NISSAN NAVARA 2005 Repair Workshop Manual SE-26 FRONT SEAT SEATBACK (POWER AND MANUAL SEAT) Disassembly WARNING: Removal of front side air bag module should only be done to allow deployment of front side air bag module prior to disposal of se

Page 2898 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual FRONT SEAT SE-27 C D E F G H J K L MA B SE 6. Remove the headrest holder. Squeeze and pull up headrest holder tabs to remove from seatback frame. NOTE: Before installing the headrest holder, check its

Page 2899 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual SE-28 FRONT SEAT 3. Remove the retainer(1) from the seatback frame(2). 4. Remove the hog ring(A) and separate the seatback trim lower side. 5. Remove the mounting nut of side air bag module. 6. Remove

Page 2900 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual REAR SEAT SE-29 C D E F G H J K L MA B SE REAR SEATPFP:88300 Removal and InstallationEIS00DVS JUMP SEAT (KING CAB) Removal 1. Remove seat leg cover. 2. Remove the seat cushion bolts and assembly. 3. L

Page 2901 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual SE-30 REAR SEAT BENCH SEAT LH (DOUBLE CAB) Removal 1. Remove the seat outer reg cover. 2. Release the seat lock and tilt the seatback down. Remove the nuts. 3. Raise the seatback. 4. Tilt the seat cus

Page 2902 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual REAR SEAT SE-31 C D E F G H J K L MA B SE 7. Remove the seat bolts. 8. Remove the seat assembly. Installation Installation is in the reverse order of removal. NOTE: Make sure the washers are on the re

Page 2903 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual SE-32 REAR SEAT Disassembly and Assembly EIS00DVT Jump Seat (King Cab) LIIA1957E

Page 2904 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual REAR SEAT SE-33 C D E F G H J K L MA B SE 1. Headrest 2. Seatback pad and frame 3. Seatback trim 4. Seat leg cover 5. Seat cushion pad and frame assem- bly6. Seat cushion trim 7. Bushing 8. Spacer 9.
