSTICS
5. Compressor Clutch Diagnosis

Page 1506 of 3342

SUBARU LEGACY 1997 Service Repair Manual 6. Radiator Fan (Main Fan) Diagnosis
EPA0048
49
4-7DIAGNOSTICS
6. Radiator Fan (Main Fan) Diagnosis

Page 1507 of 3342

SUBARU LEGACY 1997 Service Repair Manual 7. Condenser Fan (Sub Fan)
Diagnosis (I)
50
4-7DIAGNOSTICS
7. Condenser Fan (Sub Fan) Diagnosis (I)

Page 1508 of 3342

SUBARU LEGACY 1997 Service Repair Manual 8. Condenser Fan (Sub Fan)
Diagnosis (II)
51
4-7DIAGNOSTICS
8. Condenser Fan (Sub Fan) Diagnosis (II)

Page 1509 of 3342

SUBARU LEGACY 1997 Service Repair Manual 1. Supplemental Restraint System
“Airbag”
Airbag system wiring harness is routed on and along body
panels.
CAUTION:
All Airbag system wiring harness and connectors
are colored yellow. Do not use

Page 1510 of 3342

Page 1511 of 3342

SUBARU LEGACY 1997 Service Repair Manual 1. ENGINE COMPARTMENT AND ROOM
B5M0187A
0Cowl panel weather attaching hole 6 mm (0.24 in) dia.

1Hood hinge front attaching hole M8

2Strut mount attaching hole (Front center) 9.5 mm (0.374 in)
dia

1. ENGINE COMPARTMENT AND ROOM
B5M0187A
0Cowl panel weather attaching hole 6 mm (0.24 in) dia.

1Hood hinge front attaching hole M8

2Strut mount attaching hole (Front center) 9.5 mm (0.374 in)
dia.

3Front fender attaching hole (Tip) M6

4Rear upper surface of front side frame 12 mm (0.47 in) dia.

5Middle upper surface of front side frame 20 mm (0.79 in) dia.

6Front side frame front upper surface 14 x 16 mm (0.55 x 0.63
in) dia. oblong hole

7Side frame of front side frame 12 mm (0.47 in) dia.

8Headlight attaching hole at radiator side panel 6.2x9mm
(0.244 x 0.35 in) dia.

9Radiator panel side (LWR) gauge hole 23 mm (0.91 in) dia.

23Rear strut mount attaching hole (Side) 10 mm (0.39 in) dia.

24Rear strut mount attaching hole (Center) 12 mm (0.47 in) dia.

25Radiator panel (UPR) middle hole 6 mm (0.24 in) dia.

26Front fender attaching hole at radiator panel side M6

27Front fender attaching hole at front pillar lower portion M6

28Hinge middle hole at front pillar center 10 mm (0.39 in) dia.

29Front fender attaching hole at front pillar center portion M6

30Retainer attaching square hole at front pillar7x7mm(0.28
x 0.28 in)
31Retainer attaching hole at center pillar (Front) 3.5 mm (0.138
in) dia.

32Retainer attaching hole at center pillar (Rear) 3.5 mm (0.138
in) dia.

33Lower side of rear door hinge M8

34Center pillar (LWR) gauge hole 27 mm (1.06 in) dia.

35Rear quarter outer corner patch attaching hole 5.2 mm (0.205
in) dia.

39Front rail center notch

40Front glass upper locating notch RH: 6.5 mm (0.256 in) dia.,
LH: 6.5 x 10 mm (0.256 x 0.39 in) dia. oblong hole

41Stud bolt lower locating notch

48Front center of rear floor pan 8 mm (0.31 in) dia.

51Front upper pillar (Inner) 7 mm (0.28 in) dia.

52Front seat belt adjust plate attaching hole 12 mm (0.47 in)
dia.

53Rear door hinge middle hole 10 mm (0.39 in) dia.

54Rear floor, near door 8 mm (0.31 in) dia.

55Trim upper attaching hole at 6 light 8 mm (0.31 in) dia.

56Trim lower attaching hole at 6 light 8 mm (0.31 in) dia.

58Rear floor, near floor strut 15 x 20 mm (0.59 x 0.79 in) dia.
oblong hole
3
5-1SERVICE DATA
2. Body Datum Points

Page 1512 of 3342

SUBARU LEGACY 1997 Service Repair Manual 2. LUGGAGE COMPARTMENT AND ROOM (SEDAN)
B5M0188A
366 light upper retainer attaching square hole7x7mm(0.28 x 0.28 in)

42Rear rail center notch

43Rear glass upper locating hole RH: 6.5 mm (0.256 in
