Page 3161 of 3342

SUBARU LEGACY 1997 Service Repair Manual G6M0181 1. CHECK FUSE AND POWER SUPPLY. 1) Check fuse No. 18. 2) Turn ignition switch to ON. 3) Measure voltage between fuse box connector and body. Connector & terminal / Specified voltage: (B51) No.

Page 3162 of 3342

SUBARU LEGACY 1997 Service Repair Manual 8. Diagnostics Chart with Trouble Code A: TROUBLE CODE Trouble code Item Contents of diagnosis Page 10 OK Normal 18 11 BRAKE/ST/CL or NInput signals from brake switch“OFF”, stop light switch“ON

Page 3163 of 3342

SUBARU LEGACY 1997 Service Repair Manual B: TROUBLE CODE 10 —NORMAL CONDITION— DIAGNOSIS: SET/COAST switch or disconnection of the wiring or short circuit. RESUME/ACCEL switch or disconnection of the wiring or short circuit. TROUBLE SY

Page 3164 of 3342

SUBARU LEGACY 1997 Service Repair Manual LED No. Signal name Display 1 SET/COAST switch SE 2 RESUME/ACCEL switch RE 3 Stop light switch ST 4Brake switch Clutch switch (MT)BR 5 Inhibitor switch (AT) N 6—— 7—— 8—— 9—— 10—

Page 3165 of 3342

SUBARU LEGACY 1997 Service Repair Manual B6M0244 C: TROUBLE CODE 11 —BRAKE SWITCH, STOP LIGHT SWITCH, CLUTCH SWITCH, INHIBITOR SWITCH— DIAGNOSIS: Failure or disconnection of the stop light switch and brake switch. Failure or disconnect

Page 3166 of 3342

SUBARU LEGACY 1997 Service Repair Manual LED No. Signal name Display 1 SET/COAST switch SE 2 RESUME/ACCEL switch RE 3 Stop light switch ST 4Brake switch Clutch switch (MT)BR 5 Inhibitor switch (AT) N 6—— 7—— 8—— 9—— 10—

Page 3167 of 3342

SUBARU LEGACY 1997 Service Repair Manual B6M0242 4. CHECK INHIBITOR SWITCH. (AT MODEL) 1) Set the selector lever to N position. 2) Disconnect connector of inhibitor switch. 3) Check continuity of the inhibitor switch. Terminals / Specified r

Page 3168 of 3342

SUBARU LEGACY 1997 Service Repair Manual B6M0191 D: TROUBLE CODE 12, 13 AND 21 —VEHICLE SPEED SENSOR 2 SYSTEM— DIAGNOSIS: Disconnection or short circuit of vehicle speed sensor 2 system. TROUBLE SYMPTOM: Cruise control cannot be set. (
