INFINITI M35 2007 Factory Service Manual CO-56
[VK45DE]
THERMOSTAT AND WATER CONTROL VALVE
Revision: 2007 April2007 M35/M45
5. Disconnect water suction hose from water inlet.
6. Remove water inlet and thermostat.
CAUTION:
Do not disassemble

CO-56
[VK45DE]
THERMOSTAT AND WATER CONTROL VALVE
Revision: 2007 April2007 M35/M45
5. Disconnect water suction hose from water inlet.
6. Remove water inlet and thermostat.
CAUTION:
Do not disassemble thermostat.
7. Remove intake manifolds (upper and lower). Refer to EM-179, "
INTAKE MANIFOLD" .
8. Disconnect radiator hose (upper) from thermostat housing.
9. Disconnect heater hoses from water outlet and heater pipe.
10. Remove thermostat housing, water outlet pipe, water connector, water control valve, water outlet and
heater pipe.
CAUTION:
Do not disassemble water control valve.
INSPECTION AFTER REMOVAL
Make sure that valves both in thermostat and water control valve are completely closing at normal tempar-
ature.
Place a thread so that it is caught in the valves of the thermostat
and water control valve. Immerse fully in a container filled with
water. Heat while stirring. (The example in the figure shows ther-
mostat.)
The valve opening temperature is the temperature at which the
valve opens and falls from the thread.
Continue heating. Check the maximum valve lift.
NOTE:
The maximum valve lift standard temperature for water control
valve is the reference value.
After checking the maximum valve lift, lower the water tempera-
ture and check the valve closing temperature.
Standard values:
If the malfunctioning condition, when closing valve at normal temperature, or measured values are out of
the standard, replace thermostat and/or water control valve.
INSTALLATION
Note the following, and install in the reverse order of removal.
CAUTION:
Be careful not to spill engine coolant over engine room. Use rag to absorb engine coolant.
Thermostat and Water Control Valve
Install thermostat and water control valve with the whole circum-
ference of each flange part fit securely inside rubber ring. (The
example in the figure shows thermostat.)
SLC252B
Thermostat Water control valve
Valve opening temperature 80 - 84°C (176 - 183°F) 93.5 - 96.5°C (200 - 206°F)
Maximum valve liftMore than 10 mm/95°C
(0.39 in/203°F)More than 8 mm/108°C
(0.315 in/226°F)
Valve closing temperature 77°C (171°F) 90°C (194°F)
PBIC0157E

Page 1418 of 4647

INFINITI M35 2007 Factory Service Manual THERMOSTAT AND WATER CONTROL VALVE
CO-57
[VK45DE]
C
D
E
F
G
H
I
J
K
L
MA
CO
Revision: 2007 April2007 M35/M45
Install thermostat with jiggle valve facing upwards. (The position
deviation may be within

Page 1419 of 4647

INFINITI M35 2007 Factory Service Manual CO-58
[VK45DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
Revision: 2007 April2007 M35/M45
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
Standard and LimitNBS004RT
ENGINE COOLANT CAPACITY (APPROXIMATE)
Un

Page 1420 of 4647

INFINITI M35 2007 Factory Service Manual DI-1
DRIVER INFORMATION SYSTEM
K ELECTRICAL
CONTENTS
C
D
E
F
G
H
I
J
L
M
SECTION DI
A
B
DI
Revision: 2007 April2007 M35/M45
DRIVER INFORMATION SYSTEM
PRECAUTION ......................................

