Page 1497 of 3171

CYLINDER BLOCK
EM-115
C
D
E
F
G
H
I
J
K
L
MA
EM
2. Install drain plug to cylinder block.
lApply liquid gasket to drain plug.
Use Genuine Liquid Gasket or equivalent
3. Install oil jet relief valve.
4. Install oil jet.
lAlign knock pin on back of oil jet with hole on block when
installing oil jet.
5. Install main bearings and thrust bearings.
a. Remove contamination, dust and engine oil from bearing mount-
ing positions on cylinder block and main bearing caps.
b. Install thrust bearings on both sides of No. 3 housing on cylinder
block.
lInstall thrust bearings with oil groove facing to crankshaft arm
(outside).
c. Being careful with the direction, install main bearings.
lInstall main bearings with the oil holes and grooves onto the
cylinder block side, and those without oil holes and grooves
onto the main cap side.
lWhile installing bearings, apply engine oil to bearing surfaces
(inside). Do not apply engine oil to rear surfaces, but clean
them completely.
lAlign stopper notches on bearings to install them.
lMake sure that the oil holes on the cylinder block body are
mated with the oil hole positions on the bearings.
6. Install crankshaft to cylinder block.
lMake sure crankshaft rotates smoothly by hand.
1 : Cylinder block
2 : Drain plug
PBIC3483E
PBIC0389E
JEM224G
JEM213G
Page 1498 of 3171

EM-116
CYLINDER BLOCK
7. Install main bearing caps.
lIdentify main bearing caps by the punched mark. Install cor-
rectly matching the journal No. on the bearing cap and the
journal with the front mark facing forward.
lMain bearing caps are commonly processed with the cylinder
block. Therefore, caps and cylinder block should be replaced
as a set.
8. Check the main bearing cap bolts for deformation. Refer toEM-
133, "MAIN BEARING CAP BOLT DEFORMATION".
9. With the TORX socket (size: E14, commercial service tool),
tighten the main bearing cap bolts according to the following
procedure:
a. Apply engine oil to the threaded part and seat surface of each
bolt.
b. Tighten all bolts in numerical order shown in the figure.
c. Put alignment marks (with paint) on each bolt and the main
bearing cap, all in the same direction. (When using a protractor)
d. Then, tighten 90 degrees. (angle tightening)
CAUTION:
Always use either the angle wrench [SST] or protractor dur-
ing angular tightening. Avoid tightening based on visual
checks alone.
lAfter tightening bolts to specified torque, make sure that
crankshaft rotates smoothly.
lCheck crankshaft end play. Refer toEM-124, "CRANKSHAFT
END PLAY".
10. Check the outer diameter of connecting rod bolts. Refer toEM-
133, "CONNECTING ROD BOLT DEFORMATION".
11. Install piston to connecting rod.
a. Using the snap ring pliers, install snap rings to groove on piston rear side.
lFit snap ring correctly into grooves.
b. Install pistons to connecting rods.
lUsing the industrial use dryer, heat pistons up to approx. 60 to
70°C(140to158°F) until piston pin can be pressed down by
finger touch. Then insert piston pin into piston and connecting
rod from front side of piston toward rear.
JEM225G
: 27.0 N·m (2.8 kg-m, 20 ft-lb)
JEM200G
JEM226G
PBIC0089E
Page 1499 of 3171

CYLINDER BLOCK
EM-117
C
D
E
F
G
H
I
J
K
L
MA
EM
lAssemble piston and connecting rod with front mark of piston
head and cylinder No. stamped on connecting rod being posi-
tioned as shown in the figure.
c. Install snap ring to front side of piston.
lRefer to above step a for precaution on snap ring installation.
lAfter installation, check connecting rods for smooth move-
ment.
12. Use the piston ring expander (commercial service tool) to install piston rings.
CAUTION:
When installing, prevent piston from being damaged.
lInstall top ring and second ring with punched mark surfaces
facing upward.
lInstall rings so that three closed gap position 120 degrees
apart one another.
lClosed gaps do not need to face in a specific directions, as
long as each are positioned 120 degrees apart.
13. Install connecting rod bearing to connecting rod and cap.
lWhile installing connecting rod bearing, apply engine oil to
bearing surfaces (inside). Do not apply engine oil to rear sur-
faces, but clean them completely.
lAlign protrusions on connecting rod bearings with connecting
rod cut-outs to install connecting rod bearings.
14. Install piston and connecting rod assembly to crankshaft.
lMove crankshaft pin to be assembled to BDC.
lAlign cylinder position with cylinder No. on connecting rod to
install piston and connecting rod assembly.
lUsing the piston ring compressor [SST] or suitable tool, install
piston and connecting rod assembly with front mark on piston
head facing toward the front side of engine.
CAUTION:
When installing piston and connecting rod assembly, pre-
vent the big end of connecting rod from interfering with
oil jet.
MBIA0024E
Punched mark:
To p r i n g : R TO P
Second ring : R2ND
JEM228G
JEM229G
PBIC1619E
Page 1500 of 3171

