AXLE SHAFT
4. Install a bearing puller under the bearing ring retainer, and using
a suitable press, push the axle shaft out of the bearing ring
retainer.
CAUTION:
lThe axle shaft will fall while released from the bearing
ring retainer. Place a wooden pad under the axle shaft to
hold the axle shaft.
lDo not tighten the tool against the axle shaft.
lDo not heat or cut the axle shaft bearing or bearing ring
retainer with a torch during removal, doing so will dam-
age the axle shaft.
5. Remove the bearing from the axle shaft and discard.
6. Remove the seal lip from the axle shaft and discard.
7. Remove the axle shaft retainer.
8. Remove the grease catcher from the axle shaft and discard.Tool number : ST30031000
MDIB9046E
Page 2674 of 3171
![NISSAN NAVARA 2005 Repair Workshop Manual AXLE SHAFT
RAX-11
[M226]
C
E
F
G
H
I
J
K
L
MA
B
RAX
INSPECTION AFTER DISASSEMBLY
Axle Shaft
lClean and remove all nicks and burrs.
lCheck for straightness and distortion. Replace if necessary.
lInspec NISSAN NAVARA 2005 Repair Workshop Manual AXLE SHAFT
RAX-11
[M226]
C
E
F
G
H
I
J
K
L
MA
B
RAX
INSPECTION AFTER DISASSEMBLY
Axle Shaft
lClean and remove all nicks and burrs.
lCheck for straightness and distortion. Replace if necessary.
lInspec](/manual-img/5/57362/w960_57362-2673.png)
AXLE SHAFT
RAX-11
[M226]
C
E
F
G
H
I
J
K
L
MA
B
RAX
INSPECTION AFTER DISASSEMBLY
Axle Shaft
lClean and remove all nicks and burrs.
lCheck for straightness and distortion. Replace if necessary.
lInspect machined surfaces for evidence of overheating, damage and wear. Replace if necessary.
lMeasure the bearing ring retainer axle journal diameter. Replace if necessary.
ASSEMBLY
1. Install a new grease catcher onto the axle shaft.
2. Reinstall studs on the axle shaft retainer, and install the axle shaft retainer on the axle shaft.
3. Install a new seal lip onto the axle shaft.
CAUTION:
lSeal lip can not be reused. Do not attempt to reuse it.
lWhen installing oil seals, apply multi-purpose grease to oil seal lips.
4. Install a new bearing on the axle shaft.
CAUTION:
lWheel bearing can not be reused. Do not attempt to reuse it.
5. Using a bearing inserter, and a suitable press, press fit the axle
shaft to the new bearing ring retainer, until the snap ring groove.
CAUTION:
lMake sure the bearing ring retainer, axle shaft bearing,
axle shaft lip seal, and axle shaft retainer are installed
facing in the correct direction.
lBearing ring retainer can not be reused. Do not attempt to
reuse it.
6. Apply grease to the bearing cup, and install onto the axle shaft
bearing.
7. Install a new snap ring using a suitable snap ring pliers.
CAUTION:
Discard the old snap ring: replace with new ones.
8. Install the new ABS rotor sensor. Refer toBRC-39, "
SENSOR ROTOR".
CAUTION:
Discard the old sensor rotor; replace with a new one.Bearing ring retainer axle journal diameter (minimum)
: 45.027 mm (1.7727 in)
MDIB9047E
Page 2675 of 3171
RAX-12
[M226]
AXLE BEARING
AXLE BEARING
PFP:40120
Removal and InstallationEDS003I0
For removal and installation, refer toRAX-7, "AXLE SHAFT".
Page 2676 of 3171
AXLE OIL SEAL
