Page 2785 of 3171
RFD-82
[WITH ELECTRONIC LOCKING DIFFERENTIAL]
REAR FINAL DRIVE ASSEMBLY
Disassembly and Assembly
EDS003BG
COMPONENTS
1. Drive pinion lock nut 2. Washer 3. Companion flange
4. Front oil seal 5. Front bearing thrust washer 6. Drive pinion front bearing
7. Axle housing 8. Differential lock position switch 9. Breather
10. Sensor connector 11. Drain plug 12. Side bearing cap
13. Adjuster lock plate 14. Carrier cover 15. Filler plug
16. Bracket 17. Drive pinion 18. Drive pinion height adjusting washer
19. Drive pinion rear bearing 20. Collapsible spacer 21. Side bearing adjuster
22. Side bearing 23. Differential case assembly 24. Drive gear
25. Differential lock solenoid 26. Solenoid washer
PDIA1064E
Page 2786 of 3171
![NISSAN NAVARA 2005 Repair Workshop Manual REAR FINAL DRIVE ASSEMBLY
RFD-83
[WITH ELECTRONIC LOCKING DIFFERENTIAL]
C
E
F
G
H
I
J
K
L
MA
B
RFD
ASSEMBLY INSPECTION AND ADJUSTMENT
lBefore inspection and adjustment, drain gear oil.
Total Preload T NISSAN NAVARA 2005 Repair Workshop Manual REAR FINAL DRIVE ASSEMBLY
RFD-83
[WITH ELECTRONIC LOCKING DIFFERENTIAL]
C
E
F
G
H
I
J
K
L
MA
B
RFD
ASSEMBLY INSPECTION AND ADJUSTMENT
lBefore inspection and adjustment, drain gear oil.
Total Preload T](/manual-img/5/57362/w960_57362-2785.png)
REAR FINAL DRIVE ASSEMBLY
RFD-83
[WITH ELECTRONIC LOCKING DIFFERENTIAL]
C
E
F
G
H
I
J
K
L
MA
B
RFD
ASSEMBLY INSPECTION AND ADJUSTMENT
lBefore inspection and adjustment, drain gear oil.
Total Preload Torque
1. Rotate drive pinion back and forth 2 to 3 times to check for unusual noise and rotation malfunction.
2. Rotate drive pinion at least 20 times to check for smooth operation of the bearing.
3. Turn drive pinion in both directions several times to set bearing
rollers.
4. Measure total preload with preload gauge.
NOTE:
Total preload torque = Pinion bearing preload torque + Side bearing preload torque
lIf measured value is out of the specification, disassemble it to check and adjust each part. Adjust pinion
bearing preload and side bearing preload.
Adjust pinion bearing preload first, then adjust side bearing preload.
Tooth Contact
Checking gear tooth contact pattern is necessary to verify correct relationship between drive gear and drive
pinion. Gears which are not positioned in proper arrangement may be noisy and/or have a short life. Check
gear tooth contact pattern to obtain the best contact for low noise and long life.
1. Remove carrier cover. Refer toRFD-86, "
Differential Assembly".
2. Thoroughly clean drive gear and drive pinion teeth.
3. Apply red lead to drive gear.
CAUTION:
Applyredleadtoboththefacesof3to4gearsat4loca-
tions evenly spaced on drive gear.Tool number : ST3127S000
To ta l p r e l o a d
Gear ratio 3.538 Type:
2.34 - 4.34 N·m (0.24 - 0.44 kg-m, 21- 38 in-lb)
Gear ratio 3.692 Type:
2.32 - 4.34 N·m (0.24 - 0.44 kg-m, 21 - 38 in-lb)
When the preload torque is greater than specification
On pinion bearings: Replace collapsible spacer.
On side bearings: Loosen side bearing adjuster.
When the preload torque is less than specification
On pinion bearings: Tighten drive pinion lock nut.
On side bearings: Tighten side bearing adjuster.