DI-1
DRIVER INFORMATION SYSTEM
K ELECTRICAL
CONTENTS
C
D
E
F
G
H
I
J
L
M
SECTION DI
A
B
DI
Revision: 2007 April2007 M35/M45
DRIVER INFORMATION SYSTEM
PRECAUTION ............................................................ 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 3
PREPARATION ........................................................... 4
Commercial Service Tools ........................................ 4
COMBINATION METERS ........................................... 5
System Description .................................................. 5
UNIFIED METER CONTROL UNIT ...................... 5
UNIFIED METER AND A/C AMP. ......................... 5
POWER SUPPLY AND GROUND CIRCUIT ........ 5
SPEEDOMETER ................................................... 6
TACHOMETER ..................................................... 6
WATER TEMPERATURE GAUGE ........................ 6
FUEL GAUGE ....................................................... 7
ODO/TRIP METER ............................................... 7
METER ILLUMINATION CONTROL ..................... 8
FAIL-SAFE ............................................................ 9
Arrangement of Combination Meter ....................... 10
Component Parts Location ...................................... 11
Internal Circuit ........................................................ 12
Wiring Diagram — METER — ................................ 13
Terminals and Reference Value for Combination
Meter ...................................................................... 15
Terminals and Reference Value for Unified Meter
and A/C Amp. ......................................................... 16
Self-Diagnosis Mode of Combination Meter ........... 17
SELF-DIAGNOSIS FUNCTION .......................... 17
OPERATION PROCEDURE ............................... 17
CONSULT-II Function (METER A/C AMP) ............. 18
Trouble Diagnosis .................................................. 18
HOW TO PERFORM TROUBLE DIAGNOSIS ... 18
PRELIMINARY CHECK ...................................... 18
Symptom Chart ...................................................... 18
Power Supply and Ground Circuit Inspection ........ 19
Vehicle Speed Signal Inspection ............................ 20
Engine Speed Signal Inspection ............................ 21
Engine Coolant Temperature Signal Inspection ..... 22
Fuel Level Sensor Signal Inspection ...................... 22
Fuel Gauge Pointer Fluctuates, Indicator Wrong Value or Varies ....................................................... 25
Fuel Gauge Does Not Move to FULL Position ....... 25
Electrical Components Inspection .......................... 26
CHECK FUEL LEVEL SENSOR UNIT ................ 26
Removal and Installation of Combination Meter ..... 27
REMOVAL ........................................................... 27
INSTALLATION ................................................... 27
Disassembly and Assembly of Combination Meter ... 27
DISASSEMBLY ................................................... 27
ASSEMBLY ......................................................... 27
UNIFIED METER AND A/C AMP .............................. 28
System Description ................................................. 28
COMBINATION METER CONTROL FUNCTION ... 28
A/C AUTO AMP. FUNCTION ............................... 29
OTHER FUNCTIONS .......................................... 29
Schematic ............................................................... 30
CONSULT-II Function (METER A/C AMP) ............. 31
CONSULT-II BASIC OPERATION ....................... 31
SELF-DIAG RESULTS ........................................ 31
DATA MONITOR ................................................. 32
Power Supply and Ground Circuit Inspection ......... 34
DTC [U1000] CAN Communication Circuit ............. 35
DTC [B2202] Meter Communication Circuit ........... 35
DTC [B2205] Vehicle Speed Circuit ........................ 38
Removal and Installation of Unified Meter and A/C
Amp. ....................................................................... 38
REMOVAL ........................................................... 38
INSTALLATION ................................................... 38
WARNING LAMPS .................................................... 39
System Description ................................................. 39
OIL PRESSURE WARNING LAMP ..................... 39
Component Parts and Harness Connector Location ... 40
Schematic ............................................................... 41
Wiring Diagram — WARN — .................................. 42
Oil Pressure Warning Lamp Stays Off (Ignition
Switch ON) ............................................................. 52
Oil Pressure Warning Lamp Does Not Turn Off (Oil
Pressure Is Normal) ................................................ 53
Electrical Component Inspection ............................ 54
OIL PRESSURE SWITCH ................................... 54

Page 1421 of 4647

INFINITI M35 2007 Factory Service Manual DI-2Revision: 2007 April2007 M35/M45 A/T INDICATOR ........................................................ 55
System Description ................................................. 55
MANUAL MODE ...

