SUBARU LEGACY 1997 Service Repair Manual B4M0808 10AF3 CHECK MOTOR GROUND. : Tightening torque: 32±10 N⋅m (3.3±1.0 kg-m, 24±7 ft-lb) Is the motor ground terminal tightly clamped? : Go to step10AF4. : Tighten the clamp of motor ground te

Page 2850 of 3342

SUBARU LEGACY 1997 Service Repair Manual 10AF6 CHECK ABSCM. 1) Connect all connectors. 2) Erase the memory. 3) Perform inspection mode. 4) Read out the trouble code. : Is the same trouble code as in the current diagnosis still being output?

Page 2851 of 3342

SUBARU LEGACY 1997 Service Repair Manual B4M0972 AG: 54 BLS —ABNORMAL STOP LIGHT SWITCH— DIAGNOSIS: Faulty stop light switch TROUBLE SYMPTOM: ABS does not operate. 10AG1.Check output of stop light switch using select monitor.  10AG2.C

Page 2852 of 3342

SUBARU LEGACY 1997 Service Repair Manual WIRING DIAGRAM: B4M1041 247 4-4cBRAKES [ABS 5.3 TYPE] 10. Diagnostics Chart with Select Monitor

Page 2853 of 3342

SUBARU LEGACY 1997 Service Repair Manual B4M0973 10AG1CHECK OUTPUT OF STOP LIGHT SWITCH USING SELECT MONITOR. 1) Press F, 0and 9on the select monitor. 2) Depress the brake pedal. 3) Read the stop light switch output on the select monitor dis

Page 2854 of 3342

SUBARU LEGACY 1997 Service Repair Manual 10AG4CHECK POOR CONTACT IN CONNEC- TOR BETWEEN STOP LIGHT SWITCH AND ABSCM. : Is there poor contact in connector between stop light switch and ABSCM? : Repair connector. : Go to step10AG5. 10AG5 CHECK

Page 2855 of 3342

SUBARU LEGACY 1997 Service Repair Manual B4M0974 AH: 56 G SENSOR LINE —OPEN OR SHORT CIRCUIT OF G SENSOR — DIAGNOSIS: Faulty G sensor output voltage TROUBLE SYMPTOM: ABS does not operate. 10AH1.Check specifications of ABSCM using selec

Page 2856 of 3342

SUBARU LEGACY 1997 Service Repair Manual From the former page. 10AH11. Check ground short in G sensor output harness. 10AH12.Check G sensor. 10AH13.Check poor contact in connector between ABSCM and G sensor. 10AH14.Check ABSCM. WIRING DIAGRA
