Page 4353 of 4647

INFINITI M35 2007 Factory Service Manual SE-154 HEATED SEAT Revision: 2007 April2007 M35/M45 Check Rear Seat Control Unit Power Supply and Ground CircuitNIS00288 1. CHECK REAR SEAT CONTROL UNIT POWER SUPPLY CIRCUIT (BAT) 1. Turn ignition swi

Page 4354 of 4647

INFINITI M35 2007 Factory Service Manual HEATED SEAT SE-155 C D E F G H J K L MA B SE Revision: 2007 April2007 M35/M45 3. CHECK REAR SEAT CONTROL UNIT HARNESS 1. Turn ignition switch OFF. 2. Disconnect IPDM E/R (heated seat relay) and rear s

Page 4355 of 4647

INFINITI M35 2007 Factory Service Manual SE-156 HEATED SEAT Revision: 2007 April2007 M35/M45 Check Rear Heated Seat Switch CircuitNIS00289 1. CHECK REAR HEATED SEAT SWITCH POWER SUPPLY-1 1. Turn ignition switch ON. 2. Check voltage between

Page 4356 of 4647

INFINITI M35 2007 Factory Service Manual HEATED SEAT SE-157 C D E F G H J K L MA B SE Revision: 2007 April2007 M35/M45 3. CHECK REAR HEATED SEAT SWITCH Check continuity rear heated seat switch connector. OK or NG OK >> GO TO 4. NG >> Replac

Page 4357 of 4647

INFINITI M35 2007 Factory Service Manual SE-158 HEATED SEAT Revision: 2007 April2007 M35/M45 Check Rear Heated Seat Indicator Power Supply CircuitNIS0028A 1. CHECK REAR HEATED SEAT INDICATOR POWER SUPPLY 1. Turn ignition switch OFF. 2. Disco

Page 4358 of 4647

INFINITI M35 2007 Factory Service Manual HEATED SEAT SE-159 C D E F G H J K L MA B SE Revision: 2007 April2007 M35/M45 3. CHECK REAR HEATED SEAT SWITCH Check continuity rear heated seat switch connector. OK or NG OK >> Check the condition o

Page 4359 of 4647

INFINITI M35 2007 Factory Service Manual SE-160 HEATED SEAT Revision: 2007 April2007 M35/M45 2. CHECK REAR HEATED SEAT INDICATOR HARNESS 1. Turn ignition switch OFF. 2. Disconnect rear seat control unit and rear heated seat switch connector.

Page 4360 of 4647

INFINITI M35 2007 Factory Service Manual HEATED SEAT SE-161 C D E F G H J K L MA B SE Revision: 2007 April2007 M35/M45 Check Rear Heated Seat CircuitNIS0028C 1. CHECK REAR SEAT CONTROL UNIT 1. Turn ignition switch ON. 2. Check voltage betwee