DI-2Revision: 2007 April2007 M35/M45 A/T INDICATOR ........................................................ 55
System Description ................................................. 55
MANUAL MODE .................................................. 55
NOT MANUAL MODE ......................................... 55
Wiring Diagram — AT/IND — ................................. 56
A/T Indicator Is Malfunction .................................... 58
WARNING CHIME ..................................................... 59
System Description ................................................. 59
POWER SUPPLY AND GROUND CIRCUIT ....... 59
IGNITION KEY WARNING CHIME (WITH INTEL-
LIGENT KEY) ...................................................... 60
LIGHT WARNING CHIME ................................... 60
SEAT BELT WARNING CHIME ........................... 60
Component Parts and Harness Connector Location ... 61
Schematic ............................................................... 62
Wiring Diagram — CHIME — ................................. 63
Terminals and Reference Value for Combination
Meter ...................................................................... 66
Terminals and Reference Value for Unified Meter
and A/C Amp. ......................................................... 66
Terminals and Reference Value for BCM ................ 67
CONSULT-II Function (BCM) .................................. 68
CONSULT-II BASIC OPERATION ....................... 68
DATA MONITOR .................................................. 68
ACTIVE TEST ..................................................... 69
SELF-DIAG RESULTS ........................................ 69
CONSULT-II Function (METER A/C AMP) ............. 69
Trouble Diagnosis ................................................... 70
HOW TO PERFORM TROUBLE DIAGNOSIS .... 70
PRELIMINARY INSPECTION ............................. 70
SYMPTOM CHART ............................................. 70
Meter Buzzer Circuit Inspection .............................. 70
Lighting Switch Signal Inspection ........................... 71
Front Door Switch (Driver Side) Signal Inspection ... 72
Seat Belt Buckle Switch Signal Inspection ............. 73
Electrical Component Inspection ............................ 74
FRONT DOOR SWITCH (DRIVER SIDE) ........... 74
SEAT BELT BUCKLE SWITCH (DRIVER SIDE) ... 74
LANE DEPARTURE WARNING SYSTEM ................ 75
Precautions for Lane Departure Warning (LDW)
system .................................................................... 75
System Description ................................................. 75
LDW SYSTEM OPERATION ............................... 75
POWER SUPPLY AND GROUND CIRCUIT ....... 77
Action Test .............................................................. 77
LDW SYSTEM RUNNING TEST ......................... 77
Camera Aiming Adjustment .................................... 78
OUTLINE ............................................................. 78
PREPARATION ................................................... 78
TARGET SETTING .............................................. 78
VEHICLE HEIGHT CHECK ................................. 81
AIMING ADJUSTMENT ....................................... 81Component Parts and Harness Connector Location ... 85
Wiring Diagram — LDW — ..................................... 86
Terminals and Reference Value for LDW Camera
Unit .......................................................................... 88
CONSULT-II Function (LDW) .................................. 88
DESCRIPTION .................................................... 88
CONSULT-II BASIC OPERATION ....................... 88
WORK SUPPORT ............................................... 89
SELF-DIAG RESULTS ......................................... 89
DATA MONITOR .................................................. 90
ACTIVE TEST ...................................................... 91
Trouble Diagnosis ................................................... 92
HOW TO PERFORM TROUBLE DIAGNOSIS .... 92
PRELIMINARY INSPECTION .............................. 92
SYMPTOM CHART .............................................. 93
Power Supply and Ground Circuit Inspection ......... 93
DTC [C1B00] CAMERA UNIT MALF ...................... 94
DTC [C1B01] CAM AIMING INCMP ....................... 94
DTC [C1B02] VHCL SPD DATA MALF ................... 94
DTC [C1B03] ABNRML TEMP DETECT ................ 94
DTC [U1000] CAN COMM CIRCUIT ...................... 95
DTC [U1010] CONTROL UNIT (CAN) .................... 95
LDW Chime Circuit Inspection ................................ 95
LDW Switch Circuit Inspection ................................ 96
LDW Indicator Lamp Circuit Inspection ................... 99
Turn Signal Input Inspection .................................100
Electrical Component Inspection ..........................100
LDW SWITCH ....................................................100
Removal and Installation for LDW Camera Unit ...100
REMOVAL ..........................................................100
INSTALLATION ..................................................100
Removal and Installation for LDW Chime .............101
REMOVAL ..........................................................101
INSTALLATION ..................................................101
Removal and Installation for LDW Switch .............101
COMPASS ...............................................................102
Precautions for Compass ......................................102
System Description ...............................................102
Troubleshooting ....................................................103
Zone Variation Setting Procedure .........................104
Calibration Procedure ...........................................104
Wiring Diagram – COMPAS – ...............................105
Removal and Installation of Compass ...................106
CLOCK ....................................................................107
Wiring Diagram — CLOCK — ...............................107
Removal and Installation of Clock .........................108
REMOVAL ..........................................................108
INSTALLATION ..................................................108
CAN COMMUNICATION .........................................109
System Description ...............................................109
CAN Communication Unit .....................................109

