AV-96
[WITHOUT MOBILE ENTERTAINMENT SYSTEM]
DIAGNOSIS SYSTEM
Revision: 2007 April2007 M35/M45
AV COMM CIRCUIT
Amplifier Connection Error
BOSE amp power supply and
ground circuit malfunction is
detected
Malfunction is detected on communi-
cation signal between BOSE amp
and AV (NAVI) control unit
BOSE amp power supply and ground
circuit
BOSE amp
AV (NAVI) control unit
Front Display Connection Error
Front display unit power supply and
ground circuit malfunction is
detected
Malfunction is detected on communi-
cation circuit between front display
unit and AV (NAVI) control unit
Malfunction is detected on communi-
cation signal between front display
unit and AV (NAVI) control unit
Front display unit power supply and
ground
Communication circuit between front
display unit and AV (NAVI) control unit
Front display unit
AV (NAVI) control unit
GPS Antenna ErrorGPS antenna connection malfunction
is detected
GPS antenna feeder
GPS antenna
NAVI control unit
Camera Control Unit Connection ErrorCamera and connection recognition
signal circuit malfunction is detected
Camera-connection recognition signal
circuit
Camera control unit
AV (NAVI) control unit
FLASH-ROM Error Of Control UnitAV (NAVI) control unit malfunction is
detectedReplace AV (NAVI) control unit
Refer to AV-131, "
AV (NAVI) Control Unit"
Connection Of GyroNAVI control unit malfunction is
detectedReplace NAVI control unit
Refer to AV-131, "AV (NAVI) Control Unit"
GPS Communication Error
GPS malfunction is detectedIf the symptoms such as the GPS receipt
malfunction occur, intermittent malfunction
caused by strong radio interference may
be detected.
If the malfunction always occurs, replace
NAVI control unit. GPS ROM Error
GPS RAM Error
GPS RTC Error
DVD-ROM Communication Error
Malfunction is detected on DVD-
ROM drive pickup lens in NAVI con-
trol unit
There is dirt and damage on the map
disc
Map disc
NAVI control unit
Refer to AV-131, "
AV ( N AV I ) C o n t r o l
Unit" DVD-ROM Read Error
DVD-ROM Disc Error
DVD-ROM Mechanism not Detected
DVD-ROM Mechanism Error
DVD-ROM Focus Error
DVD-ROM TOC Error
DVD-ROM Seek Error
DVD-ROM Error Correction Error
DVD-ROM Data Transfer Error
DVD-ROM Data Error
DVD-ROM Time-out
DVD-ROM Loading / Eject Error
CAN Controller Memory Error
AV (NAVI) control unit malfunction is
detectedReplace AV (NAVI) control unit
Refer to AV-131, "
AV (NAVI) Control Unit"Bluetooth Module Connection ErrorError item Description Possible cause/Action to take
Page 722 of 4647
![INFINITI M35 2007 Factory Service Manual DIAGNOSIS SYSTEM
AV-97
[WITHOUT MOBILE ENTERTAINMENT SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2007 April2007 M35/M45
VEHICLE CAN DIAGNOSIS
CAN communication status and error counter is displayed.
INFINITI M35 2007 Factory Service Manual DIAGNOSIS SYSTEM
AV-97
[WITHOUT MOBILE ENTERTAINMENT SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2007 April2007 M35/M45
VEHICLE CAN DIAGNOSIS
CAN communication status and error counter is displayed.](/manual-img/42/57024/w960_57024-721.png)
DIAGNOSIS SYSTEM
AV-97
[WITHOUT MOBILE ENTERTAINMENT SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2007 April2007 M35/M45
VEHICLE CAN DIAGNOSIS
CAN communication status and error counter is displayed.
Error counter displays 0 if any malfunction is not detected in the
past. If the malfunction is detected, it displays 40. When turning
the ignition switch ON, if it is normal, it displays 39. The lower
limit of the counter is 1.
If it is reset, the error counter is deleted.
NOTE:
“???” indicates “UNKWN”.
AV COMM DIAGNOSIS
