Page 1081 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual DTC P0112, P0113 IAT SENSOR EC-101 C D E F G H I J K L MA EC Diagnostic ProcedureEBS01KE8 1.CHECK GROUND CONNECTIONS 1. Turn ignition switch OFF. 2. Loosen and retighten three ground screws on the bod

Page 1082 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual EC-102 DTC P0112, P0113 IAT SENSOR 3.CHECK INTAKE AIR TEMPERATURE SENSOR GROUND CIRCUIT FOR OPEN AND SHORT 1. Turn ignition switch OFF. 2. Disconnect ECM harness connector. 3. Check harness continuity

Page 1083 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual DTC P0117, P0118 ECT SENSOR EC-103 C D E F G H I J K L MA EC DTC P0117, P0118 ECT SENSORPFP:22630 DescriptionEBS01KEB The engine coolant temperature sensor is used to detect the engine coolant tempera

Page 1084 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual EC-104 DTC P0117, P0118 ECT SENSOR WITHOUT CONSULT-II 1. Turn ignition switch ON and wait at least 5 seconds. 2. Turn ignition switch OFF, wait at least 10 seconds and then turn ON. 3. Perform Diagnos

Page 1085 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual DTC P0117, P0118 ECT SENSOR EC-105 C D E F G H I J K L MA EC Wiring DiagramEBS01KEE MBWA1038E

Page 1086 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual EC-106 DTC P0117, P0118 ECT SENSOR Diagnostic Procedure EBS01KEF 1.CHECK GROUND CONNECTIONS 1. Turn ignition switch OFF. 2. Loosen and retighten three ground screws on the body. Refer toEC-78, " Groun

Page 1087 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual DTC P0117, P0118 ECT SENSOR EC-107 C D E F G H I J K L MA EC 3.CHECK ECT SENSOR GROUND CIRCUIT FOR OPEN AND SHORT 1. Turn ignition switch OFF. 2. Disconnect ECM harness connector. 3. Check harness con

Page 1088 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual EC-108 DTC P0122, P0123 APP SENSOR DTC P0122, P0123 APP SENSOR PFP:18002 DescriptionEBS01KEI The accelerator pedal position sensor is installed on the upper end of the accelerator pedal assembly. The