Page 1422 of 4647

INFINITI M35 2007 Factory Service Manual PRECAUTION
DI-3
C
D
E
F
G
H
I
J
L
MA
B
DI
Revision: 2007 April2007 M35/M45
PRECAUTION PFP:00011
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
NKS

Page 1423 of 4647

INFINITI M35 2007 Factory Service Manual DI-4
PREPARATION
Revision: 2007 April2007 M35/M45
PREPARATIONPFP:00002
Commercial Service ToolsNKS003TU
Tool nameDescription
Power toolLoosening bolts, nuts and screws
PIIB1407E

Page 1424 of 4647

INFINITI M35 2007 Factory Service Manual COMBINATION METERS
DI-5
C
D
E
F
G
H
I
J
L
MA
B
DI
Revision: 2007 April2007 M35/M45
COMBINATION METERSPFP:24814
System DescriptionNKS003TV
UNIFIED METER CONTROL UNIT
Speedometer, odo/trip meter, tacho

COMBINATION METERS
DI-5
C
D
E
F
G
H
I
J
L
MA
B
DI
Revision: 2007 April2007 M35/M45
COMBINATION METERSPFP:24814
System DescriptionNKS003TV
UNIFIED METER CONTROL UNIT
Speedometer, odo/trip meter, tachometer, fuel gauge and water temperature gauge are controlled by the
unified meter control unit, which is built into the combination meter. Unified meter control unit receives sig-
nals from unified meter and A/C amp.
Warning lamp and indicator lamp of combination meter are controlled by signals drawn from the unified
meter and A/C amp.
Digital meter is adopted for odo/trip meter.
NOTE:
The record of the odo meter is kept even if the battery cable is disconnected. The record of the trip meter
is erased when the battery cable is disconnected.
Dot matrix LCD is adopted to display “push engine starter”, “A/T position” and “ICC system* ”.
Odo/trip meter and dot matrix LCD segments can be checked in self-diagnosis mode.
Meters/gauges can be checked in self-diagnosis mode.
*: With ICC system
UNIFIED METER AND A/C AMP.
Refer to DI-28, "COMBINATION METER CONTROL FUNCTION" in “UNIFIED METER AND A/C AMP”.
POWER SUPPLY AND GROUND CIRCUIT
Power is supplied at all times
through 10A fuse [No. 21, located in the fuse block (J/B)]
to combination meter terminal 23,
through 10A fuse [No. 19, located in the fuse block (J/B)]
to unified meter and A/C amp. terminal 54.
With the ignition switch in the ACC or ON position, power is supplied
through 10A fuse [No. 6, located in the fuse block (J/B)],
to combination meter terminal 2, and
to unified meter and A/C amp. terminal 41.
With the ignition switch in the ON or START position, power is supplied
through 10A fuse [No. 14, located in the fuse block (J/B)]
to combination meter terminal 12,
through 10A fuse [No. 12, located in the fuse block (J/B)]
to unified meter and A/C amp. terminal 53.
Ground is supplied
to combination meter terminals 9, 10 and 11
to unified meter and A/C amp. terminals 55 and 71
through grounds M16 and M70.

Load next 8 pages

Page: < prev 1-10 ... 1385-1392 1393-1400 1401-1408 1409-1416 1417-1424 1425-1432 1433-1440 1441-1448 1449-1456 ... 4648 next >

oil dipstick rear entertainment refuelling washer fluid deactivate airbag service reset