PDIA0309E
SDIA2623E
Page 2787 of 3171
RFD-84
[WITH ELECTRONIC LOCKING DIFFERENTIAL]
REAR FINAL DRIVE ASSEMBLY
4. Hold companion flange steady by hand and rotate drive gear in
both directions.
5. If outside the standard, adjust drive pinion height adjusting washer and backlash. Refer toRFD-90, "
Drive
Pinion Height Adjusting Washer"andRFD-84, "Backlash".
Backlash
1. Remove carrier cover. Refer toRFD-86, "Differential Assembly".
2. Check drive gear to drive pinion backlash using a dial indicator
at several points.
3. If outside the standard, adjust side bearing adjusters.
CAUTION:
Check tooth contact and total preload after adjusting side
bearing adjusters. Refer toRFD-83, "
To ta l P r e l o a d To r q u e",
RFD-83, "
Tooth Contact".
a. Remove adjuster lock plates.
b. Loosen side bearing cap bolts.
PDIA0322E
SDIA2591E
Drive gear to drive pinion backlash:
0.08 - 0.13 mm (0.0031 - 0.0051 in)
SDIA2580E
Page 2788 of 3171
![NISSAN NAVARA 2005 Repair Workshop Manual REAR FINAL DRIVE ASSEMBLY
RFD-85
[WITH ELECTRONIC LOCKING DIFFERENTIAL]
C
E
F
G
H
I
J
K
L
MA
B
RFD
c. Tighten or loosen each side bearing adjusters using Tool.
d. In case of excessive backlash, loosen NISSAN NAVARA 2005 Repair Workshop Manual REAR FINAL DRIVE ASSEMBLY
RFD-85
[WITH ELECTRONIC LOCKING DIFFERENTIAL]
C
E
F
G
H
I
J
K
L
MA
B
RFD
c. Tighten or loosen each side bearing adjusters using Tool.
d. In case of excessive backlash, loosen](/manual-img/5/57362/w960_57362-2787.png)
REAR FINAL DRIVE ASSEMBLY
RFD-85
[WITH ELECTRONIC LOCKING DIFFERENTIAL]
C
E
F
G
H
I
J
K
L
MA
B
RFD
c. Tighten or loosen each side bearing adjusters using Tool.
d. In case of excessive backlash, loosen side bearing adjuster A
and tighten side bearing adjuster B. In case of insufficient back-
lash, loosen side bearing adjuster B and tighten side bearing
adjuster A.
e. After adjusting backlash, tighten side bearing cap bolts to the
specified torque. Refer toRFD-82, "
COMPONENTS".
f. Install adjuster lock plates and tighten to the specified torque.
Refer toRFD-82, "
COMPONENTS".
Companion Flange Runout
1. Fit a dial indicator onto companion flange face (inner side of pro-
peller shaft bolt holes).
2. Rotate companion flange to check for runout.
3. Fit a test indicator to the inner side of companion flange (socket
diameter).
4. Rotate companion flange to check for runout.
5. If the runout value is outside the repair limit, follow the procedure
below to adjust.
a. Check for runout while changing the phase between companion flange and drive pinion by 90°,180°and
270°and search for the point where the runout is the minimum.
b. If the runout value is still outside of the limit after the phase has been changed, replace companion flange.
c. If the runout value is still outside of the limit after companion flange has been replaced, check drive pinion
front bearing, drive pinion rear bearing and drive pinion assembly.Tool number : KV38108800
PDIA1044E
PDIA0330E
SDIA2582E
Runout limit : 0.10 mm (0.0039 in) or less
Runout limit : 0.13 mm (0.0051 in) or less
SDIA2078E
Page 2789 of 3171
RFD-86
[WITH ELECTRONIC LOCKING DIFFERENTIAL]
REAR FINAL DRIVE ASSEMBLY
DISASSEMBLY
Differential Assembly
1. Remove carrier cover bolts and bracket.
2. Separate carrier cover from axle housing using Tool.
CAUTION:
lBe careful not to damage the mating surface.
lDo not insert flat-bladed screwdriver, this will damage the
mating surface.
