Page 201 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual TROUBLE DIAGNOSIS FOR SYMPTOMS AT-193 D E F G H I J K L MA B AT 6.DETECT MALFUNCTIONING ITEM 1. Check control valve with TCM. Refer toAT- 2 1 8 , " Control Valve With TCM and A/T Fluid Temperature Sen

Page 202 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual AT-194 TROUBLE DIAGNOSIS FOR SYMPTOMS A/T Does Not Shift: D 4®D5ECS00G2M SYMPTOM: lThe vehicle does not shift-up from D4to D5gear at the specified speed. lThe vehicle does not shift-up from D4to D5ge

Page 203 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual TROUBLE DIAGNOSIS FOR SYMPTOMS AT-195 D E F G H I J K L MA B AT 7.DETECT MALFUNCTIONING ITEM 1. Check control valve with TCM. Refer toAT- 2 1 8 , " Control Valve With TCM and A/T Fluid Temperature Sen

Page 204 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual AT-196 TROUBLE DIAGNOSIS FOR SYMPTOMS A/T Does Not Perform Lock-up ECS00G2N SYMPTOM: A/T does not perform lock-up at the specified speed. DIAGNOSTIC PROCEDURE 1.CHECK SELF-DIAGNOSTIC RESULTS Perform s

Page 205 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual TROUBLE DIAGNOSIS FOR SYMPTOMS AT-197 D E F G H I J K L MA B AT 6.CHECK A/T FLUID CONDITION 1. Remove oil pan. Refer toAT- 2 1 8 , " Control Valve With TCM and A/T Fluid Temperature Sensor 2". 2. Chec

Page 206 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual AT-198 TROUBLE DIAGNOSIS FOR SYMPTOMS 2.CHECK A/T FLUID LEVEL Check A/T fluid level. Refer toAT-12, " Checking A/T Fluid". OK or NG OK >> GO TO 3. NG >> Refill ATF. 3.CHECK A/T FLUID CONDITION 1. Remo

Page 207 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual TROUBLE DIAGNOSIS FOR SYMPTOMS AT-199 D E F G H I J K L MA B AT Lock-up Is Not ReleasedECS00G2P SYMPTOM: The lock-up condition cannot be cancelled even after releasing accelerator pedal. DIAGNOSTIC PR

Page 208 of 3171

NISSAN NAVARA 2005 Repair Workshop Manual AT-200 TROUBLE DIAGNOSIS FOR SYMPTOMS 3.CHECK A/T FLUID CONDITION 1. Remove oil pan. Refer toAT- 2 1 8 , " Control Valve With TCM and A/T Fluid Temperature Sensor 2". 2. Check A/T fluid condition. Ref