EM-118
CYLINDER BLOCK
15. Install connecting rod caps and mounting nuts.
lAlign cylinder No. stamped on connecting rod with that on cap
to install connecting rod cap.
lMake sure that the front mark on connecting rod cap faces
towards the front of the engine.
16. Tighten connecting rod nuts according to the following procedure:
a. Apply engine oil on bolt threads and seat surface of nuts.
b. Tighten bolts.
c. Loosen completely.
d. Tighten bolts.
e. Tighten 120 degrees. (angle tightening)
lAlways use either the angle wrench [SST] or protractor
during angular tightening. Avoid tightening based on
visual checks alone.
lAfter tightening nuts, make sure that crankshaft rotates
smoothly.
lCheck connecting rod side clearance. Refer toEM-125,
"CONNECTING ROD SIDE CLEARANCE".
17. Press fit rear oil seal into rear oil seal retainer.
lUsing the drift [105 mm (4.13 in) dia.], press fit so that the
dimension is as specified in the figure.
lAvoid inclined fitting. Force fit perpendicularly.
MBIA0024E
: 29.4 N·m (3.0 kg-m, 22 ft-lb)
:0N·m(0kg-m,0in-lb)
: 19.6 N·m (2.0 kg-m, 14 ft-lb)
JEM231G
JEM232G
Page 1501 of 3171

CYLINDER BLOCK
EM-119
C
D
E
F
G
H
I
J
K
L
MA
EM
18. Install rear oil seal retainer to cylinder block.
lApply new engine oil to the oil and dust seal lips.
lApply liquid gasket to rear oil seal retainer using the tube
presser [SST: WS39930000] as shown in the figure.
Use Genuine Liquid Gasket or equivalent.
19. Press fit pilot bushing into crankshaft (M/T models).
lUsing the drift with outer diameter of 19 mm (0.75 in), press fit
pilot bushing until it stops.
20. Press fit pilot converter into crankshaft (A/T models).
lUsing the drift with outer diameter of 33 mm (1.30 in), press fit pilot converter until it stops.
lPress fit pilot converter with its chamfer facing crankshaft as
showninthefigure.
21. Install fuel pump bracket.
lAlign the bracket with the dowel pins on cylinder block to
install.
lThe two bolts used for dowel pins have a longer shanks than
the other two.
22. Install parts to engine in the reverse order of disassembly.
23. Remove engine from engine stand in the reverse order of assembly.
24. Install flywheel (M/T models).
JEM233G
JEM234G
SEM537E
PBIC2329E
Page 1502 of 3171

EM-120
CYLINDER BLOCK
lWhen installing flywheel to crankshaft, be sure to correctly
align crankshaft side dowel pin and flywheel side dowel pin
hole.
CAUTION:
If these are not aligned correctly, engine runs roughly
and “MI” turns on.
lThere is a mating mark on the clutch cover side of flywheel.
Refer it during installation.
lHolding ring gear with ring gear stopper [SST], tighten secur-
ing bolts with TORX socket (size: T55, commercial service
tool).
lTighten bolts uniformly in a crisscross manner.
–If these are not aligned correctly, engine runs roughly and “MI” turns on.
25. Install drive plate (A/T models).
lWhen installing drive plate to crankshaft, be sure to correctly align crankshaft side dowel pin and drive
plate side dowel pin hole.
CAUTION:
If these are not aligned correctly, engine runs roughly and “MI” turns on.
lInstall drive plate and reinforcement plate as shown in the fig-
ure.
lHolding ring gear with ring gear stopper [SST: KV10105630],
tighten securing bolts with TORX socket (size: E20) (commer-
cial service tool).
lTighten bolts uniformly in a crisscross manner.
26. Install in the reverse order of removal.
PBIC2538E
PBIC1112E
PBIC2406E
PBIC0910E
Page 1503 of 3171