3. Remove sensor connector bolt and differential lock solenoid
connector.
4. For proper reinstallation, paint matching mark on one side of
side bearing cap and axle housing.
CAUTION:
lSide bearing caps are line-board for initial assembly. The
matching marks are used to reinstall them in their origi-
nal positions.
lFor matching mark, use paint. Do not damage side bear-
ing cap and axle housing.
5. Remove adjuster lock plates.
PDIA1066E
Tool number : KV10111100
PDIA1041E
SDIA2585E
SDIA2583E
Page 2790 of 3171
REAR FINAL DRIVE ASSEMBLY
RFD-87
[WITH ELECTRONIC LOCKING DIFFERENTIAL]
C
E
F
G
H
I
J
K
L
MA
B
RFD
6. Remove side bearing caps.
7. Loosen side bearing adjusters using Tool.
8. Keep side bearing outer races together with inner races. Do not
mix them up. Also, keep side bearing adjusters together with
bearing.
9. Remove side bearing adjusters from axle housing.
10. Remove bracket of differential lock position switch connector
and bolts.
11. Remove differential lock position switch.
12. Remove side bearing inner race using suitable tools.
CAUTION:
Be careful not to damage differential case assembly and
differential lock solenoid.
13. Remove differential lock solenoid and solenoid washer.
SDIA2587E
Tool number : KV38108800
PDIA1044E
SDIA2588E
SDIA2633E
SDIA3447E
Page 2791 of 3171
RFD-88
[WITH ELECTRONIC LOCKING DIFFERENTIAL]
REAR FINAL DRIVE ASSEMBLY
14. Remove side bearing inner race using suitable tools.
CAUTION:
Be careful not to damage differential case assembly.
15. For proper reinstallation, paint matching mark on differential
case assembly and drive gear.
CAUTION:
For matching mark, use paint. Do not damage differential
case assembly and drive gear.
16. Remove drive gear bolts.
17. Tap drive gear off differential case assembly using suitable tool.
CAUTION:
Tap evenly all around to keep drive gear from binding.
Drive Pinion Assembly
1. Remove differential case assembly. Refer toRFD-86, "Differential Assembly".
2. Remove drive pinion lock nut and washer using Tool.
3. Put a matching mark on the thread edge of drive pinion. The
mark should be in line with the mark on companion flange.
CAUTION:
For matching mark, use paint. Do not damage drive pinion
and companion flange.
SDIA3448E
SDIA2238E
Tool number : KV40104000
PDIA0314E
SDIA2590E
Page 2792 of 3171
REAR FINAL DRIVE ASSEMBLY
RFD-89
[WITH ELECTRONIC LOCKING DIFFERENTIAL]
C
E
F
G
H
I
J
K
L
MA
B
RFD
4. Remove companion flange using suitable tool.
5. Remove front oil seal using Tool.
CAUTION:
Be careful not to damage axle housing.
6. Remove front bearing thrust washer.
7. Press the drive pinion assembly and collapsible spacer from
axle housing.
CAUTION:
Do not drop drive pinion assembly.
8. Remove drive pinion front bearing inner race from axle housing.
9. Tap drive pinion front bearing outer race uniformly with a brass
bar or equivalent to remove.
CAUTION:
Be careful not to damage axle housing.
10. Tap drive pinion rear bearing outer race uniformly with a brass
bar or equivalent for removal.
CAUTION:
Be careful not to damage axle housing.
11. Remove drive pinion rear bearing inner race and drive pinion
height adjusting washer using Tool.
12. Remove the breather.
PDIA0315E
Tool number : KV381054S0
SDIA2586E
PDIA0316E
SDIA2641E
Tool number : ST30021000
SDIA2236E
