Page 233 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual ON-VEHICLE SERVICE AT-225 D E F G H I J K L MA B AT 10. Connect A/T fluid temperature sensor 2 connector. 11. Securely fasten terminal cord assembly and A/T fluid tempera- ture sensor 2 harness with t

Page 234 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual AT-226 ON-VEHICLE SERVICE 15. Install oil pan to transmission case. a. Install oil pan gasket to oil pan. CAUTION: lDo not reuse oil pan gasket. lInstall it in the direction to align hole positions. l

Page 235 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual ON-VEHICLE SERVICE AT-227 D E F G H I J K L MA B AT A/T FLUID TEMPERATURE SENSOR 2 REMOVAL AND INSTALLATION Removal 1. Disconnect the battery cable from the negative terminal. 2. Remove under cover. 3

Page 236 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual AT-228 ON-VEHICLE SERVICE 8. Remove A/T fluid temperature sensor 2 with bracket from con- trol valve with TCM. 9. Remove bracket from A/T fluid temperature sensor 2. Installation CAUTION: After comple

Page 237 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual ON-VEHICLE SERVICE AT-229 D E F G H I J K L MA B AT 3. Connect A/T fluid temperature sensor 2 connector. 4. Securely fasten A/T fluid temperature sensor 2 harness with ter- minal clip. 5. Install oil

Page 238 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual AT-230 ON-VEHICLE SERVICE Parking Components (2WD Models Only) ECS00GVL REMOVAL AND INSTALLATION Components Removal 1. Drain ATF through drain hole. 2. Remove rear propeller shaft. Refer toPR-8, " Rem

Page 239 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual ON-VEHICLE SERVICE AT-231 D E F G H I J K L MA B AT 7. Remove tightening bolts for rear extension assembly and trans- mission case. lSelf-sealing bolt (1) : Bolt (10) 8. Tap rear extension assembly wi

Page 240 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual AT-232 ON-VEHICLE SERVICE 12. Remove parking gear from output shaft. 13. Remove seal rings from output shaft. 14. Remove needle bearing (1) from rear extension. 15. Remove parking actuator support fro
