Page 705 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual DOOR BL-121 C D E F G H J K L MA B BL 2. Disconnect the front door harness connector. 3. Grommet is pulled out, and the front door harness is pulled out. 4. Remove the mounting bolts of the check link

Page 706 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual BL-122 DOOR 4. Disconnect the rear door harness connector. 5. Grommet is pulled out, and the rear door harness connector is pulled out. 6. Remove the mounting bolts of the rear door check link of the

Page 707 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual DOOR BL-123 C D E F G H J K L MA B BL Removal and Installation of Rear Door (Double Cab)EIS00DUN CAUTION: lWhen removing and installing the rear door assembly, support the door with a jack and cloth t

Page 708 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual BL-124 DOOR Removal and Installation of Door Weather-strip (King Cab) EIS00BQ6 REMOVAL CAUTION: After removal, do not pull strongly on the weather-strip. Remove the weather-strip clips, and remove wea

Page 709 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual DOOR BL-125 C D E F G H J K L MA B BL Removal and Installation of Door Weather-strip (Double Cab)EIS00DWU REMOVAL CAUTION: After removal, do not pull strongly on the weather-strip. Remove the weather-

Page 710 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual BL-126 FRONT DOOR LOCK FRONT DOOR LOCK PFP:80502 Removal and InstallationEIS00B6B REMOVAL 1. Remove the front door finisher. Refer toEI-30, "FRONT DOOR". 2. Fully close the front door window. 3. Remov

Page 711 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual FRONT DOOR LOCK BL-127 C D E F G H J K L MA B BL 7. Remove the door side grommet, and remove the outside handle bracket bolt from grommet hole. CAUTION: Do not forcibly remove the TORX bolt. 8. Reach

Page 712 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual BL-128 FRONT DOOR LOCK 12. Remove the front gasket and rear gasket. 13. Remove the TORX bolts (T30), remove the door lock assembly. 14. While pulling outside handle bracket, slide toward rear of vehic
