Page 4521 of 4647

INFINITI M35 2007 Factory Service Manual TF-32 TROUBLE DIAGNOSIS FOR SYSTEM Revision: 2007 April2007 M35/M45 4. CHECK DTC Perform the self-diagnosis, after driving a vehicle for a while. OK or NG OK >>INSPECTION END NG >> Replace AWD control

Page 4522 of 4647

INFINITI M35 2007 Factory Service Manual TROUBLE DIAGNOSIS FOR SYMPTOMS TF-33 C E F G H I J K L MA B TF Revision: 2007 April2007 M35/M45 TROUBLE DIAGNOSIS FOR SYMPTOMSPFP:00007 AWD Warning Lamp Does Not Turn ON When The Ignition Switch Is Tu

Page 4523 of 4647

INFINITI M35 2007 Factory Service Manual TF-34 TROUBLE DIAGNOSIS FOR SYMPTOMS Revision: 2007 April2007 M35/M45 2. CHECK AWD CONTROL UNIT POWER SUPPLY CIRCUIT 1. Turn ignition switch “OFF”. 2. Disconnect AWD control unit harness connector

Page 4524 of 4647

INFINITI M35 2007 Factory Service Manual TROUBLE DIAGNOSIS FOR SYMPTOMS TF-35 C E F G H I J K L MA B TF Revision: 2007 April2007 M35/M45 4. CHECK AWD CONTROL UNIT Check AWD control unit input/output signal. Refer to TF-20, " AWD Control Unit

Page 4525 of 4647

INFINITI M35 2007 Factory Service Manual TF-36 TROUBLE DIAGNOSIS FOR SYMPTOMS Revision: 2007 April2007 M35/M45 3. CHECK SYSTEM FOR AWD SOLENOID Perform trouble diagnosis for AWD solenoid system. Refer to TF-28, " AWD Solenoid" . OK or NG OK

Page 4526 of 4647

INFINITI M35 2007 Factory Service Manual TROUBLE DIAGNOSIS FOR SYMPTOMS TF-37 C E F G H I J K L MA B TF Revision: 2007 April2007 M35/M45 3. CHECK AWD SOLENOID Check AWD solenoid. Refer to TF-30, " COMPONENT INSPECTION" . OK or NG OK >> GO TO

Page 4527 of 4647

INFINITI M35 2007 Factory Service Manual TF-38 TROUBLE DIAGNOSIS FOR SYMPTOMS Revision: 2007 April2007 M35/M45 2. CHECK INPUT SIGNAL OF TIRE DIAMETER With CONSULT-II 1. Start engine. 2. Drive at 20 km/h (12 MPH) or more for approx. 200 seco

Page 4528 of 4647

INFINITI M35 2007 Factory Service Manual AWD CONTROL UNIT TF-39 C E F G H I J K L MA B TF Revision: 2007 April2007 M35/M45 AWD CONTROL UNITPFP:41650 Removal and InstallationNDS000E0 REMOVAL 1. Remove the dash side finisher. Refer to EI-37, "