CYLINDER BLOCK
EM-121
C
D
E
F
G
H
I
J
K
L
MA
EM
How to Select Piston and BearingEBS01E6F
DESCRIPTION
lThe identification grade stamped on each part is the grade for the dimension measured in new condition.
This grade cannot apply to reused parts.
lFor reused or repaired parts, measure the dimension accurately. Determine the grade by comparing the
measurement with the values of each selection table.
lFor details of the measurement method of each part, the reuse standards and the selection method of the
selective fitting parts, refer to the text.
HOW TO SELECT PISTON
When Using New Cylinder Block
1. Identify the cylinder bore grade (No. 1, 2, or 3) on LH surface at
the rear of cylinder block.
2. Select piston of the same grade.
lThe part No. of piston is specified together with piston pin as
an assembly.
When Re-using an Old Cylinder Block
1. Measure cylinder bore inner diameter. Refer toEM-129, "Cylinder Bore Inner Diameter".
2. Referring to “Cylinder bore inner diameter” in “Piston Selection Table”, determine the bore grade.
3. Select piston of the same grade.
Piston Selection Table
Unit: mm (in) Selection points Selection parts Selection items Selection methods
Between cylinder block to
crankshaftMain bearingMain bearing grade (bearing
thickness)Determined by match of cylin-
der block bearing housing
grade (inner diameter of hous-
ing) and crankshaft journal
grade (outer diameter of jour-
nal)
Between crankshaft to connect-
ing rodConnecting rod bearingConnecting rod bearing grade
(bearing thickness)Combining service grades for
connecting rod big end diame-
ter and crankshaft pin outer
diameter determine connecting
rod bearing selection.
Between cylinder block to pis-
tonPiston and piston pin assembly
The piston is available together
with piston pin as an assembly.Piston grade (piston outer
diameter)Piston grade = cylinder bore
grade (inner diameter of bore)
JEM208G
MBIA0025E
Grade (punched) 1 2 3
Page 1504 of 3171

EM-122
CYLINDER BLOCK
NOTE:
Piston is available together with piston pin as an assembly.
HOW TO SELECT CONNECTING ROD BEARING
When Using New Crankshaft and Connecting Rod
1. Identify the pin diameter grade (No. 0, 1, or 2) on front surface of
crankshaft.
2. Select connecting rod bearings of the same grade.
NOTE:
There is no grading for the inner diameter of the big end of the
connecting rod.
When Re-using the Removed Crankshaft and Connecting Rod
1. Measure the inner diameter of the big end of connecting rod and make sure it is within the specified
range. Refer toEM-127, "
CONNECTING ROD BIG END INNER DIAMETER".
2. Measure the outer diameter of the crankshaft pin. Refer toEM-130, "
CRANKSHAFT PIN JOURNAL
DIAMETER".
3. Determine the crankshaft pin grade by comparing the measurement with the values under the column
“Crankshaft pin outer diameter” in “Selection Table of connecting Rod Bearing”.
4. Choose bearings of the same grade.
Selection Table of connecting Rod Bearing
Unit: mm (in)
Unit: mm (in)
Under Size Bearing Usage
lIf bearing clearance is out of the specifications for connecting rod bearings in standard size, use under
size bearings.
lWhen using under size bearings, measure bearing inner diameter with bearing installed, and grind crank-
shaft pins to adjust clearance to specification.
Connecting Rod Bearing Under Size List
Unit: mm (in) Cylinder bore
inner diameter89.000 - 89.010 (3.5039 - 3.5043) 89.010 - 89.020 (3.5043 - 3.5047) 89.020 - 89.030 (3.5047 - 3.5051)
Piston outer
diameter88.928 - 88.942 (3.5011 - 3.5016) 88.938 - 88.952 (3.5015 - 3.5020) 88.948 - 88.962 (3.5019 - 3.5024)
JEM215G
Connecting rod big end inner diameter 55.000 - 55.013 (2.1654 - 2.1659)
Crankshaft pin outer diameter Grade (Mark) Dimension (Bearing thickness range) Bearing grade No. Color
51.968 - 51.974 (2.0460 - 2.0462) 0 1.492 - 1.496 (0.0587 - 0.0589) STD 0 Black
51.961 - 51.968 (2.0457 - 2.0460) 1 1.496 - 1.500 (0.0589 - 0.0591) STD 1 Brown
51.954 - 51.961 (2.0454 - 2.0457) 2 1.500 - 1.504 (0.0591 - 0.0592) STD 2 Green
Size Thickness
US 0.08 (0.0031) 1.536 - 1.540 (0.0605 - 0.0606)
US 0.12 (0.0047) 1.556 - 1.560 (0.0613 - 0.0614)
US 0.25 (0.0098) 1.621 - 1.625 (0.0638 - 0.0640)
